MANUFACTURING & ASSEMBLY
204
Cordless
Benchtop
Saws
Woodworking
Hammers
Dust
Extraction
Drills
Metalworking
Pneumatic
OPE
Manufacturing And Assembly
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately. TorqueAdjustmentTool (765027-4)
Precise Torque Control Consistently Delivers Repeatability Of +/- 10%
• Built in LED to illuminate tight spaces
• Extremely compact and lightweight for outstanding ergonomics
• On board LED and audible signal informs user
of successful rundown
Reversible
1/4˝ Precise Torque Screwdriver
SPECIFICATIONS
Battery Capacities 14.4V Li-ion
Capacity (Driving Shank)
Hex 1/4˝
No Load Speed 950 RPM
Fastening Torque
1 - 4 Nm. (8.9 - 35 in./lbs)
Width 2-15/16˝ (74 mm)
Height (With Battery) 9-7/8˝ (250 mm)
Length (With Battery) 7-7/8˝ (200 mm)
Net Weight 2.4 lbs (1.1 kg)
DFT044FZ
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately. USB Cable (661432-2),TorqueAdjustmentTool (765027-4), Lock Nut (457530-6)
Programmable Speed Control For Maximum Fastening Precision And Accuracy
• Precise torque control consistently delivers repeatability of +/- 10%
• Programmable speed control enables user to control speed of hard or soft joints or production
time using USB / PC connection
• Brushless DC motor with high power to weight and size ratio
• On board LED and audible signal informs user of successful run down
• Battery capacity warning light indicates ideal time
to recharge battery
Programmable
Speed Control,
Reversible
1/4˝ Precise Torque Screwdrivers
SPECIFICATIONS
Battery Capacities 14.4V Li-ion
Capacity (Driving Shank)
Hex 1/4˝
Width 2-13/16˝ (72 mm)
Height (With Battery) 9-3/4˝ (249 mm)
Length (With Battery) 6-1/4˝ (159 mm)
Net Weight 1.8 lbs (0.8 kg)
No Load Speed:
DFT023FMZ 400 - 1,300 RPM
DFT045FMZ 150 - 900 RPM
Fastening Torque:
DFT023FMZ 0.5 - 2 Nm. (4 - 18 in./lbs)
DFT045FMZ 1 - 4 Nm. (9 - 35 in./lbs)
DFT045FMZ DFT023FMZ
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately. USB Cable (661432-2),TorqueAdjustmentTool (765027-4), Ring 25 (424977-9)
Programmable Speed Control For Maximum Fastening Precision And Accuracy
• Precise torque control consistently delivers repeatability of +/- 10%
• Programmable speed control enables user to control speed of hard or soft joints or production
time using USB / PC connection
• Brushless DC motor with high power to weight and size ratio
• On board LED and audible signal informs user of successful run down
• Battery capacity warning light indicates ideal time
to recharge battery
Programmable
Speed Control,
Reversible
1/4˝ Precise Torque Screwdrivers
SPECIFICATIONS
Battery Capacities 14.4V Li-ion
Capacity (Driving Shank)
Hex 1/4˝
Width 2-13/16˝ (72 mm)
Height (With Battery) 10˝ (254 mm)
Length (With Battery) 7-1/2˝ (190 mm)
Net Weight 2.3 lbs (1.0 kg)
No Load Speed:
DFT085FMZ 150 - 900 RPM
DFT127FMZ 100 - 600 RPM
Fastening Torque:
DFT085FMZ 3 - 8 Nm. (27 - 71 in./lbs)
DFT127FMZ 5 - 12 Nm. (44 - 106 in./lbs)
DFT127FMZ DFT085FMZ
For Battery and Charger Compatibility
please refer to pages 56 – 58
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately. TorqueAdjustmentTool (765027-4)
Bluetooth® Enabled For Wireless Data Capture Of Fastening Torque And Angle
• Precise torque control consistently delivers repeatability of +/- 10%
• Built in LED to illuminate tight spaces
• Using optional receiver, can record torque and angle data
• Highly accurate spring clutch
• Uses LXT technology for long battery life
• Design and built to withstand high volume assembly processes
Reversible
1/4˝ Precise Torque Screwdriver
SPECIFICATIONS
Battery Capacities 14.4V Li-ion
Capacity (Driving Shank)
Hex 1/4˝
No Load Speed 860 RPM
Fastening Torque
4 - 8 Nm. (35 - 71 in./lbs)
Width 2-13/16˝ (72 mm)
Height (With Battery) 10-1/2˝ (266 mm)
Length (With Battery) 7-1/2˝ (191 mm)
Net Weight 2.2 lbs (1.0 kg)
DFT082RZ
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately. TorqueAdjustmentTool (765027-4)
Bluetooth® Enabled For Wireless Data Capture Of Fastening Torque And Angle
• Precise torque control consistently delivers repeatability of +/- 10%
• Built in LED to illuminate tight spaces
• Using optional receiver, can record torque and angle data
• Highly accurate spring clutch
• Uses LXT technology for long battery life
• Design and built to withstand high volume assembly processes
Reversible
1/4˝ Precise Torque Screwdriver
SPECIFICATIONS
Battery Capacities 14.4V Li-ion
Capacity (Driving Shank)
Hex 1/4˝
No Load Speed 600 RPM
Fastening Torque
6 - 12 Nm. (53 - 106 in./lbs)
Width 2-13/16˝ (72 mm)
Height (With Battery) 10-1/2˝ (266 mm)
Length (With Battery) 7-1/2˝ (191 mm)
Net Weight 2.2 lbs (1.0 kg)
DFT124RZ
BFL201RZ
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately. TorqueAdjustmentTool (765027-4)
Bluetooth® Enabled For Wireless Data Capture Of Fastening Torque And Angle
• Precise torque control consistently delivers
repeatability of +/- 10%
• Built in LED to illuminate tight spaces
• Using optional receiver, can record torque
and angle data
• Highly accurate spring clutch
• Uses LXT technology for long battery life
• Design and built to
withstand high
volume assembly
processes
3/8˝ Torque Tracer Precise Torque Angle Wrenches
SPECIFICATIONS
Battery Capacities 14.4V Li-ion
Capacity (Driving Shank)
Square 3/8˝
Width 2-13/16˝ (72 mm)
Height (With Battery) 3-7/8˝ (98 mm)
Length (With Battery) 16-7/8˝ (429 mm)
Net Weight 2.6 lbs (1.2 kg)
No Load Speed:
BFL201RZ 360 RPM
BFL301RZ 260 RPM
Fastening Torque:
BFL201RZ 10 - 20 Nm. (88.5 – 177 in./lbs)
BFL301RZ 16 - 30 Nm. (142 – 266 in./lbs)
BFL301RZ
Reversible
