HAMMERS
118
STANDARD EQUIPMENT INCLUDES:
Straight Side Handle Incl. Depth Gauge (135209-6), Bit Grease (194683-7), Plastic Carrying Case (824798-3)
SDS-MAX Shank
Hammer & Rotation / Hammer Only
• Torque Limiter stops bit rotation if bit jams for increased operator safety and enhanced tool protection
• 12 Angle Bit Positions enable chisels to be positioned at optimum angle of operation
• One-Touch Sliding Chuck for easy bit installation and removal
• Ergonomic Soft Rubber Grip for vibration absorption and comfortable operation
1-9/16˝ Rotary Hammer
SPECIFICATIONS
Bit Type SDS-MAX
Maximum Capacities:
Concrete (TCT) 1-9/16˝ (40 mm)
Concrete (Core Bit) 4-1/8˝ (105 mm)
No Load Speed 680 RPM
Blows Per Minute 2,500 BPM
Impact Energy 6.2 J (4.6 ft.lbs)
AMPS (120V) 10.0 A
Overall Length 18˝ (458 mm)
Net Weight 14.6 lbs (6.6 kg)
HR4002
Cordless
Benchtop
Saws
Woodworking
Hammers
Dust
Extraction
Drills
Metalworking
Pneumatic
OPE
Manufacturing And Assembly
STANDARD EQUIPMENT INCLUDES:
HR2811F: Side Handle (158057-6), Depth Gauge (324219-0), Plastic Carrying Case (824789-4)
HR2811FT: Side Handle (158057-6), Depth Gauge (324219-0), Quick Change Drill Chuck (194079-2), Plastic Carrying Case (824789-4)
SDS-PLUS Shank
Hammer & Rotation / Hammer Only / Rotation Only
• Compact L-Shaped Motor Housing for high
maneuverability and better handling
• Torque Limiter stops bit rotation if bit jams
for increased operator safety and enhanced
tool protection
Variable Speed,
Reversible
1-1/8˝ Rotary Hammers
SPECIFICATIONS
Bit Type SDS-PLUS
Maximum Capacities:
Concrete 1-1/8˝ (28 mm)
Steel 1/2˝ (13 mm)
Wood 1-1/4˝ (32 mm)
No Load Speed 0 - 1,100 RPM
Blows Per Minute 0 - 4,500 BPM
Impact Energy 2.9 J (2.1 ft. lbs)
AMPS (120V) 7.0 A
HR2811F: Overall Length
12-5/8˝ (320 mm)
Net Weight 7.7 lbs (3.5 kg)
HR2811FT: Overall Length
(with SDS-PLUS Chuck)
13-5/8˝ (345 mm)
Net Weight 7.9 lbs (3.6 kg)
HR2811F HR2811FT
Makita offers a wide variety of ACCESSORIES!
SDS-MAX Shank
Hammer & Rotation / Hammer Only
• Anti-Vibration Technology (AVTTM) actively counteracts vibration of
tool for greatly reduced transmission to operator
• Torque Limiter stops bit rotation if bit jams for increased operator
safety and tool protection
• Soft Start feature gradually increases speed to eliminate start up shock
• Variable Speed Dial allows operator to adjust speed based on
materials or application
SPECIFICATIONS
Bit Type SDS-MAX
Maximum Capacities:
Concrete (TCT) 1-3/4˝ (45 mm)
Concrete (Core Bit) 5˝ (125 mm)
No Load Speed 130 - 280 RPM
Blows Per Minute 1,250 - 2,750 BPM
Impact Energy 12.5 J (9.2 ft. lbs)
AMPS (120V) 13.5 A
Overall Length 18˝ (458 mm)
Net Weight 19.6 lbs (8.9 kg)
STANDARD EQUIPMENT INCLUDES:
BitGrease(194683-7),D-StyleSideHandle(135531-1),
StraightSideHandleIncl.DepthGauge(135209-6),
CleaningCloth(443122-7),DustExtractionAttachment
(196074-8),PlasticCarryingCase(196192-2)
HR4511CV
Locking Slide Switch For ChiselingApplications
(HR4510CV Only)
STANDARD EQUIPMENT INCLUDES:
BitGrease(194683-7),D-StyleSideHandle(135531-1),
StraightSideHandleIncl.DepthGauge(135209-6),
CleaningCloth(443122-7),DustExtractionAttachment
(196074-8),PlasticCarryingCase(196191-4)
HR4510CV
HR4511CV, HR4510CV 1-3/4 ˝ Rotary Hammers with Dust Extraction Attachment
Variable Speed, Constant Speed Control,
Soft Start
Locking Slide Switch
Trigger Switch
STANDARD EQUIPMENT INCLUDES:
Straight Side Handle (123138-5), D-Style Side Handle (196792-8), Cleaning Cloth (443122-7), Depth Gauge (331955-1),
Plastic Carrying Case (141977-1)
SDS-MAX Shank
Ultra-Low Vibration At Just 5.0 m/s For Maximum Operator Comfort and Safety!
Hammer & Rotation / Hammer Only
• Advanced Anti-Vibration Technology (AVTTM ) system incorporates vibration absorbing housing, active
dynamic vibration absorber and damper spring to actively counteract the vibration of the tool for greatly
reduced transmission to the operator
• Incorporates both trigger and locking switches for ease of operation in
intermittent drilling and prolonged demolition applications
• Torque limiter stops bit rotation if bit jams for increased operator safety and tool protection
• Soft start feature gradually increases speed to
eliminate start up shock
1-9/16˝ Rotary Hammer
SPECIFICATIONS
Bit Type SDS-MAX
Maximum Capacities:
Concrete (TCT) 1-9/16˝ (40 mm)
Concrete (Core Bit) 4-1/8˝ (105 mm)
No Load Speed 250 - 500 RPM
Blows Per Minute 1,450 - 2,900 BPM
Impact Energy 11.4 J (8.4 ft. lbs)
AMPS (120V) 11.0 A
Overall Length 18-11/16˝ (479 mm)
Net Weight 15.1 lbs (6.8 kg)
HR4013C
Variable Speed,
Constant Speed Control,
Soft Start
STANDARD EQUIPMENT INCLUDES:
Straight Side Handle (123138-5), D-Style Side Handle (196792-8), Cleaning Cloth (443122-7), Depth Gauge (331955-1),
Bit Grease (194683-7), Plastic Carrying Case (141976-3)
SDS-MAX Shank
Hammer & Rotation / Hammer Only
• Incorporates both trigger and locking switches for ease of operation in
intermittent drilling and prolonged demolition applications
• Constant speed control maintains constant speed under heavy load
• Torque limiter stops bit rotation if bit jams for increased operator safety and tool protection
• Soft start feature gradually increases speed to eliminate start up shock
• Variable speed dial allows operator to adjust speed based on materials or application
• Auto-shut off carbon brushes shut off motor when carbon brushes require replacement
1-9/16˝ Rotary Hammer
SPECIFICATIONS
Bit Type SDS-MAX
Maximum Capacities:
Concrete (TCT) 1-9/16˝ (40 mm)
Concrete (Core Bit) 4-1/8˝ (105 mm)
No Load Speed 250 - 500 RPM
Blows Per Minute 1,450 - 2,900 BPM
Impact Energy 11.4 J (8.4 ft. lbs)
AMPS (120V) 11.0 A
Overall Length 18-11/16˝ (479 mm)
Net Weight 13.8 lbs (6.2 kg)
HR4003C
Variable Speed,
Constant Speed Control,
Soft Start
