121 / 212
Electric
Power Tools
makita.ca119
When
QUALITY & SERVICE
Counts – Choose Makita
Cordless
Benchtop
Saws
Woodworking
Hammers
Dust
Extraction
Drills
Metalworking
Pneumatic
OPE
Manufacturing
And Assembly
SDS-PLUS Shank
Hammer & Rotation / Hammer Only / Rotation Only
• Anti-Vibration Technology (AVT
TM
) actively counteracts vibration of tool for greatly reduced transmission to operator
• Torque Limiter stops bit rotation if bit jams for increased operator safety and enhanced tool protection
• Constant Speed Control maintains constant speed under heavy load
• Soft Start feature gradually increases speed to eliminate start up shock
• Variable Speed Dial allows operator to adjust speed based on materials or application
• 24 Angle Bit Positions enable chisels to be positioned at optimum angle of operation
• One-Touch Sliding Chuck for easy bit installation and removal
STANDARD EQUIPMENT INCLUDES:
Bit Grease (194683-7), Side Handle (135197-7),
Depth Gauge(321248-4),
Plastic Carrying Case (824825-6)
HR3210C
STANDARD EQUIPMENT INCLUDES:
BitGrease(194683-7),SideHandle(135197-7),
DepthGauge(321248-4),
QuickChangeDrillChuck(194568-7),
PlasticCarryingCase(824825-6)
HR3210FCT
HR3210C, HR3210FCT
1-1/4˝ Rotary Hammers
Constant Speed Control,
Variable Speed,
Soft Start
SPECIFICATIONS
Bit Type
SDS-PLUS
Maximum Capacities:
Concrete (TCT)
1-1/4˝ (32 mm)
Concrete (Core Bit)
3-1/2˝ (90 mm)
No Load Speed
315 - 630 RPM
Blows Per Minute
1,650 - 3,300 BPM
Impact Energy
5.5 J (4.1 ft. lbs)
AMPS (120V)
8.2 A
HR3210C:
Overall Length
15-5/8˝ (398 mm)
Net Weight
11.5 lbs (5.2 kg)
HR3210FCT:
Overall Length (with SDS-PLUS Chuck) 16-3/4˝ (424 mm)
Net Weight
11.9 lbs (5.4 kg)
With
Quick Change
Drill Chuck
194568-7
STANDARD EQUIPMENT INCLUDES:
HR2631F:
Side Handle (122878-2), Depth Gauge (331886-4), Plastic Carrying Case (824913-9)
HR2631FT:
Side Handle (122878-2), Depth Gauge (331886-4), Quick Change Drill Chuck (194079-2), Plastic Carrying Case (824915-5)
SDS-PLUS Shank
Hammer & Rotation / Hammer Only / Rotation Only
• Anti-Vibration Technology
TM
(AVT
TM
) actively
counteracts vibration of tool for greatly reduced
transmission to operator
• Torque limiter stops bit rotation if bit jams for
increased operator safety and enhanced
tool protection
1˝ Rotary Hammers
SPECIFICATIONS
Bit Type
SDS-PLUS
Maximum Capacities:
Concrete
1˝ (26 mm)
Steel
1/2˝ (13 mm)
Wood
1-1/4˝ (32 mm)
No Load Speed
0 - 1,200 RPM
Blows Per Minute
0 - 4,600 BPM
Impact Energy
2.9 J (2.1 ft. lbs)
AMPS (120V)
7.0 A
HR2631F:
Overall Length
14-1/4˝ (361 mm)
Net Weight 6.4 lbs (2.9 kg)
HR2631FT:
Overall Length
(with SDS-PLUS Chuck)
15-1/8˝ (385 mm)
Net Weight 6.8 lbs (3.1 kg)
HR2631F
HR2631FT
Variable Speed
SDS-PLUS Shank
Hammer & Rotation / Hammer Only / Rotation Only
• Integrated dust extraction system with HEPA
TM
filter captures harmful silica dust at point of
origin for virtually dust-free operation and reduced harm to workers
• Ideal for use in dust sensitive environments, e.g. hospitals, healthcare facilities, offices,
facilities, institutions and more!
• HEPA
TM
filter offers 99.75% efficiency
STANDARD EQUIPMENT INCLUDES:
Side Handle (158057-6) Depth Gauge (324219-0),
Five Sealing Caps (424474-5),
Dust Collector (136018-6),
Plastic Carrying Case (821722-7)
HR2651
STANDARD EQUIPMENT INCLUDES:
SideHandle(158057-6)DepthGauge(324219-0),
FiveSealingCaps(424474-5),
DustCollector(136018-6),
PlasticCarryingCase(821721-9)
HR2661
HR2651, HR2661
1
˝
Rotary Hammers with Dust Extraction Attachment
SPECIFICATIONS
Bit Type
SDS-PLUS
Maximum Capacities:
Concrete
1˝ (26 mm)
Steel
1/2˝ (13 mm)
Wood
1-1/4˝ (32 mm)
No Load Speed
0 - 1,200 RPM
Blows Per Minute
0 - 4,600 BPM
Impact Energy
2.9 J (2.1 ft. lbs)
AMPS (120V)
7.0 A
HR2651:
Overall Length
23-3/4˝ (604 mm)
Net Weight
11.5 lbs (5.2 kg)
HR2661:
Overall Length
26-1/4˝ (666 mm)
Net Weight
9.7 lbs (4.4 kg)
Variable Speed, Reversible
STANDARD EQUIPMENT INCLUDES:
Side Handle (122878-2), Depth Gauge (331886-4), Plastic Carrying Case (824695-3)
SDS-PLUS Shank
Hammer & Rotation / Hammer Only / Rotation Only
• Anti-Vibration Technology
TM
(AVT
TM
) actively counteracts vibration of tool for greatly reduced
transmission to operator
• Torque limiter stops bit rotation if bit jams for increased operator safety and enhanced tool protection
• High durability design with zig-zag armature varnish, enhanced sealing, improved impact bolt and
impact reducing cushion ring
• Retractable sky hook allows tool to be hung on rafters, pipes or scaffolding
• Improved bit guide for increased bit stability during drilling applications
• Re-located operating mode lever for increased protection and durability
Variable Speed,
Reversible
1˝ Rotary Hammer
SPECIFICATIONS
Bit Type
SDS-PLUS
Maximum Capacities:
Concrete
1˝ (26 mm)
Steel
1/2˝ (13 mm)
Wood
1-1/4˝ (32 mm)
No Load Speed
0 - 1,100 RPM
Blows Per Minute
0 - 4,500 BPM
Impact Energy
2.9 J (2.1 ft. lbs)
AMPS (120V)
8.0 A
Overall Length 16-5/8˝ (422 mm)
Net Weight
6.8 lbs (3.1 kg)
HR2641
