STANDARD EQUIPMENT INCLUDES:

PinEnd15TPIScrollSawBlade(351011-000),HexWrenchM3(040005-003),

HexWrenchM4(040006-001),BladeChangeRod(040026-001)

Accepts Pin End And Plain Type Scroll Saw Blades

• Bevel Cuts up to 45° Left and 15° Right

• Blade Tension Lever enables quick adjustment of blade tension

• Cast Iron Base provides stability and enables vibration-free cutting

SPECIFICATIONS

Blade Type

Plain or Pin End

Blade Length

5˝ (127 mm)

Maximum Capacities:

Length Of Stroke

7/8˝ (22.2 mm)

Throat

16˝ (406.4 mm)

Thickness Of Cut

2˝ (50.8 mm)

Strokes Per Minute

400 - 1,600 SPM

AMPS (120V)

1.2 A

Table Size

14-3/4˝ x 9-3/8˝ (365 mm x 238 mm)

Net Weight

31.1 lbs (14.1 kg)

SJ401

Scroll Saw

Variable

Speed

STANDARD EQUIPMENT INCLUDES:

4˝ CTCutter Blade 6T(A-95118),Angle Guide (123148-2), Dust Bag (123150-5),

Lock Nut Wrench 20 (782401-1), Set Plate (415579-2), Plastic Carrying Case (821509-7)

Lightweight And Compact Design With Enhanced

Ergonomics For Maximum Maneuverability

• Depth Adjustment Knob enables quick adjustment

for #0, #10 and #20 biscuits

• Rack-and-Pinion Angle Guide enables precise

adjustment of fence

• Cast Aluminum Adjustable Fence with positive

stops at 0°, 45° and 90°

SPECIFICATIONS

Blade Diameter

4˝ (100 mm)

Maximum Cutting Depth 3/4˝ (20 mm)

No Load Speed

11,000 RPM

AMPS (120V)

5.6 A

Overall Length

11-7/8˝ (302 mm)

Net Weight

5.6 lbs (2.5 kg)

PJ7000

4˝ Plate Joiner

PLATE JOINER BISCUITS

Size

Material

Dimensions

For

Model

100 / Pk

Part No.

Biscuit

Compressed

Beechwood

5/8" x 1-7/8"

3901

PJ7000

DPJ180

441001A

#10

Biscuit

3/4" x 2-1/8"

441002A

#20

Biscuit

15/16" x 2-1/4"

441003A

WHEEL SANDER ABRASIVE WHEELS

Description

Grit

Application For Model Part No.

Slit Paper

Wheel

40G

Sanding

9741

794380-1

Wire Brush

Wheel

Metal Finishing

794382-7

Cotton Buff

Wheel

Polishing

794381-9

Nylon Brush

Wheel

80G Coarse Sanding

794384-3

100G Medium Sanding

794379-6

240G Fine Sanding

794383-5

Unique Design - Fast, Easy And Controlled Operation

• Fast and efficient paint and rust removal

• Well balanced design with a low center of

gravity and large front

loop handle for

easy handling

SPECIFICATIONS

Wheel Size

3-15/16˝ x 4-23/32˝ (100 mm x 120 mm)

No Load Speed

3,500 RPM

AMPS (120V)

7.8 A

Overall Length

12-1/4˝ (310 mm)

Net Weight

9.3 lbs (4.2 kg)

4-3/4˝ Wheel Sander

9741

STANDARD EQUIPMENT INCLUDES:

Joint (P-80014),Two Hex Wrenches 6 (783204-6), Nylon Brush Wheel 120-100 (794379-6)

Perfect For Timber Framing And Log Home Building

• Cuts lap joints up to 5-1/8˝

• Notches or cuts holes in thick wood stock quickly

cleanly and accurately

• Quick horizontal chain lever for widening holes

SPECIFICATIONS

Capacities:

Max. Hole Width:

(Longitudinal)

5-1/8˝ (130 mm)

Max. Hole Width:

(Transverse)

1-1/4˝ (31.5 mm)

Max. Hole Depth

6-1/8˝ (155 mm)

No Load Speed

3,200 RPM

AMPS (120V)

10.5 A

Dimensions 20-1/8˝ x 11-3/4˝ x 20-1/4˝

(512 mm x 298 mm x 513 mm)

Net Weight

38.1 lbs (17.3 kg)

Chain Mortiser

STANDARD EQUIPMENT INCLUDES:

5/8˝ Cutting Chain (A-16570), Chain BarAssy (133571-3),

Wrench 13-17 (781204-0), Oil Supply (182229-1)

7104L

CHAIN MORTISER ACCESSORIES

Part No.

Description

Dimensions For Model

122235-4

Chain Bar for 30 mm Gauge Chain

7104L

133571-3 Chain Bar Assembly for All Other Gauge Chain

123028-2

Sharpening Holder Assembly

221502-5

Chain Sprocket

1-3/16" / 30 mm

A-16564

Cutter Chain

9/16" / 15 mm

A-16570

5/8" / 16.5 mm

A-16586

11/16" / 18 mm

A-16592

51/64" / 21 mm

A-16601

15/16" / 24 mm

A-16617

1-3/16" / 30 mm
