211 / 220
OUTDOOR
Power Equipment
UM600DZ
12V MAX CXT Slide
STANDARD EQUIPMENT INCLUDES:
UM600DZ:
ToolOnly.BatteriesandChargerSoldSeparately.
ShearBladeAssembly (195176-7),BladeCover (452055-5),GrassCatcher (457426-1)
MU01Z:
Tool Only. Batteries and Charger Sold Separately.
Shear BladeAssembly (195176-7), Base Frame (325896-1),
Change Lever (451813-6), Blade Cover (452055-5)
Compact Design For Added Versatility
• Dual Blade action cuts quickly with shearing effect
• Non-Electrolyzed Nickel Plated Blades reduce staining and rusting
• Grass Catcher enables quick and easy depth adjustment
• Tool-less Blade Changing System enables simple and easy blade changes
6-5/16" / 12V LXT Cordless Grass Shears
SPECIFICATIONS
Battery Capacities 12V MAX CXT Li-Ion
No Load Speed
2,500 SPM
Cutting Width
6-5/16" (160 mm)
Depth Adjustment
5/8" / 13/16" / 1"
(15 mm / 20 mm / 25 mm)
Overall Length
13-5/8" (347 mm)
Net Weight
2.5 lbs (1.1 kg)
Optional Hedge
Trimmer Attachment
for UM600DZ or MU01Z
Shear BladeAssembly
198409-9
Chip Receiver Set
198402-3
Blade Cover
195274-7
MU01Z
12V MAX (1.3 Ah) Pod
UM600DZ
UM600DZ:
12V MAX CXT Slide
MU01Z:
12V MAX (1.3 Ah) Pod
MU01Z
DUM604Z
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
Shear BladeAssembly (195176-7), Blade Cover (452055-5), Grass Catcher (457426-1)
Compact Design For Added Versatility
• Dual Blade action cuts quickly with shearing effect
• Non-Electrolyzed Nickel Plated Blades reduce staining and rusting
• Grass Catcher enables quick and easy depth adjustment
• Tool-less Blade Changing System enables simple and easy blade changes
• Left and Right Hand Lock Off Button for operator safety
• Ergonomic Soft Rubber Grip design for vibration absorption and
comfortable operation
• Optional Hedge trimmer blade kit for converting tool to use as a
precise hedge trimmer
6-5/16" / 18V LXT Cordless Grass Shear
SPECIFICATIONS
Battery Capacities
18V Li-Ion
No Load Speed
2,500 SPM
Cutting Width
6-5/16" (160 mm)
Depth Adjustment
5/8" / 13/16" / 1-5"
(15 mm / 20 mm / 35 mm)
Overall Length
13-7/8" (353 mm)
Net Weight
2.5 lbs (1.1 kg)
Dual Blade
Action
Optional Hedge
Trimmer Attachment
for DUM604Z
Hedge Trimmer Blades
195178-3
Hedge Trimmer Cover
195274-7
EN4951SH
STANDARD EQUIPMENT INCLUDES:
HedgeTrimmer HeadAssembly (135780-0), Blade Cover (454279-9), Box Driver 10-16 (782233-6), Hex Wrench 4 (783223-2),
Starter Rope (444023-2), Spark Plug (168534-0), Shoulder Harness (125516-5), Oil Supply,Accessory Bag (831304-7)
Short Shaft Style Ideal For Reaching Taller Hedges Or Lower Hedge Areas
Without Extended Up Reaching Or Bending Down
Complies with CARB Tier 3, EPA Phase 2, EU Stage 2 Emissions Requirements
• Multi-position engine lubrication system allows Makita 4-Stroke Pole Hedge Trimmers
to be operated at any angle for maximum versatility
• 135° hedge trimmer head articulation (-90° - 45°) with 13 positive
stops (11.25° increments)
• Pin style angle securing system provides added retention at
positive stop angles versus friction securing systems
• Hedge trimmer blades fold up to 180° to provide
compact size during transport or storage
• Clutch prevents engagement of hedge trimmer
head when folded in the 180° position for
maximum safety during transport
or storage
19-1/4" / 25.4cc 4-Stroke Short Shaft Pole Hedge Trimmer
SPECIFICATIONS
Displacement
25.4cc
Maximum Engine Power 0.77 Kw / 1.03 HP
Cutting Length
19-1/4" (490 mm)
Carburetor
Diaphragm Type
Fuel Tank Capacity
0.6 L
Overall Length
80-1/2" (205 cm)
Net Weight
14.5 lbs (6.6 kg)
With Adjustable
Cutting Head
Cordless
Benchtop
Saws
Woodworking
Hammers
Dust
Extraction
Drills
Metalworking
Pneumatic
OPE
Manufacturing
And Assembly
209
HKU01ZX2
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
Direct Connect Battery Converter
Lightweight Design with High Efficiency, Zero Emissions
and Low Noise Level
• Zero Emissions and Low Noise Level ideal for use in sensitive work environments,
including residential areas and more
• Adjustable 3-Stage Handle enables positioning at optimal angle of operation or for more compact
storage when not in use
• Battery Capacity Warning Light
indicates approximate remaining
battery power for each battery
• Transport Wheels enable easy
movement around the work site
and can be folded upright
when not in use
13-3/4" / 18Vx2 LXT Cordless Cultivator
SPECIFICATIONS
Battery Capacities:
36V Li-Ion
Two 18V Li-Ion
No Load Speed:
Tine Axle Speed
85 RPM
Motor Speed
4,100 RPM
Cultivating Width
13-3/4" / 8-7/8" (350 / 225 mm)
Tine Diameter
9-5/8" (245 mm)
Transmission Speeds
1-Forward
Dimensions (L x W x H)
47" x 19-1/4" x 39-1/4"
(119 cm x 49 cm x 100 cm)
Net Weight
48.5 lbs (22.2 kg)
makita.ca
>
WHERE TOBUY
>
Buy ONLINE !
Follow us @makita.ca
DUN600L
Refer to
makita.ca
>
New Tools
for updates!
23-5/8" / 18Vx2 LXT Cordless Pole Hedge Trimmer
Coming
Soon!
MAINTENANCE ACCESSORIES FORGAS POWERED
LINE TRIMMERS&BRUSHCUTTERS
Description For Engine No.
For Models
Contents Part No.
4-Stroke Engine
Maintenance Kit for
Line Trimmers &
Brush Cutters
EH025
EH035
EBH253L, EBH253U
EBH341L, EBH341U
ER2550LH
Air Filter x 2
Fuel Filter
Spark Plug
197678-9
Lubricating
Maintenance Grease
for Line Trimmers
& Brush Cutters
N 00
EBH253L, EBH253U
EBH341L, EBH341U
EM2600L, EM400MP
EM401MP, ER2550LH
ER2600L, ER400MP
80 g 197437-1
197437-1
197678-9
Service Gear
Assembly Every
30 Hours
