123 / 212
Electric
Power Tools
121
STANDARD EQUIPMENT INCLUDES:
1/2˝ Drill Chuck (192877-8), Chuck Key (763432-9), Side Handle (122428-3), Depth Gauge (321059-7), Plastic Carrying Case (824608-4)
Makita’s Most Popular 3/4˝ Hammer Drill
Hammer & Rotation / Rotation Only
• Industrial Aluminum Gear Housing for durability
• 1/2˝ Chuck will accept 3/4˝ concrete bits with 1/2˝ reduced shank
• Depth Setting Rod for easier drilling of accurate hole depths
• 360° Swivel Side Handle
Variable 2-Speed, Reversible
3/4˝ Hammer Drill
SPECIFICATIONS
Maximum Capacities:
Concrete
3/4˝ (20 mm)
Steel
1/2˝ (13 mm)
Wood
1-1/2˝ (40 mm)
No Load Speed:
Low
0 - 900 RPM
High
0 - 2,300 RPM
Blows Per Minute:
Low
0 - 18,000 BPM
High
0 - 46,000 BPM
AMPS (120V)
6.0 A
Overall Length
13-3/4˝ (350 mm)
Net Weight
6.4 lbs (2.9 kg)
HP2010N
STANDARD EQUIPMENT INCLUDES:
1/2˝ Drill Chuck & Key Set (193067-6), Side Handle (135302-6), Depth Gauge (324219-0), Plastic Carrying Case (824650-5)
Hammer & Rotation / Rotation Only
• Improved Motor Durability with Machined Metal Gearing
• Torque Limiter stops bit rotation if bit jams for increased operator safety and enhanced tool protection
• Industrial Aluminum Gear Housing for durability
• Industrial Strength Keyed Chuck for durability
• 1/2˝ Chuck will accept 3/4˝ concrete bits
with 1/2˝ reduced shank
• 360° Side Handle
Variable 2-Speed, Reversible
3/4˝ Hammer Drill
SPECIFICATIONS
Maximum Capacities:
Concrete:
Low - 3/4˝ (20 mm)
High - 3/4˝ (20 mm)
Steel:
Low - 1/2˝ (13 mm)
High - 5/16˝ (8 mm)
Wood
Low - 1-9/16˝ (40 mm)
High - 1˝ (26 mm)
No Load Speed
Low
0 - 1,200 RPM
High
0 - 2,900 RPM
Blows Per Minute
Low
0 - 24,000 BPM
High
0 - 58,000 BPM
AMPS (120V)
6.6 A
Overall Length
14-1/4˝ (372 mm)
Net Weight
5.5 lbs (2.5 kg)
HP2050H
STANDARD EQUIPMENT INCLUDES:
Keyless Drill Chuck (196193-0), Side Handle (135302-6), Depth Gauge (324219-0), Plastic Carrying Case (824811-7)
Ideal For Small Self Anchoring Concrete Screws
Hammer & Rotation / Rotation Only
• Lock-On Button for easy comfortable operation during prolonged periods of use
• 1/2˝ Keyless Chuck will accept 5/8˝ concrete bits with 1/2˝ reduced shank
• 360° Swivel Side Handle
• Ergonomic Soft Rubber Grip design for vibration absorption and comfortable operation
Variable Speed, Reversible
5/8˝ Hammer Drill
SPECIFICATIONS
Maximum Capacities:
Concrete
5/8˝ (16 mm)
Steel
1/2˝ (13 mm)
Wood
1-3/16˝ (30 mm)
No Load Speed
0 - 2,800 RPM
Impacts Per Minute
0 - 44,800 IPM
AMPS (120V)
6.0 A
Overall Length
11-7/8˝ (303 mm)
Net Weight
4.4 lbs (2.0 kg)
HP1641K
STANDARD EQUIPMENT INCLUDES:
Keyless Drill Chuck (196193-0), Side Handle (153503-4), Plastic Carrying Case (824811-7)
Ideal For Small Self Anchoring Concrete Screws
Hammer & Rotation / Rotation Only
• Industrial Aluminum Gear Housing for durability and long tool life
• Lock-On Button for easy comfortable operation during prolonged periods of use
• 1/2˝ Keyless Chuck will accept 5/8˝ concrete bits with 1/2˝ reduced shank
• 360° Swivel Side Handle
• Ergonomic Soft Rubber Grip design for vibration absorption and comfortable operation
Variable Speed, Reversible
5/8˝ Hammer Drill
SPECIFICATIONS
Maximum Capacities:
Concrete
5/8˝ (16 mm)
Steel
1/2˝ (13 mm)
Wood
1-3/16˝ (30 mm)
No Load Speed
0 - 3,200 RPM
Impacts Per Minute
0 - 48,000 IPM
AMPS (120V)
6.2 A
Overall Length
11-5/8˝ (296 mm)
Net Weight
4.4 lbs (2.0 kg)
HP1631K
SPECIFICATIONS
Wheel Diameter
5˝ (125 mm)
Wheel Type
Offset Diamond
Hole Diameter
7/8˝ (22.3 mm)
PC5010C:
No Load Speed 4,000 - 9,000 RPM
AMPS (120V)
12.0 A
Cord Length
8.2´ (2.5 m)
Overall Length 17-1/8˝ (437 mm)
Net Weight
7.7 lbs (3.5 kg)
PC5000C:
No Load Speed
10,000 RPM
AMPS (120V)
10.0 A
Cord Length
16.4 ft. (5.0 m)
Overall Length 17-1/8˝ (437 mm)
Net Weight
8.8 lbs (4.0 kg)
PC5001C:
No Load Speed
10,000 RPM
AMPS (120V)
10.0 A
Cord Length
16.4 ft. (5.0 m)
Overall Length 18-13/16˝ (479 mm)
Net Weight
11.2 lbs (5.1 kg)
PC5010C, PC5000C, PC5001C
5˝ Concrete Planers
STANDARD EQUIPMENT
INCLUDES:
Loop Handle (458690-7),
Lock Nut Wrench 28 (782425-7),
Steel Carrying Case (140B63-7)
PC5010C
• SJS II (Super Joint System II) reduces vibration
and prevents kickback during wheel lock up for
optimal tool and operator protection
(PC5010C Only)
• Variable speed dial enables operator to adjust
wheel speed based on materials or application
(PC5010C Only)
• Auxiliary Planing Base and Front Roller enables
planing to a consistent depth (PC5001C Only)
• Electronic Speed Control maintains constant
speed under heavy load
• Soft Start feature gradually increases speed to
eliminate start up shock
• Electronic Current Limiter eliminates motor
burnout due to current overload
• Anti-Restart feature prevents tool from operating
if it is plugged in when locked in the on position
• LED Light indicates active power supply and
activation of Anti-Restart feature
• Easy to Operate Larger Trigger Switch with
Lock-On feature
• Removable Front Dust Cap enables operator to
plane flush to walls and corners
5" DIAMOND CUP WHEELS
Diameter Arbour Range
Rim Type
Segments Finish Type Max. RPM For Models Part No.
5"
7/8"
Standard
Segmented
11
Fast / Rough
12,250 RPM PC5010C
PC5000C
PC5001C
D-41458
Continuous
-
Fine / Finish
D-41464
Premium
Double Row Segmented
11
Fast / Rough
12,200 RPM
A-95009
Continuous
-
Fine / Finish
A-94998
Cordless
Benchtop
Saws
Woodworking
Hammers
Dust
Extraction
Drills
Metalworking
Pneumatic
OPE
Manufacturing
And Assembly
STANDARD EQUIPMENT
INCLUDES:
D-Style Front Handle (273529-1),
5˝ Offset Finish Diamond Wheel
(A-94998), Dust BagAssembly
(122853-8), Wrench Holder
(410047-0), Hex Wrench 5 (783203-8),
Lock Nut Wrench 28 (782425-7),
Steel Carrying Case (140073-2)
PC5001C
STANDARD EQUIPMENT
INCLUDES:
Loop Handle (416256-9),
5˝ Offset Coarse Diamond Wheel
(A-95009), Dust BagAssembly
(122853-8), Wrench Holder
(410047-0), Hex Wrench 5 (783203-8),
Lock Nut Wrench 28 (782425-7),
Steel Carrying Case (140073-2)
PC5000C
Thumb Switch
with Lock-On (AC)
