General Catalogue

OUTDOOR

Power Equipment

makita.ca

199

Cordless

Benchtop

Saws

Woodworking

Hammers

Dust

Extraction

Drills

Metalworking

Pneumatic

OPE

Manufacturing

And Assembly

When

QUALITY & SERVICE

Counts – Choose Makita

STANDARD EQUIPMENT INCLUDES:

Tool Only. Batteries and Charger Sold Separately.

Shear BladeAssembly Set (196689-1), Blade Cover (450490-1)

25-1/2˝ / 18Vx2 LXT Cordless Hedge Trimmer

SPECIFICATIONS

Battery Capacities

Two 18V Li-Ion

Strokes Per Minute (min-1)

1,000 - 1,800 SPM

Cutting Length

25-1/2˝ (650 mm)

Maximum Cutting Thickness

11/16˝ (18 mm)

Overall Length

48-1/2˝ (123 cm)

Net Weight

8.9 lbs (4.0 kg)

DUH651Z

STANDARD EQUIPMENT INCLUDES:

Two Shear Blades, Blade Cover (452327-8), End Cover Set (196969-5),

Box Driver 10-16 (782233-6), Hex Wrench 4 (783223-2), Starter Rope (444028-2), Spark Plug (0650109950)

5 Position Adjustable Rear Handle for

Vertical or Angle Trimming

• 23-1/8" Cutting Length with 3 Edge Tooth Design

and High Anti-Abrasion Coated Surface for

Stain Free Long Lasting Operation

• Double Sided Stainless Steel Blades for

Extended Life, Clean Trimming and Cutting

on Both Sides of Blade

• Extended 50 Hour Long Life Gear Case

Lubrication System offers Minimal Service

Maintenance by circulating grease in the

gear housing.

• 5 Position Adjustable Rear Handle for

Vertical or Angle Trimming

• Anti-vibration design for Less

Operator Fatigue

• Forward Facing Exhaust

redirects away from

the operator

23-1/8˝ / 22.2cc 2-Stroke Hedge Trimmer

SPECIFICATIONS

Displacement

22.2cc

Maximum Engine Power 0.68 kW / 0.91 HP

Cutting Length

23-1/8˝ (588 mm)

Carburetor

Diaphragm type

Fuel / Oil Mixture

50:1

Fuel Tank Capacity

400 ml

Overall Length

44˝ (111 cm)

Net Weight

11.0 lbs (5.0 kg)

EH6000W

STANDARD EQUIPMENT INCLUDES:

Two Shear Blades, Blade Cover (454279-9), End Cover Set (196969-5),

Box Driver 10-16 (782233-6), Hex Wrench 4 (783223-2), Starter Rope (444028-2), Spark Plug (0650109950)

5 Position Adjustable Rear Handle for

Vertical or Angle Trimming

• 19" Cutting Length with 3 Edge Tooth Design

and High Anti-Abrasion Coated Surface for

Stain Free Long Lasting Operation

• Double Sided Stainless Steel Blades for

Extended Life, Clean Trimming and Cutting

on Both Sides of Blade

• Extended 50 Hour Long Life Gear Case

Lubrication System offers Minimal Service

Maintenance by circulating grease in the

gear housing.

• 5 Position Adjustable Rear Handle for

Vertical or Angle Trimming

• Anti-vibration design for Less

Operator Fatigue

• Forward Facing Exhaust

redirects away from

the operator

19˝ / 22.2cc 2-Stroke Hedge Trimmer

SPECIFICATIONS

Displacement

22.2cc

Maximum Engine Power 0.68 kW / 0.91 HP

Cutting Length

19˝ (483 mm)

Carburetor

Diaphragm type

Fuel / Oil Mixture

50:1

Fuel Tank Capacity

400 ml

Overall Length

40˝ (101 cm)

Net Weight

10.5 lbs (4.8 kg)

EH5000W

STANDARD EQUIPMENT INCLUDES:

Two Shear Blades, Blade Cover (454277-3), End Cover Set (196969-5),

Box Driver 10-16 (782233-6), Hex Wrench 4 (783223-2), Starter Rope (444028-2), Spark Plug (0650109950)

5 Position Adjustable Rear Handle for

Vertical or Angle Trimming

• 28-3/4" Cutting Length with 3 Edge Tooth Design

and High Anti-Abrasion Coated Surface for

Stain Free Long Lasting Operation

• Double Sided Stainless Steel Blades for

Extended Life, Clean Trimming and Cutting

on Both Sides of Blade

• Extended 50 Hour Long Life Gear Case

Lubrication System offers Minimal Service

Maintenance by circulating grease in the

gear housing.

• 5 Position Adjustable Rear Handle for

Vertical or Angle Trimming

• Anti-vibration design for Less

Operator Fatigue

• Forward Facing Exhaust

redirects away from

the operator

28-3/4˝ / 22.2cc 2-Stroke Hedge Trimmer

SPECIFICATIONS

Displacement

22.2cc

Maximum Engine Power 0.68 kW / 0.91 HP

Cutting Length

28-3/4˝ (728 mm)

Carburetor

Diaphragm type

Fuel / Oil Mixture

50:1

Fuel Tank Capacity

400 ml

Overall Length

49-1/2˝ (125 cm)

Net Weight

11.4 lbs (5.2 kg)

EH7500W

Reduced Noise And Emissions Versus

Competitive Gas Models

• Accepts two 18V Li-Ion batteries without a battery converter for use with

existing 18V Li-Ion battery platform

• eXtreme Protection Technology (XPT) offers maximum protection against dust, debris and liquids

for optimal performance in extreme conditions

• Electric brake stops blade 3-5 seconds after trigger is

released for increased operator safety

• Battery capacity warning light indicates

approximate remaining battery power

• 5 position rotating rear handle with

positive stops at 0

, 45

and 90

enables optimal positioning when

cutting vertical or angled hedges

Dual Blade Action

DUH523SF

STANDARD EQUIPMENT INCLUDES:

DUH523SF:

18V (3.0Ah) Li-Ion Battery

BL1830B (194205-3), Standard Charger (DC18SD), Shear Blade Complete Set (195846-8),

Blade Cover (453723-3)

DUH523Z:

Tool Only. Batteries and Charger Sold Separately.

Blade Cover (453723-3), Shear Blade Complete Set (195846-8)

Designed for Maximum Versatility and Ease of Operation

• Battery Protection System provides Over-Discharge, Temperature and Current Protection

for enhanced performance, battery cycle life and overall battery life

• Anti-Vibration Structure features five cushions linking handle and motor sections for significantly

reduced vibration transmission to operator

• Non-Electrolyzed Nickel Plated Blades reduce

staining and rusting

• Tool-less Blade Changing System

enables simple and easy blade changes

• Ergonomic Soft Rubber Grip design for

vibration absorption and comfortable

operation

22˝ / 18V LXT Cordless Hedge Trimmer

SPECIFICATIONS

Battery Capacities

18V Li-Ion

Strokes Per Minute (min-1)

1,350 SPM

Cutting Length

22˝ (560 mm)

Maximum Cutting Thickness

15/32˝ (12 mm)

Overall Length

38˝ (96 cm)

Net Weight

6.0 lbs (2.7 kg)

Dual Blade Action

DUH523Z

STANDARD EQUIPMENT INCLUDES:

Cord Holder Complete Set (194677-2), Hook Complete Set (158024-1), Blade Cover (450490-1), Shear BladeAssembly Set (194669-1)

25-1/2˝ Electric Hedge Trimmer

SPECIFICATIONS

Cutting Length

25-1/2˝ (650 mm)

Strokes Per Minute

1,600 SPM

AMPS(120V)

4.8 A

Overall Length

40-1/2˝ (103 cm)

Net Weight

3.8 lbs (8.4 kg)

UH6570

Ergonomic Soft Rubber Grip For Vibration Absorption

And Comfortable Operation

Three switches are installed in handle, front grip and sub grip

• 2-hand operation switch–motor will run only when grips

are held with both hands

• Guard is provided at the tip of blades to

prevent kick-back

• Blades are coated particularly to improve durability

• Built in clutch for safety

• Easy blade replacement

• Powerful 550W Motor

• Protection of extension cord from breakage

Electric Brake
