STANDARD EQUIPMENT INCLUDES:
Hex Wrench 4 (783202-0), Plastic Carrying Case (824490-1), Safety Goggles (195246-2), Oil Supply (181434-7)
15° Round Head Coil Siding Nailer
• 360° exhaust system directs exhaust away from the operator
• 3 Mode - Sequential, Bump, Lock-Off
• Easy load magazine provides maximum versatility
• 9 depth nailing settings in 1/16˝ increments with adjustment knob
• Convenient adjustable Belt Hook
• One touch and easy to load magazine
• Rubberized Grip for increased comfort during prolonged use
2-1/2˝ Coil Siding Nailer
SPECIFICATIONS
Operating Air Pressure 65 - 120 PSIG
Nail Size:
Wire Collated
1-1/4˝ - 2-1/2˝
(32 mm - 65 mm)
Plastic Collated
1-1/4˝ - 2˝
(32 mm - 50 mm)
Nail Type .080˝ - .099˝ 15° Round Head
Magazine Capacity
200 - 400 Nails
Dimensions (L x W x H)
13-1/16˝ x 5˝ x 12-1/2˝
(332 mm x 317 mm x 127 mm)
Net Weight
5.1 lbs (2.3 kg)
AN611
STANDARD EQUIPMENT INCLUDES:
Oil Supply 30cc (181434-7), Safety Goggles (195246-2), Hex.Wrench 3 (783201-2), Hex.Wrench 4 (783202-0),
Protective Casing (BA00000165), Plastic Carrying Case (BA00000397)
16-Gauge Lightweight Finish Nailer
• 360° exhaust system directs exhaust away from operator
• Rubber grip for comfortable handling
• Fires in Sequential Mode
• Convenient Adjustable Belt Hook
2-1/2˝ Finishing Nailer
SPECIFICATIONS
Operating Air Pressure 72.5 - 116 PSIG
Nail Size (16 ga)
3/4˝ - 2-1/2˝
(20 mm - 64 mm)
Nail Type
16 ga Finishing Nails
Magazine Capacity
100
Dimensions (L x W x H)
11-1/2˝ x 2-7/8˝ x 10-3/4˝
(292 mm x 74 mm x 272 mm)
Net Weight
3.5 lbs (1.6 kg)
AF600
STANDARD EQUIPMENT INCLUDES:
Oil Supply (181434-7), Safety Glasses (A0908-0171), Wrench (A0913-0011)
1˝ - 2˝ (1˝ Width) 16-Gauge Staples
• 360° exhaust system directs exhaust away from operator
• Dry fire prevention prolongs tool life
• Rubber grip for comfortable handling
• Inlet Filter prevent contamination due to dust or debris
• Quick Release nose enables easy clearing of jammed nails
1˝ Crown Stapler
SPECIFICATIONS
Operating Air Pressure 65 - 120 PSIG
Staple Size: (L x W)
1˝ - 2˝ (1˝ Width)
Nail Type
16ga Crown Staples
Magazine Capacity
140
Dimensions (L x W x H )
14-1/2˝ x 3˝ x 10-1/4˝
(370 mm x 76 mm x 260 mm)
Net Weight
4.9 lbs (2.2 kg)
AT2550A
STANDARD EQUIPMENT INCLUDES:
Oil Dispenser (181434-7), Plastic Carrying Case (A0905-0361), Safety Goggles (A0908-0171),Wrench 3 (783201-2), Wrench 4 (783202-0)
18-Gauge Crown Stapler
• 360° exhaust system directs exhaust away from operator
• Rubber grip for comfortable handling
• Clear window allows operator to see number of remaining staples
• Quick release magazine; staples load from the top
• Convenient Adjustable Belt Hook
1/4˝ Crown Stapler
SPECIFICATIONS
Operating Air Pressure 60 - 115 PSIG
Staple Size 5/8˝ - 1-1/2˝ (18 ga) (1/4˝ Width)
Magazine Capacity
100
Dimensions (L x W x H)
9-3/4˝ x 2-7/16˝ x 9-3/4˝
(247 mm x 62 mm x 246 mm)
Net Weight
5.5 lbs (2.5 kg)
AT638
STANDARD EQUIPMENT INCLUDES:
Oil Supply (181434-7), Safety Glasses (A0908-0171), Wrench (A0913-0011)
1˝ - 2˝ (7/16˝ Width) 16-Gauge Staples
• 360° exhaust system directs exhaust away from operator
• Dry fire prevention prolongs tool life
• Rubber grip for comfortable handling
• Inlet Filter prevent contamination due to dust or debris
• Quick Release nose enables easy clearing of jammed nails
7/16˝ Crown Stapler
SPECIFICATIONS
Operating Air Pressure 65 - 120 PSIG
Staple Size: (L x W)
1˝ - 2˝ (7/16˝ Width)
Nail Type
16ga Crown Staples
Magazine Capacity
140
Dimensions (L x W x H)
14-1/2˝ x 3-7/16˝ x 11-3/8˝
(370 mm x 87 mm x 290 mm)
Net Weight
4.0 lbs (1.8 kg)
AT1150A
STANDARD EQUIPMENT INCLUDES:
Oil Supply (181434-7), Safety Goggles (195246-2), NoseAdapter (HY00000378), Plastic Carrying Case (HY00000090)
Features Slim Contact Tip Design For Precise Woodworking
Fastening Applications
• Slim contact tip design enables precise fastening in wood trim, crown moulding, baseboard, casing,
cabinetry and other woodworking applications!
• 360° exhaust system directs exhaust air away from operator
• Quick release noise enables fast and easy clearing of jammed nails
• Quick release, side loading magazine holds up to 100 18-gauge brad nails
• Dual windows enable fast identification of remaining nail capacity
• Convenient, adjustable belt hook for operator convenience
2˝ Brad Nailer
SPECIFICATIONS
Operating Air Pressure 60 - 115 PSIG
Nail Size (18 ga)
5/8˝ - 2˝ (15 - 50 mm)
Nail Type
18 ga Brad Nails
Magazine Capacity
100
Dimensions (L x W x H)
10-1/4˝ x 2-1/2˝ x 9-3/8˝
(260 mm x 64 mm x 237 mm)
Net Weight
3.0 lbs (1.4 kg)
AF505N
