MANUFACTURING&ASSEMBLY
BFH120FRAE
STANDARD EQUIPMENT INCLUDES:
Two 12V (2.0Ah) MAKSTAR Batteries
(193928-0), Charger (DC18RA), Steel Carrying Case (183664-6),TorqueAdjustmentTool (765027-4)
• Precise torque control consistently delivers repeatability of +/- 10%
• On board LED and audible signal informs user of successful rundown
• Highly accurate spring clutch
• Designed and manufactured to withstand high volume assembly processes
SPECIFICATIONS
Battery
12V Ni-MH
Capacity (Driving Shank)
Hex
1/4" (6.4 mm)
No Load Speed
400 RPM
Fastening Torque
5.0 - 12.0 Nm.
(44 - 106 in./lbs)
Width
2-3/16" (55.5 mm)
Height (With Battery) 10-15/32" (266 mm)
Length (With Battery)
7-7/8" (200 mm)
Net Weight
3.3 lbs (1.3 kg)
Reversible
BFH040RAE
STANDARD EQUIPMENT INCLUDES:
Two 12V (2.0Ah) MAKSTAR Batteries
(193928-0), Charger (DC18RA), Steel Carrying Case (183664-6),TorqueAdjustmentTool (765027-4)
• Precise torque control consistently delivers repeatability of +/- 10%
• On board LED and audible signal informs user of successful rundown
• Highly accurate spring clutch
• Designed and manufactured to withstand high volume assembly processes
1/4" Hazardous Location Screwdriver
SPECIFICATIONS
Battery
12V Ni-MH
Capacity (Driving Shank)
Hex
1/4" (6.4 mm)
No Load Speed
400 RPM
Fastening Torque
0.8 - 4.5 Nm.
(7 - 40 in./lbs)
Width
2-3/16" (71 mm)
Height (With Battery) 10-15/32" (266 mm)
Length (With Battery)
7-7/8" (200 mm)
Net Weight
3.3 lbs (1.3 kg)
Reversible
1/4" Hazardous Location Screwdriver
HAZLOC Series Tools are the only Cordless Power Tools in the world certified for use in
a Class I Division 2 (group A – D) environment as outlined in UL1604 standard.
Class I:
Specifies that ignitable gases, vapours or liquids exist.
Division 2:
Specifies that concentrations of flammable gases, vapours or liquids are not likely to exist under normal
operating conditions but likely to exist under abnormal conditions.
For Battery and Charger Compatibility
please refer to pages 63–65
BML145
• 4-Position Pivoting Head for greater versatility
• High illumination emits high power at 4,500 Lux
• New Xenon bulb for extra brightness
• BATTERY NOT INCLUDED
14.4V LXT Flashlight
SPECIFICATIONS
Battery Capacities
14.4V Li-Ion
Continuous Use
up to 3.7 hours
Overall Length
11-1/8" (284 mm)
Net Weight
0.9 lbs (0.4 kg)
TD022DS
Compact And Lightweight Design With Precision
Control And High Fastening Torque
• Multi-function variable speed rotary switch allows operators to
adjust driving speed and direction
simultaneously for precise fastening applications
• Switch position enables easy access for left or right handed users
• Lock-off button prevents
accidental startup
1/4" Impact Driver
SPECIFICATIONS
Battery Capacities
7.2V Li-Ion
Hex Shank
1/4"
Impacts Per Minute
0 - 3,000 IPM
No Load Speed
0 - 2,450 RPM
Maximum Fastening Torque
220 in. lbs (25 Nm)
Capacities:
Machine Screw
1/8" - 5/16" (M3 - M8)
Standard Bolt
1/8" - 5/16" (M3 - M8)
High Tensile Bolt
1/8" - 1/4" (M3 - M6)
Overall Length
11-1/8" (282 mm)
Net Weight
1.2 lbs (0.56 kg)
Please refer to pages 50 – 51 and 60 – 61 of this
catalogue for a complete selection of
FLASHLIGHTS
DML807
• Operates in 180º or 360º lantern modes
for flashlight mode
• Features 20 x LEDs with up to 710 Lumens
• Built in USB port enables
convenient charging of
mobile devices on
the jobsite
• eXtreme Protection
Technology (XPT) offers
maximum protection against
dust, debris and liquids for
optimal performance in
extreme conditions
• BATTERY NOT INCLUDED
18V / 14.4V LXT LED Worklight
SPECIFICATIONS
Battery Capacities
18V / 14.4V Li-Ion
Continuous Use Approx. 28 Hours (with battery BL1840B)
Overall Dimensions
14-1/4" x 3-1/8" x 4-3/4"
(361 mm x 79 mm x 121 mm)
Net Weight
0.9 lbs (0.4 kg)
Up To
710
Lumens
STANDARD EQUIPMENT INCLUDES:
7.2V (1.5Ah) Li-Ion Battery
BL0715 (198001-1), Pod / Stick Charger (DC10WB),
Holster (168435-2), Phillips Bit 2-50 (784244-7),Tool Bag (831277-4)
Variable Speed,
Reversible,
Electric Brake
Cordless
Benchtop
Saws
Woodworking
Hammers
Dust
Extraction
Drills
Metalworking
Pneumatic
OPE
Manufacturing
And Assembly
