OUTDOOR
Power Equipment
BHX2500CA
STANDARD EQUIPMENT INCLUDES:
BHX2500CA:
LongNozzle (125729-8),RoundEndNozzle (450966-8),ToolKit (194717-6),StarterRope (444019-3),SparkPlug (0650109950)
BHX2500CAV:
Long Nozzle (125729-8), Round End Nozzle (450966-8),Tool Kit (194717-6), Starter Rope (444019-3),
Spark Plug (0650109950), Vacuum Kit (197234-5)
Air Speed 145 MPH, Max. Air Volume 356 CFM
• Exceeds Government Clean Air Emission Ratings
• 4-Stroke, for low noise and low emission
• Quick-start - low compression engine
for easy starting
• Auto decompression for easy starting
• Easy access to spark plug and air filter
Improved Fuel
Tank Coating Is
EPA Phase II
And CARB III
Compliant
24.5cc 4-Stroke Blower
SPECIFICATIONS
Displacement
24.5cc
Maximum Air Flow
145 MPH
Maximum Air Volume (End Of Nozzle)
356 CFM
Carburetor All Position Diaphragm Type
Fuel / Oil Mixture
Not Required
Power Rating
0.81 kW / 1.1 HP
Tank Capacity
520 ml
Overall Length
13-3/4" (350 mm)
Dry Weight
9.9 lbs (4.5 kg)
EB5300TH
STANDARD EQUIPMENT INCLUDES:
Long Pipe 90 (197723-0), End Nozzle 90-62 (198034-6),
Flat Nozzle 90 (196911-6), Flexible Pipe (454934-3),
Swivel Pipe (161653-1), Box Wrench Set (196771-6),
Shoulder Harness R (162506-7), Shoulder Harness L (162505-9),
Hose Clamp (282025-8), Spark Plug (168652-4),
Starter Rope (444043-6),Accessory Bag (831304-7)
218 MPH Air Speed with
512 CFM Volume
• Professional power in a lighter weight blower
• 4 damper springs mounted between the engine and
the backpack frame reduce the vibration on the
back of operator even during long hours
• Cushioned back padding and shoulder straps,
in addition to being well-ventilated, aid in effective
sweat evaporation and to provide
more operator comfort
• MM4 4-Stroke engine for lower emissions and
longer run time
52.5cc 4-Stroke Backpack Blower
BLOWERACCESSORIES FOR EB7660TH / EB5300TH
Description
For Model No.
Part No.
Long Pipe
EB7660TH
EB5300TH
197723-0
Short Pipe
196912-4
End Nozzle
454896-5
End Nozzle
455128-3
Flat Nozzle
196911-6
BLOWERACCESSORIES FORBHX2500CA
Description
For Model No.
Part No.
Straight Pipe #1
BHX2500CA
455462-1
Straight Pipe #2
454188-2
Pipe #3
454241-4
Round End Pipe
450966-8
Curved End Pipe
451753-8
Elbow
453720-9
Vacuum Assembly
197234-5
Dust Bag
166139-0
Tool Kit
194717-6
SPECIFICATIONS
Displacement
52.5cc
Maximum Air Flow
(Long Pipe, End Nozzle 90-62) 218 MPH
Maximum Air Volume
(Long Pipe, End Nozzle 90-62) 512 CFM
Carburetor
Diaphragm Type
Fuel / Oil Mixture
Not Required
Power Rating
1.8 kW / 2.5 HP
Tank Capacity
1.8 L
Overall Length
12-5/8" (320 mm)
Dry Weight
19.7 lbs (8.9 kg)
4-Stroke MM4 engine for
lower emissions and greater
fuel economy
EB7660TH
STANDARD EQUIPMENT INCLUDES:
Long Pipe 90 (197723-0), End Nozzle 90-68 (197722-2),
Flat Nozzle 90 (196911-6), Flexible Pipe (454934-3),
Swivel Pipe (161653-1), Box Wrench Set (196771-6),
Shoulder Harness L (162501-7), Shoulder Harness R (162502-5),
Hose Clamp (282025-8), Spark Plug (168652-4),
Starter Rope (444043-6),Accessory Bag (831304-7)
205 MPH Air Speed with 705 CFM Volume
• For the demanding professional. Now with more power and air flow.
• 4 damper springs mounted between the engine and the backpack frame reduce the vibration on the
back of operator even during long hours
• Cushioned back padding and shoulder straps, in addition to being well-ventilated, aid in effective
sweat evaporation and to provide
more operator comfort
• MM4 4-stroke engine for lower emissions and
longer run time
• Anti-Icing feature: You can open the anti-icing
valve by simply turning a dial to supply warm air
from the engine to prevent the carburetor from icing
up under cold conditions.
• Extendable pipe and nozzle (3" extension)
• Anti-static – Users hand is protected from static
electric shock by sufficient insulation
distance between grip and nozzle
75.6cc 4-Stroke Backpack Blower
SPECIFICATIONS
Displacement
75.6cc
Maximum Air Flow (Long Pipe) 205 MPH
Maximum Air Volume (Long Pipe) 706 CFM
Carburetor
Diaphragm Type
Fuel / Oil Mixture
Not Required
Power Rating
3.0 kW / 4.1 HP
Tank Capacity
1.9 L
Overall Length
13 -1/8" (332 mm)
Dry Weight
24.1 lbs (10.9 kg)
4-Stroke MM4 engine for
lower emissions and greater
fuel economy
BHX2500CAV
BHX2500CAV
includes Vacuum Kit
PM7650H
STANDARD EQUIPMENT INCLUDES:
Nozzle Set (196499-6), Flexible Pipe (412115-5), Straight Pipe 380
(453700-5),SwivelPipe (168746-5),ShoulderHarnessR (161510-3),
Shoulder Harness L (161509-8), Hand Strap (163319-9), Band 25
Set (199237-5), Diffusion Cover (453506-1), Hose Clamp 76
(282024-0), Hose Clamp 100 (282025-8), Box Wrench (782237-8),
Driver (783019-1),SparkPlug (0650109950),StarterRope (444043-6)
190 MPH Air Speed with 497 CFM Volume and a Spray Range of
52 Feet (horizontal)
• 4 damper springs mounted between the engine and the backpack frame reduce the vibration on
the back of operator even during long hours
• Cushioned back padding and shoulder straps, in addition to being well-ventilated, aid in effective
sweat evaporation and to to provide more operator comfort
• MM4 4-stroke engine for lower emissions and longer run time
• L-shaped chemical tank lowers center of gravity for improved balance
• Single action switch to activate liquid chemical flow
• Liquid chemical in tank is automatically mixed by
intake air flow for uniform solution concentration
• Compact design with less weight (30.7 lbs)
• 61 oz. (1.8 litres) fuel tank with large openings
for longer run time and easy refueling
75.6cc 4-Stroke Backpack Mist Blower
SPECIFICATIONS
Displacement
75.6cc
Maximum Air Flow
190 MPH
Maximum Air Volume
497 CFM
Power Rating
2.7 kW / 3.67 HP
Carburetor
Diaphragm Type
Fuel / Oil Mixture
Not Required
Tank Capacity
1.8 L
Overall Length
16-1/2" (420 mm)
Dry Weight
30.7 lbs (13.9 kg)
Ideal for application of
insecticides, herbicides,
fungicides, and liquid fertilizers
Turning off the spray
valve, the PM7650H can be
used for blower applications
