General Catalogue

makita.ca

194

Cordless

Benchtop

Saws

Woodworking

Hammers

Dust

Extraction

Drills

Metalworking

Pneumatic

OPE

Manufacturing

And Assembly

DUR364LZ

STANDARD EQUIPMENT INCLUDES:

Tool Only. Batteries and Charger Sold Separately.

Bump and FeedTrimmer HeadAssembly (197297-1), Safety Goggles (195246-2), Hex Wrench 5 (783217-7), Hex Wrench 4 (783202-0),

Accessory Bag (831304-7), Protector (455622-5)

Powerful Trimming For Where Low Noise Is A Concern

• Brushless motor is located on the trimmer head end to provide ultimate torque

for trimming

• XPT (eXtreme Protection Technology) is provided to protect the unit under wet and

dirty conditions for the longest life

• Electronic current limiter for overload protection

• Dual Charge Level Indicators for batteries state of charge at a glance

• Soft start feature for added motor protection

• Brushless motor with electronic 2 speed selection

• Reverse switch for easy removal of stuck grass clippings

in the trimmer head

13-3/4˝ / 18Vx2 LXT Cordless Line Trimmer

SPECIFICATIONS

Battery Capacities

Two 18V Li-Ion

Cutting Width

13-3/4˝ (350 mm)

No Load Speed:

Low

5,000 RPM

High

6,500 RPM

Overall Length

69˝ (175 cm)

Net Weight

7.3 lbs (3.3 kg)

Makita offers a wide variety of

ACCESSORIES!

STANDARD EQUIPMENT INCLUDES:

Trimmer Head (DA00000655), Protective Guard (DA00000630), Socket Wrench M5 (DA00000457),Tool Kit (DA00000458),

Spark Plug (965 603 021)

Compliant With EPA Phase 2, EU Stage 2 Exhaust Emissions Regulations

• Multi-positional engine

• Environment-friendly 2-stroke engine with catalytic exhaust

• Equipped with Easy Start system for faster,

easier starting

• Compact trimmer head cover for better view

of cutting area, without losing performance

of preventing grass clippings

to be scattered

• High power output to easily

trim the 16" cutting swath

15-3/4˝ / 25.7cc 2-Stroke Line Trimmer

SPECIFICATIONS

Cutting Width

15-3/4˝ (400 mm)

Displacement

25.7cc

Maximum Engine Power 0.83 Kw / 1.11 HP

Carburetor

Diaphragm Type

Fuel / Oil Mixture

50:1

Fuel Tank Capacity

0.6L

Overall Length

64-3/4˝ (164 cm)

Dry Weight

9.5 lbs ( 4.3 kg)

ER2600L

Lightweight yet powerful

2-Stroke trimmer

STANDARD EQUIPMENT INCLUDES:

ProtectorAssembly (DA00000525), Protector (DA00000526),Trimmer Head (DA00000454), Shoulder Harness (DA00000456),

Socket Wrench M5 (DA00000457),Tool Kit (DA00000458), Spark Plug (965 603 021)

Compliant With EPA Phase 2, EU Stage 2 Exhaust Emissions Regulations

• Multi-positional engine

• Environment-friendly 2-stroke engine with

catalytic exhaust

• Wide trigger control and soft grip for

comfortable operation

• Primer bulb and choke for easy starting

• Durable nylon string trimmer head

17˝ / 25.7cc 2-Stroke Line Trimmer

SPECIFICATIONS

Cutting Width

17˝ (430 mm)

Displacement

25.7cc

Maximum Engine Power 0.83 Kw / 1.15 HP

Carburetor

Diaphragm Type

Ignition System

Recoil

Fuel / Oil Mixture

50:1

Fuel Tank Capacity

0.6L

Overall Length

69-3/4˝ (177 cm)

Dry Weight

10.8 lbs (4.9 kg)

EM2600L

Professional Use

EBH253L

STANDARD EQUIPMENT INCLUDES:

Trimmer HeadAssembly (123234-9), Protective Guard (452260-4),Trimmer Head Protective GuardAttachment (135753-3),

Box Wrench 16-17 (783013-3),Hex Wrench 4 (783202-0), Hex Wrench 5 (783217-7), Shoulder Harness (125516-5), Engine Oil Set,

Starter Rope (444020-8), Spark Plug (168534-0),Accessory Bag (831304-7)

Save The Cost Of The Trimmer With Fuel Savings Alone!

• Patented lubrication system enables Makita 4-Stroke Brushcutters & Line Trimmers to be

used on any angles and slopes

• Anti-vibration system for fatigue free use

• Clean exhaust emissions and lower fuel consumption

• 40% less fuel consumption compared to

2-stroke equivalent

Quiet, Low Vibration,

Extreme Fuel Cost Savings

16˝ / 24.5cc 4-Stroke Line Trimmer

SPECIFICATIONS

Cutting Width

16˝ (406 mm)

Displacement

24.5cc

Maximum Engine Power 0.71 Kw / 0.97 HP

Carburetor

Diaphragm Type

Fuel / Oil Mixture

Not Required

Fuel Tank Capacity

0.5 L

Oil Tank Capacity

0.08 L

4-Stroke Crank Case Oil

10W-30

Overall Length

69-3/4˝ (177 cm)

Dry Weight

11.5 lbs ( 5.2 kg)

DUR188LZ

STANDARD EQUIPMENT INCLUDES:

Tool Only. Batteries and Charger Sold Separately.

Bump & FeedTrimmer Head (198385-7), Protective Guard (457324-9),

Shoulder Harness (125516-5), Hex Wrench 4 (783202-0), Hex Wrench 5 (783217-7),Accessory Bag (831304-7)

Lightweight and Powerful with Low Noise Level suitable for use in Residential

Areas and Public Spaces. Split shaft for ease of storage and transporting.

• Brushless DC Motor for Longer Life / Less Heat / More Run Time & More Work

• XPT (eXtreme Protection Technology) Prevent Debris & Liquids from entering the tool, Expands Tool

Usage to Harsh Environments and Provides Longer Tool Life

• Automatic torque Drive Technology (ADT) Adjusts Motor Speed and Torque during heavy-Duty cutting for

Maximum Efficiency and Performance

• Battery Protection System provides Over-Discharge,Temperature and Circuit Protection for

Enhanced Performance, and Overall Battery Life

• Front Mounted Operator Controls for easy function changes during use

• Reverse Switch for Clearing Entangled Weeds and Grass

from Cutting Head

• Split shaft design for easier storage and transportation

11-3/4˝ / 18V LXT Cordless Split Shaft Line Trimmer

SPECIFICATIONS

Battery Capacities

18V Li-Ion

No Load Speed 4,000 / 5,000 / 6,000 RPM

Cutting Width

11-3/4˝ (300 mm)

Overall Length

70-1/2˝ (179.1 cm)

Net Weight

6.7 lbs (3.0 kg)

3 Speed, Reversible

Brushless / ADT / XPT

Battery Protection System

DUR365UZ

STANDARD EQUIPMENT INCLUDES:

Tool Only. Batteries and Charger Sold Separately.

Bump and FeedTrimmer HeadAssembly (197296-3), Protective Guard (197295-5),

Safety Goggles (195246-2), Shoulder Harness (125516-5), Hex Wrench 4 (783202-0), Hex Wrench 5 (783217-7),Accessory Bag (831304-7)

Powerful Trimming For Where Low Noise Is A Concern

• Brushless motor is located on the trimmer head end to provide

ultimate torque for trimming

• XPT (eXtreme Protection Technology) is provided to protect the

unit under wet and dirty conditions for the longest life

• Electronic current limiter for overload protection

• Dual LED charge level indicators display approximate

remaining battery power

• Soft start feature for added motor protection

• Brushless motor with electronic 3 speed selection

• Reverse switch for easy removal of stuck grass clippings

in the trimmer head

• Ergonomically designed bike handle for best

operator control

9˝ / 18Vx2 LXT Cordless Brush Cutter

SPECIFICATIONS

Battery Capacities

Two 18V Li-Ion

No Load Speed 3,500 / 5,300 / 6,500 RPM

Cutting Width

13-3/4˝ (350 mm)

Overall Length

69˝ (1,754 mm)

Net Weight

8.9 lbs (4.0 kg)
