STANDARD EQUIPMENT INCLUDES:
Tool-Kit (282-290301-H0),Two Spark Plugs (065-01402-80), (Battery Not Included)
Electric Start
• RECEPTACLES: Duplex 120V (20 AMP), Locking 120V (20 AMP), Locking 120V (30 AMP),
Locking 120V / 240V (30 AMP)
• GENERATOR: Full copper windings, AC & DC circuit breakers, AVR (Automatic Voltage Regulator)
• SUBARU-ROBIN: Air-cooled 4 cycle single cylinder OHC gasoline engine, Idle switch features full
power mode, Low oil automatic shut-off, Auto
decompression / Electronic ignition, Overhead
valve for more fuel efficiency
8.2 Hours Of Continuous Operation
12,000W / 653cc 4-Stroke Generator
SPECIFICATIONS
Maximum Output Current
12,000W
(100 / 50 AMP)
Rated Output Current 9,500W / 79.2 / 39.6 A
AC Voltage
60 Hz (120V / 240V)
DC Voltage
12 VDC (8.3 AMP)
Displacement
653cc
Maximum Power
22 HP @ 3,600 RPM
Fuel Tank Capacity
44 L
Continuous Operation
8.2 Hrs (at high RPM)
Noise Level
77 dB
Dimensions (L x W x H)
32.5˝ x 24.1˝ x 30.4˝
(826 mm x 611 mm x 771 mm)
Dry Weight
310.0 lbs (141 kg)
G12000R
STANDARD EQUIPMENT INCLUDES:
Tool Kit (224-90303-00), Starter Rope (20B-50110-08), Spark Plug (065-01402-10)
• RECEPTACLES: Duplex 120V (20 AMP) Locking 120V (20 AMP), Locking 120V (30 AMP),
Locking 120V, 240V (20 AMP)
• GENERATOR: Full copper windings, AC & DC circuit breakers, AVR (Automatic Voltage Regulator)
• SUBARU-ROBIN: Air-cooled 4 cycle single cylinder OHC gasoline engine, Full power mode switch,
Low oil automatic shut-off, Auto decompression / Electronic ignition, Overhead valve for more
fuel efficiency
6.6 Hours Of Continuous Operation
7,100W / 404cc 4-Stroke Generator
SPECIFICATIONS
Maximum Output Current
7,100W
(59.2 / 29.6 AMP)
Rated Output Current 5,000W / 41.6 / 20.8 A
AC Voltage
60 Hz (120V / 240V)
DC Voltage
12 VDC (8.3 AMP)
Displacement
404cc
Maximum Power 12.5 HP @ 4,000 RPM
Fuel Tank Capacity
22 L
Continuous Operation
6.6 Hrs (at high RPM)
Noise Level
75.5 dB
Dimensions (L x W x H)
28-1/2˝ x 20-7/8˝ x 21-3/4˝
(725 mm x 530 mm x 580 mm)
Dry Weight
189.6 lbs (86 kg)
EG711A
Makita offers a wide variety of
ACCESSORIES!
STANDARD EQUIPMENT INCLUDES:
Socket Wrench 17 (782210-8), Elbow Joint (P-80008)
Used To Cut Steel, Concrete And Masonry Materials
• Guide wheels on the tool guard ensure smooth tool travel over surface material
• Rubber shield protects the operators hand and motor from debris
• Lock-On button for continuous operation
• Ball bearing construction for longer tool life
• “SJS” technology prevents kickback if blade jams protecting both the operator and tool
• Integrated nozzle can be connected to vacuum system for clean operation
AC/DC, “SJS” Technology
14˝ Angle Cutter
SPECIFICATIONS
Blade Diameter
14˝ (355 mm)
Arbor
1˝ (25.4 mm)
Maximum Cutting Depth 5˝ (125 mm)
No Load Speed
3,800 RPM
AMPS (120V)
15.0 A
Overall Length
26-1/2˝ (673 mm)
Net Weight
22.7 lbs (10.3 kg)
4114
STANDARD EQUIPMENT INCLUDES:
Plastic Carrying Case (824697-9), Socket Wrench 17 (782210-8)
Used To Cut Steel, Concrete And Masonry Materials
• Guide wheels on the tool guard ensure smooth tool travel over surface material
• Rubber shield protects the operators hand and motor from debris
• Lock-On button for continuous operation
• Ball bearing construction for longer tool life
• “SJS” technology prevents kickback if blade jams protecting both the operator and tool
• Integrated nozzle can be connected to vacuum system for clean operation
AC/DC, “SJS” Technology
12˝ Angle Cutter
SPECIFICATIONS
Blade Diameter
12˝ (305 mm)
Arbor
1˝ (25.4 mm)
Maximum Cutting Depth 3-15/16˝ (100 mm)
No Load Speed
5,000 RPM
AMPS (120V)
15.0 A
Overall Length
25-1/2˝ (648 mm)
Net Weight
25.1 lbs (11.4 kg)
4112H
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
Blade (1 Ea. B-20432, 1 Ea. 723063-A-5), Hex Wrench 3 (783201-2)
Ultra-Compact And Lightweight Design For Maximum Versatility
and Maneuverability
• Multi-position switch (tool handle & tool body) with lock-off levers for easier operation, maximum
versatility and operator safety
• Battery protection system provides over-discharge,
temperature and circuit protection for
enhanced performance, battery cycle life
and overall battery life
• One-handed, fast tool-less blade changes
• LED joblight with afterglow feature
18V LXT Cordless Reciprocating Saw
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Maximum Cutting Capacities:
Pipe
2˝ (50 mm)
Wood (12" Blade)
2˝ (50 mm)
Strokes Per Minute
0 - 3,000 SPM
Length of Stroke
1/2˝ (13 mm)
Overall Length
15-5/8˝ (398 mm)
Net Weight
2.7 lbs (1.2 kg)
DJR183Z
GENERATOR WHEEL KITS
Part No.
Description
For Models
110004-B
• Constructed of rugged,
lightweight tubular steel
• Mounts directly to generator
frame for easy portability
• Pneumatic wheels for easy
transportation around the jobsite
G2800I, EG301A
110004-D
EW220R, EW320R
EW320TR
