209 / 220
OUTDOOR
Power Equipment
DUH523SF
STANDARD EQUIPMENT INCLUDES:
DUH523SF:
18V (3.0Ah) Li-Ion Battery
BL1830B (194205-3), Standard Charger (DC18SD), Shear Blade Complete Set (195846-8),
Blade Cover (453723-3)
DUH523Z:
Tool Only. Batteries and Charger Sold Separately.
Blade Cover (453723-3), Shear Blade Complete Set (195846-8)
Designed for Maximum Versatility and Ease of Operation
• Battery Protection System provides Over-Discharge, Temperature and Current Protection
for enhanced performance, battery cycle life and overall battery life
• Anti-Vibration Structure features five cushions linking handle and motor sections for significantly
reduced vibration transmission to operator
• Non-Electrolyzed Nickel Plated Blades reduce
staining and rusting
• Tool-less Blade Changing System
enables simple and easy blade changes
• Ergonomic Soft Rubber Grip design for
vibration absorption and comfortable
operation
22" / 18V LXT Cordless Hedge Trimmer
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Strokes Per Minute (min-1)
1,350 SPM
Cutting Length
22" (560 mm)
Maximum Cutting Thickness
15/32" (12 mm)
Overall Length
38" (96 cm)
Net Weight
6.0 lbs (2.7 kg)
Dual Blade Action
DUH523Z
DUH602Z
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
Shear BladeAssembly Set (199101-0), Blade Cover (459121-9), Safety Goggles (195246-2)
Reduced Noise And Emissions Versus Competitive Gas Models
• eXtreme Protection Technology (XPT) offers maximum protection against dust, debris and liquids for
optimal performance in extreme conditions
• Electric brake stops blade 3-5 seconds after trigger is released
for increased operator safety
• Battery capacity warning light indicates
approximate remaining battery power
• 5 position rotating rear handle with positive stops
at 0°, 45° and 90° enables optimal positioning
when cutting vertical or angled hedges
• 3 speed selection switch plus variable speed
trigger to tailor the tool to the trimming needs
• Reverse button function for freeing
the blade if it happens to jam
• Dual blade action cuts quickly
with shearing effect
23-5/8" / 18V LXT Cordless Hedge Trimmer
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Strokes Per Minute (min-1)
0 - 2,000 / 0 - 3,600 / 0 - 4,400 SPM
Cutting Length
23-5/8" (600 mm)
Maximum Cutting Thickness
7/8" (21.5 mm)
Overall Length
43-3/4" (111.3 cm)
Net Weight
7.8 lbs (3.5 kg)
Dual Blade Action
Cordless
Benchtop
Saws
Woodworking
Hammers
Dust
Extraction
Drills
Metalworking
Pneumatic
OPE
Manufacturing
And Assembly
207
makita.ca
>
WHERE TOBUY
>
Buy ONLINE !
Follow us @makita.ca
5 Position Adjustable Rear Handle for Vertical or Angle Trimming
• 3 Edge Tooth Design and High Anti-Abrasion Coated Surface for Stain Free Long Lasting Operation
• Double Sided Stainless Steel Blades for Extended Life, Clean Trimming and Cutting on Both Sides of Blade
• Extended 50 Hour Long Life Gear Case Lubrication System offers Minimal Service Maintenance by circulating grease in the gear housing.
• 5 Position Adjustable Rear Handle for Vertical or Angle Trimming
• Anti-vibration design for Less Operator Fatigue
• Forward Facing Exhaust redirects away from the operator
STANDARD EQUIPMENT INCLUDES:
Two Shear Blades,
Blade Cover (454277-3), End Cover Set (196969-5),
Box Driver 10-16 (782233-6), Hex Wrench 4 (783223-2),
Starter Rope (444028-2), Spark Plug (0650109950)
EH7500W
STANDARD EQUIPMENT INCLUDES:
Two Shear Blades
(725184-0), Blade Cover (454278-1), End Cover Set (196969-5),
Box Driver 10-16 (782233-6), Hex Wrench 4 (783223-2),
Starter Rope (444028-2), Spark Plug (0650109950)
EH6000W
STANDARD EQUIPMENT INCLUDES:
Two Shear Blades,
Blade Cover (454279-9), End Cover Set (196969-5),
Box Driver 10-16 (782233-6), Hex Wrench 4 (783223-2),
Starter Rope (444028-2), Spark Plug (0650109950)
EH5000W
SPECIFICATIONS
Displacement
22.2cc
Maximum Engine Power 0.68 kW / 0.91 HP
Cutting Length 19" (483 mm)
Carburetor
Diaphragm Type
Fuel / Oil Mixture
50:1
Fuel Tank Capacity
400 ml
Overall Length
40" (101 cm)
Net Weight
10.5 lbs (4.8 kg)
SPECIFICATIONS
Displacement
22.2cc
Maximum Engine Power 0.68 kW / 0.91 HP
Cutting Length 28-3/4" (728 mm)
Carburetor
Diaphragm Type
Fuel / Oil Mixture
50:1
Fuel Tank Capacity
400 ml
Overall Length
49-1/2" (125 cm)
Net Weight
11.4 lbs (5.2 kg)
SPECIFICATIONS
Displacement
22.2cc
Maximum Engine Power 0.68 kW / 0.91 HP
Cutting Length 23-1/8" (588 mm)
Carburetor
Diaphragm Type
Fuel / Oil Mixture
50:1
Fuel Tank Capacity
400 ml
Overall Length
44" (111 cm)
Net Weight
11.0 lbs (5.0 kg)
EH7500W, EH6000W, EH5000W
22.2cc 2-Stroke Hedge Trimmers
EH5000W
Reduced Noise And Emissions
Versus Competitive Gas Models
• Accepts two 18V Li-Ion batteries without a battery converter for use with existing 18V Li-Ion battery platform
• eXtreme Protection Technology (XPT) offers maximum protection against dust, debris and liquids
for optimal performance in extreme conditions
• Electric brake stops blade 3-5 seconds after trigger is released for
increased operator safety
• Battery capacity warning light indicates approximate remaining
battery power
• 5 position rotating rear handle with positive stops at 0°, 45° and 90°
enables optimal positioning when cutting vertical or angled hedges
• Variable speed dial enables operator to adjust cutting speed based on
materials or application
• Dual blade action cuts quickly with shearing effect
SPECIFICATIONS
Battery Capacities
Two 18V Li-Ion
Strokes Per Minute (min-1)
1,000 - 1,800 SPM
Cutting Length
25-1/2" (650 mm)
Maximum Cutting Thickness
11/16˝ (18 mm)
Overall Length
48-1/2" (123 cm)
Net Weight
8.9 lbs (4.0 kg)
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
Front Nozzle (455914-2), Long Nozzle (455915-0)
DUH651Z
25-1/2" / 18Vx2 LXT Cordless Hedge Trimmer
DUH651Z
Dual Blade Action!
