212 / 220
Cordless
Benchtop
Saws
Woodworking
Hammers
Dust
Extraction
Drills
Metalworking
Pneumatic
OPE
Manufacturing
And Assembly
STANDARD EQUIPMENT INCLUDES:
Tool-Kit (282-290301-H0),Two Spark Plugs (065-01402-80), (Battery Not Included)
Electric Start
• RECEPTACLES: Duplex 120V (20 AMP), Locking 120V (20 AMP), Locking 120V (30 AMP),
Locking 120V / 240V (30 AMP)
• GENERATOR: Full copper windings, AC & DC circuit breakers, AVR (Automatic Voltage Regulator)
• SUBARU-ROBIN: Air-cooled 4 cycle single cylinder OHC gasoline engine, Idle switch features full
power mode, Low oil automatic shut-off, Auto
decompression / Electronic ignition, Overhead
valve for more fuel efficiency
8.2 Hours Of Continuous Operation
12,000W / 653cc 4-Stroke Generator
SPECIFICATIONS
Maximum Output Current
12,000W
(100 / 50 AMP)
Rated Output Current 9,500W / 79.2 / 39.6 A
AC Voltage
60 Hz (120V / 240V)
DC Voltage
12 VDC (8.3 AMP)
Displacement
653cc
Maximum Power
22 HP @ 3,600 RPM
Fuel Tank Capacity
44 L
Continuous Operation
8.2 Hrs (at high RPM)
Noise Level
77 dB
Dimensions (L x W x H)
32.5" x 24.1" x 30.4"
(826 mm x 611 mm x 771 mm)
Dry Weight
310.0 lbs (141 kg)
G12000R
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
Blade (1 Ea. B-20432, 1 Ea. 723063-A-5), Hex Wrench 3 (783201-2)
Ultra-Compact And Lightweight Design For Maximum Versatility
and Maneuverability
• Multi-position switch (tool handle & tool body) with lock-off levers for easier operation, maximum
versatility and operator safety
• Battery protection system provides over-discharge,
temperature and circuit protection for
enhanced performance, battery cycle life
and overall battery life
• One-handed, fast tool-less blade changes
• LED joblight with afterglow feature
18V LXT Cordless Reciprocating Saw
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Maximum Cutting Capacities:
Pipe
2" (50 mm)
Wood (12" Blade)
2" (50 mm)
Strokes Per Minute
0 - 3,000 SPM
Length of Stroke
1/2" (13 mm)
Overall Length
15-5/8" (398 mm)
Net Weight
2.7 lbs (1.2 kg)
DJR183Z
210
HEDGE TRIMMERACCESSORIES
Blade Cover
Part No.
Chip Receiver
Part No.
For Models
195274-7
198402-3
UH201DZ
450490-1
194681-1 DUH651Z, UH5570
UH6570
451868-1
451866-5
EN7350SH
452327-8
-
EH6000W
452328-6
-
EN401MP, EN4950H
453723-3
195050-9
DUH523Z
454277-3
-
EH7500W
454278-1
-
EN5950SH
454279-9
-
EH5000W, EN410MP
EN4951SH
457036-4
-
EN420MP
195050-9
UH201DZ
STANDARD EQUIPMENT INCLUDES:
ToolOnly.BatteriesandChargerSoldSeparately.
ShearBladeAssemblySet (198409-9),BladeCover (195274-7),
ChipReceiverSet (198402-3)
Compact Design For Added Versatility
• Dual Blade action cuts quickly with shearing effect
• Chip Receiver prevents material from falling onto blade
• Non-Electrolyzed Nickel Plated Blades reduce staining and rusting
• Tool-less Blade Changing System enables simple and easy blade changes
7-7/8" / 12V LXT Cordless Hedge Trimmer
SPECIFICATIONS
Battery Capacities 12V MAX CXT Li-Ion
No Load Speed
2,500 SPM
Cutting Length
7-7/8" (200 mm)
Maximum Cutting Thickness 5/16" (8 mm)
Overall Length
19-7/8" (504 mm)
Net Weight
2.5 lbs (1.1 kg)
Optional Grass
Shear Attachment
for UH201DZ
Shear BladeAssembly
195176-7
Blade Cover
452055-5
Grass Catcher
457426-1
Chip Receiver Set
(Standard Equipment)
(Part No. 198402-3)
OUTDOOR
Power Equipment
makita.ca
>
WHERE TOBUY
>
Buy INASTORE !
Visit us online
>
makita.ca
Used To Cut Steel, Concrete
And Masonry Materials
• Guide wheels on the tool guard ensure smooth tool
travel over surface material
• Rubber shield protects the operators hand and motor from debris
• Lock-On button for continuous operation
• Ball bearing construction for longer tool life
• “SJS” technology prevents kickback if blade jams protecting
both the operator and tool
• Integrated nozzle can be connected to vacuum system for clean operation
4114, 4112H
Angle Cutters
SPECIFICATIONS
Arbor
1" (25.4 mm)
AMPS (120V)
15.0A
4114:
Blade Diameter
14" (355 mm)
Maximum Cutting Depth
5" (125 mm)
Overall Length
26-1/2" (673 mm)
Net Weight
22.7 lbs (10.3 kg)
4112H:
Blade Diameter
12" (305 mm)
Maximum Cutting Depth 3-15/16" (100 mm)
Overall Length
25-1/2" (648 mm)
Net Weight
25.1 lbs (11.4 kg)
STANDARD EQUIPMENT INCLUDES:
Plastic Carrying Case (824697-9),
Socket Wrench 17 (782210-8)
4112H
12" Blade Diameter
STANDARD EQUIPMENT INCLUDES:
Socket Wrench 17 (782210-8),
Elbow Joint (P-80008)
4114
14" Blade Diameter
