STANDARD EQUIPMENT INCLUDES:
Plastic Carrying Case (PR00000060)
Ideal For Welding and Forming Plastics, Heat Shrink Tubing, Soldering
Copper Pipe, Bending Plastic Pipe, Thawing Metal Pipes, Activating/
De-Activating Adhesives and Putties, Stripping Paint And More!
• 2-stage air volume and temperature control provides versatility in a wide range of applications
• Rear housing design with integrated rubber bumpers allows tool to be positioned upright for use as a
static heating source during two-handed operations
• Ergonomic soft rubber grip design for comfortable operation
Heat Gun
SPECIFICATIONS
Air Temperature:
Swtich 1
400°C (752°F)
Switch 2
550°C (1022°F)
Air Volume:
Switch 1
7.0 CFM (200 l/min)
Switch 2
14.0 CFM (400 l/min)
AMPS (120V)
13.0 A
Overall Length
9-1/8˝ (233 mm)
Net Weight
1.2 lbs (0.56 kg)
HG5030K
2-Stage Air Volume /
Temperature Control
Cordless
Benchtop
Saws
Woodworking
Hammers
Dust
Extraction
Drills
Metalworking
Pneumatic
OPE
Manufacturing
And Assembly
STANDARD EQUIPMENT INCLUDES:
Plastic Carrying Case (PR00000061)
Ideal For Welding and Forming Plastics, Heat Shrink Tubing, Soldering
Copper Pipe, Bending Plastic Pipe, Thawing Metal Pipes, Activating/
De-Activating Adhesives and Putties, Stripping Paint And More!
• Variable temperature dial provides stepless electronic temperature adjustment to achieve precise
heating requirements
• 2-stage air volume control provides versatility in a wide range of applications
• Ergonomic soft rubber grip design for comfortable operation
Heat Gun
SPECIFICATIONS
Air Temperature:
Swtich 1 50°C - 350°C (122° - 662°F)
Switch 2 80°C - 550°C (176° - 1,022°F)
Air Volume:
Switch 1
7.0 CFM (200 l/min)
Switch 2
14.0 CFM (400 l/min)
AMPS (120V)
13.0 A
Overall Length
10-1/8˝ (257 mm)
Net Weight
1.5 lbs (0.67 kg)
HG6031VK
2-Stage Air Volume Control,
Variable Temperature Dial
HEAT GUN ACCESSORIES
Item
Application
Dimensions
HG1100
HG5012 HG551V HG5030K HG6031VK
Wide Angle Slit Nozzle
Directs hot air for lap welding PVC sheet materials, single ply
roofing, industrial and marine fabrics and more
2" width
-
P-71423
PR00000029
Reflector Nozzles
Directs flow of hot air around objects, including pipes,
tubing and wiring when activating solder connectors, heat
shrinking tubing, soldering copper or plastic pipes,
thawing pipes and bending plastic pipes
3/8" width
110746-A
-
1/2" width
-
-
PR00000033
21/32" width
-
P-71495
1-1/2" width 110705-A/BULK
-
PR00000030
1-9/16" width
-
P-71445
-
3" width
110730-A
-
-
Glass / Widow Nozzle
Protects adjacent surfaces from over heating by deflecting
hot air away from delicate materials. Ideal for use with glass
2" width
-
P-71417
PR00000028
Reduction Nozzle
Directs flow of hot air for use during soldering, welding
or general heating applications
3/8" diameter
110706-A
-
-
9/16" diameter
110707-A/BULK
-
-
25/32" diameter
110708-A
P-71439
PR00000031
Surface Nozzle
Ideal for spreading hot air over large surfaces when welding
flooring, drying or stripping paint, activating or de-activating
adhesives, heat shrinking packaging and more
3" width
110702-A
-
-
Welding Nozzles
Provides concentrated hot air flow when welding plastics
1/4" width
110720-A
(use with 110706-A)
-
-
1/4" diameter
-
P-71451
-
5/16" width
-
-
PR00000034
1" (speed style)
-
P-71473
PR00000039
(use with PR00000034)
1" (overlap style)
-
P-71489
PR00000032
Plastic Welding Rods
Welding Polyvinyl Chloride (PVC) materials
(ensure welding rod matches materials being welded)
1/8" diameter x
9" length (16 / pk)
110731-A
Welding Acrylonitrile Butadiene Styrene (ABS) materials
(ensure welding rod matches materials being welded)
110742-A
1/8" diameter x
9" length (10 / pk)
PR00000036
Welding High-density Polyethylene (HDPE) materials
(ensure welding rod matches materials being welded)
R00000037
Welding Polypropylene (PP) materials
(ensure welding rod matches materials being welded)
PR00000038
Scraper
Hand held scraper for use when removing adhesives,
decals, paint, putty, silicone and more
2" width
PR00000040
3 Pc. Specialty Scraper Set
-
PR00000041
Specialty Scraper
-
PR00000042
Pressure Roller
For use during lap welding, seam sealing or
edge veneer applications
1-1/4" width
PR00000035
