General Catalogue

207 / 212

Cordless Power Tools
205
Cordless
Benchtop
Saws
Woodworking
Hammers
Dust
Extraction
Drills
Metalworking
Pneumatic
OPE
ManufacturingAnd Assembly
BFL081FZ
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately. TorqueAdjustmentTool (765027-4)
Precise Torque Control Consistently Delivers Repeatability Of +/- 10%
• Built in LED to illuminate tight spaces
• Extremely compact and lightweight for outstanding ergonomics
• On board LED and audible signal informs user of successful rundown
• Highly accurate spring clutch
• Designed and manufactured to withstand high
volume assembly processes
Reversible
3/8˝ Precise Torque Angle Wrenches
SPECIFICATIONS
Battery 12V Ni-MH
Capacity (Driving Shank)
Square 3/8˝
Width 2-13/16˝ (71 mm)
Height (With Battery) 3-5/8˝ (92 mm)
Length (With Battery) 17.0˝ (430 mm)
Net Weight 2.4 lbs (1.1 kg)
No Load Speed:
BFL081FZ 700 RPM
BFL121FZ 410 RPM
BFL200FZ 220 RPM
Fastening Torque:
BFL081FZ 2 - 8 Nm. (17.7 – 70.8 in./lbs)
BFL121FZ 5 - 12 Nm. (44.3 – 106 in./lbs)
BFL200FZ 8 - 20 Nm. (70.8 – 177 in./lbs)
BFL200FZ BFL121FZ DFL400FZ
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold
Separately. TorqueAdjustmentTool (765027-4)
Precise Torque Control Consistently Delivers Repeatability Of +/- 10%
• Built in LED to illuminate tight spaces
• Extremely compact and lightweight for outstanding ergonomics
• On board LED and audible signal informs user of successful rundown
• Highly accurate spring clutch
• Designed and manufactured to withstand high volume assembly processes
3/8˝ Precise Torque Angle Wrench
SPECIFICATIONS
Battery Capacities 14.4V Li-ion
Capacity (Driving Shank)
Square 3/8˝
No Load Speed 260 RPM
Fastening Torque 25 - 40 Nm.
(221 – 354 in./lbs)
Width 2-7/8˝ (73 mm)
Height (With Battery) 4-1/8˝ (104 mm)
Length (With Battery) 20-1/16˝ (510 mm)
Net Weight 3.3 lbs (1.5 kg)
DFL082FZ DFL122FZ DFL202FZ
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately. TorqueAdjustmentTool (765027-4)
Precise Torque Control Consistently Delivers Repeatability Of +/- 10%
• Built in LED to illuminate tight spaces
• Extremely compact and lightweight for outstanding ergonomics
• On board LED and audible signal informs user of successful rundown
• Designed and manufactured to withstand
high volume assembly processes
3/8˝ Precise Torque Angle Wrenches
SPECIFICATIONS
Battery Capacities 14.4V Li-ion
Capacity (Driving Shank)
Square 3/8˝
Width 2-15/16˝ (74 mm)
Height (With Battery) 3-7/8˝ (98 mm)
Length (With Battery) 16-5/8˝ (422 mm)
Net Weight 2.6 lbs (1.2 kg)
No Load Speed:
DFL082FZ 700 RPM
DFL122FZ 410 RPM
DFL202FZ 220 RPM
Fastening Torque:
DFL082FZ 2 - 8 Nm. (18 – 71 in./lbs)
DFL122FZ 5 - 12 Nm. (44 – 106 in./lbs)
DFL202FZ 8 - 20 Nm. (71 – 177 in./lbs)
Reversible
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately. TorqueAdjustmentTool (765027-4)
Precise Torque Control Consistently Delivers Repeatability Of +/- 10%
• Built in LED to illuminate tight spaces
• Extremely compact and lightweight for
outstanding ergonomics
• On board LED and audible signal informs user of
successful rundown
• Highly accurate spring clutch
• Designed and manufactured to withstand
high volume assembly processes
1/4˝ Precise Torque Screwdrivers
SPECIFICATIONS
Battery 9.6V Ni-MH
Capacity (Driving Shank)
Hex 1/4˝
Width 2-9/16˝ (65 mm)
Height (With Battery) 10-3/4˝ (274 mm)
Length (With Battery) 7-7/8˝ (200 mm)
Net Weight 2.2 lbs (1.0 kg)
No Load Speed:
BFT080FZ 540 RPM
BFT122FZ 320 RPM
Fastening Torque:
BFT080FZ 3 - 8 Nm. (26.6 – 70.8 in./lbs)
BFT122FZ 5 - 12 Nm. (44.3 – 106 in./lbs)
Reversible
BFT123FZ
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately. TorqueAdjustmentTool (765027-4)
Precise Torque Control Consistently Delivers Repeatability Of +/- 10%
• Built in LED to illuminate tight spaces
• Extremely compact and lightweight for outstanding ergonomics
• On board LED and audible signal informs user of successful rundown
• Highly accurate spring clutch
• Designed and manufactured to withstand high volume assembly processes
Reversible
1/4˝ Precise Torque Screwdrivers
SPECIFICATIONS
Battery 12V Ni-MH
Capacity (Driving Shank)
Hex 1/4˝
No Load Speed 390 RPM
Fastening Torque
5-12 Nm. (44.3 - 106 in./lbs)
Width 2-13/16˝ (71 mm)
Height (With Battery) 11-1/8˝ (283 mm)
Length 7-7/8˝ (200 mm)
Net Weight 2.2 lbs (1.0 kg)
Reversible
Anti-Kick Back Attachment 195620-4
• Prevents harmful kick back from being transmitted to operator during
high-torque fastening applications (Sold Separately)
BFT080FZ BFT122FZ
For Battery and Charger Compatibility
please refer to pages 56 – 58
DFL300FZ
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold
Separately. TorqueAdjustmentTool (765027-4)
Precise Torque Control Consistently Delivers Repeatability Of +/- 10%
• Built in LED to illuminate tight spaces
• Extremely compact and lightweight for outstanding ergonomics
• On board LED and audible signal informs user of successful rundown
• Highly accurate spring clutch
• Designed and manufactured to withstand high volume assembly processes
3/8˝ Precise Torque Angle Wrenches
SPECIFICATIONS
Battery Capacities 14.4V Li-ion
Capacity (Driving Shank)
Square 3/8˝
Width 2-7/8˝ (73 mm)
Height (With Battery) 4-1/8˝ (104 mm)
No Load Speed 400 RPM
Fastening Torque
16 - 30 Nm. (142 – 266 in./lbs)
Length (With Battery) 19-15/16˝ (506 mm)
Net Weight 3.1 lbs (1.4 kg)
Anti-Kick Back Attachment 195620-4
• Prevents harmful kick back from being transmitted to operator during
high-torque fastening applications(Sold Separately)
Reversible
