General Catalogue

HAMMERS

120

STANDARD EQUIPMENT INCLUDES:

Dust Bag (122708-7), Dust Cap (421727-3), Side Handle (135302-6), Plastic Carrying Case (824729-2) (Shown with Optional Bit)

SDS-Plus Shank, Built-In Dust Collection System

Hammer & Rotation / Hammer Only / Rotation Only

• Dust Collection System especially suited for operation in Hospitals, Schools and other job sites

where dust collection is mandatory

• 40 Angle Bit Positions enable chisels to be positioned at optimum angle of operation

• One-Touch Sliding Chuck for easy bit installation and removal

• Ergonomic Soft Rubber Grip for vibration absorption and comfortable operation

Variable Speed, Reversible,

With Dust Collector

1˝ Rotary Hammer

SPECIFICATIONS

Bit Type

SDS-PLUS

Maximum Capacities:

Concrete

1˝ (25 mm)

Steel

1/2˝ (13 mm)

Wood

1-1/4˝ (32 mm)

No Load Speed

0 - 1,000 RPM

Blows Per Minute

0 - 4,500 BPM

Impact Energy

2.2 J (1.6 ft. lbs)

AMPS (120V)

6.7 A

Overall Length

16˝ (407 mm)

Net Weight

7.1 lbs (3.2 kg)

HR2432

STANDARD EQUIPMENT INCLUDES:

NozzleAssembly (123245-4), Dust BagAssembly (123241-2)

• Double sided impeller and enlarged blower outlet provides increased air volume for maximum

performance and efficiency

• Self standing design allows tool to stand upright for use in stationary applications

• Top and rear handle design enables comfortable positioning for optimal jobsite maneuverability

• Converts quickly and easily between blower and vacuum modes

• Variable speed trigger and dial enables operator to adjust blower or suction speed based

on the material or application

• Lock-on button for operator convenience during periods of prolonged use

• Ergonomic soft rubber grip design

for comfortable operation

Anti-Static Design

Blower / Vacuum

SPECIFICATIONS

Max. Air Volume 145 CFM (4.1 m

/min)

Max. Air Velocity 203 MPH (91 m/sec)

No Load Speed

0 - 16,000 RPM

AMPS (120V)

6.8 A

Overall Length

18 -7/8˝ (479 mm)

Net Weight

4.3 lbs (2.0 kg)

UB1103

Cordless

Benchtop

Saws

Woodworking

Hammers

Dust

Extraction

Drills

Metalworking

Pneumatic

OPE

Manufacturing

And Assembly

Optional Long Nozzle with

Curved End available

(Part No. 196729-5)

STANDARD EQUIPMENT INCLUDES:

Side Handle (158057-6), Depth Gauge (415486-9), Plastic Carrying Case (824650-5)

SDS-PLUS Shank, Up To 46% REDUCED VIBRATION!

Hammer & Rotation / Rotation Only

• Anti-Vibration Technology (AVT

) system incorporates an active dynamic vibration absorbing

counterbalance spring and a vibration absorbing handle to actively counteract the vibration of the tool

for greatly reduced transmission to the operator

• Torque limiter stops bit rotation if bit jams for increased operator safety and enhanced tool protection

• Variable speed trigger allows operator to adjust speed based on materials or application

• Reverse rotation system using brush holder unit provides the same amount of power in forward and

reverse and extends life of carbon brushes

• 2 operating modes: Rotation / Rotation + Hammer

• One-touch SDS-PLUS sliding chuck for easy bit

installation and removal

Variable Speed, Reversible

11/16˝ Rotary Hammer

SPECIFICATIONS

Bit Type

SDS-PLUS

Maximum Capacities:

Concrete

11/16˝ (18 mm)

Steel

1/2˝ (13 mm)

Wood

15/16˝ (24 mm)

No Load Speed

0 – 2,100 RPM

Blows Per Minute

0 – 4,800 BPM

Impact Energy

1.4 J (1.0 ft. lbs)

AMPS (120V)

4.1 A

Overall Length

11-1/4˝ (285 mm)

Net Weight

5.4 lbs (2.5 kg)

HR1841F

STANDARD EQUIPMENT INCLUDES:

Side Handle (158057-6), Depth Gauge (324219-0), Plastic Carrying Case (824799-1)

SDS-PLUS Shank

Hammer & Rotation / Hammer Only / Rotation Only

• Torque Limiter stops bit rotation if bit jams for increased operator safety and enhanced tool protection

• High Durability design with Zig-Zag Armature Varnish, Enhanced Sealing, Improved Impact Bolt and

Impact Reducing Cushion Ring

• Reverse Rotation System using Brush Holder Unit provides the same amount of power in forward and

reverse and extends life of carbon brushes

• Rubber Housing Bumper protects mode selector switch and gear housing from damage

• 40 Angle Bit Positions enable chisels to be positioned at optimum angle of operation

• One-Touch Sliding Chuck for easy bit installation and removal

• LED Light illuminates drilling position

Variable Speed,

Reversible

15/16˝ Rotary Hammer

SPECIFICATIONS

Bit Type

SDS-PLUS

Maximum Capacities:

Concrete

15/16˝ (24 mm)

Steel

1/2˝ (13 mm)

Wood

1-1/4˝ (32 mm)

No Load Speed

0 – 1,100 RPM

Blows Per Minute 0 – 4,500 BPM

Impact Energy 2.7 J (1.99 ft. lbs)

AMPS (120V)

6.7 A

Overall Length 14-1/2˝ (370 mm)

Net Weight

6.4 lbs (2.9 kg)

HR2470F

STANDARD EQUIPMENT INCLUDES:

Side Handle (158057-6), Depth Gauge (415486-9), Plastic Carrying Case (821706-5)

SDS-PLUS Shank

Hammer & Rotation / Rotation Only

• Torque limiter stops bit rotation if bit jams for increased operator safety and enhanced tool protection

• Variable speed trigger allows operator to adjust speed based on materials or application

• Reverse rotation system using brush holder unit provides the same amount of power in forward and

reverse and extends life of carbon brushes

• 2 operating modes: Rotation / Rotation + Hammer

• One-touch SDS-PLUS sliding chuck for easy bit installation and removal

• Ergonomic soft rubber grip for vibration absorption and

comfortable operation

Variable Speed, Reversible

11/16˝ Rotary Hammer

SPECIFICATIONS

Bit Type

SDS-PLUS

Maximum Capacities:

Concrete

11/16˝ (18 mm)

Steel

1/2˝ (13 mm)

Wood

15/16˝ (24 mm)

No Load Speed

0 – 2,100 RPM

Blows Per Minute

0 – 4,800 BPM

Impact Energy

1.4 J (1.0 ft. lbs)

AMPS (120V)

4.1 A

Overall Length

11-1/4˝ (285 mm)

Net Weight

5.3 lbs (2.4 kg)

HR1840

POWER

Makita’s

Efficient

Hammering

Competitor’s

Inefficient

Hammering

Synchronized RPM and BPM creates

up to 50% more efficient drilling

*Only For Makita Electric Rotary Hammers featuring

ANTI-VIBRATION TECHNOLOGY
