217 / 220
Cordless
Power Tools
COLOURCODEDPLASTIC PROTECTORS& IDENTIFIERS
BFT Series
BTD & BTW Series
BFL Series
Models
BFT020FZ, BFT040FZ
BFT041FZ, BFT044Z
BFT080FZ, BFT084Z
BFT081FZ, BFT082FZ
BFT084FZ, BFT122FZ
BFT123FZ, BFT124FZ
BFT126FZ
BTD040Z
BTD042Z
BTD060Z
BTD062Z
BTW070Z
BTW072Z
BTD044Z
BTD064Z
BTD104Z
BTW074Z
BTW104Z
Models
BFL080FZ, BFL081FZ, BFL082FZ, BFL120FZ
BFL121FZ, BFL122FZ, BFL200FZ, BFL201RZ
BFL202FZ, BFL301RZ, DFL082FZ, DFL300FZ
DFL400FZ, DFL402RZ
Part No.
Part No.
Clutch Case Only Angle Head Only Complete
Yellow
418423-2
-
-
Yellow 418691-7
418692-5 418693-3 418032-7
Blue
418424-0
417835-6
454420-4
Blue
418743-4
418746-8 418749-2 418064-4
Red
418425-8
417834-8
454422-0
Red
418744-2
418747-6 418750-7 418065-2
Clear
450331-1
417349-5
454421-2
Clear
418745-0
418748-4 418751-5 418066-0
ASSEMBLYACCESSORIES
194444-5
800W96-7
889920-9
A-55924
638386-8
194089-9
765027-4
Receiver
RCV02
RCV02
Software
CD-ROM
RCV02
Instructional
CD-ROM
RCV02with
CD-ROMSet
Includes Instructional
and Software CD-ROM's
RS-232C
Cable
USB
Serial
Adapter
Set
Torque
Adjustment
Tool
For all BFH, BFL and
BFT models
TD091DZ
STANDARD EQUIPMENT INCLUDES:
ToolOnly.BatteriesandChargerSoldSeparately.
High Operational Efficiency With Ultra-Compact Design
• Heavy-duty design with 4-pole motor for maximum operational efficiency and reliability
• Electric brake stops driver bit immediately after trigger is released to prevent over-tightening of fasteners
• Short trigger stroke (just 1/4"!) minimizes operator fatigue during periods of prolonged use in
manufacturing / production applications
• Battery capacity warning light indicates ideal time to recharge battery
• Automatic battery shut-off system protects against over-discharge of cells and incomplete fastening
due to low battery power
• LED job light with pre-glow feature
• Ergonomic soft rubber grip design for vibration absorption and comfortable operation
Variable Speed,
Reversible,
Electric Brake
1/4" Impact Driver
SPECIFICATIONS
Battery
12V MAX Li-Ion
Capacity (Driving Shank)
Hex
1/4"
No Load Speed
0 - 2,400 RPM
Impacts Per Minute
0 - 3,000 IPM
Fastening Torque 90 Nm. (800 in./lbs)
Width
2-1/8" (54 mm)
Height
7-7/8" (200 mm)
Length
5-1/4" (134 mm)
Net Weight
1.6 lbs (0.7 kg)
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
1/4" Impact Drivers
SPECIFICATIONS
Battery Capacities
14.4V Li-ion
Capacity (driving shank)
Hex
1/4"
Impacts Per Minute
0 - 3,500 IPM
Width
2-15/16" (74 mm)
Height (with battery)
8-1/2" (216 mm)
Length
5-5/8" (144 mm)
No Load Speed:
DTD044Z
0 - 2,300 RPM
DTD064Z
0 - 2,500 RPM
BTD104Z
0 - 2,700 RPM
Fastening Torque Up To:
DTD044Z
35 Nm. (310 in./lbs)
DTD064Z
65 Nm. (575 in./lbs)
BTD104Z
95 Nm. (841 in./lbs)
Net Weight:
DTD044Z
1.8 lbs (0.8 kg)
DTD064Z
1.6 lbs (0.7 kg)
BTD104Z
1.8 lbs (0.8 kg)
High Fastening Precision With
Compact And Lightweight Design
• Automatic battery shut-off system warns operator
visually and audibly to prevent incomplete fastening
due to low remaining battery power
• Automatic impact stop system prevents over or
under-tightening by stopping the motor after
completing a pre-set number of impacts
Use only with 14.4V Compact
Li-Ion Battery BL1415NA
(Part No. 196987-3)
Variable / Reversible
LED Display
Panel
DTD044Z DTD064Z BTD104Z
Cordless
Benchtop
Saws
Woodworking
Hammers
Dust
Extraction
Drills
Metalworking
Pneumatic
OPE
Manufacturing
And Assembly
215
ASSEMBLY TOOL
BALANCE HOOK
281012-4
Description
• Fits Makita assembly tools
featuring a balance point
position hole
• Hook allows tool to hang
balanced for repetitive assembly
applications
