150 / 180
PNEUMATIC
makita.ca148
Cordless
Benchtop
Saws
Woodworking
Hammers
Dust
Extraction
Drills
Metalworking
Pneumatic
OPE
Manufacturing
And Assembly
STANDARD EQUIPMENT INCLUDES:
Hex Wrench 4 (783202-0), NoseAdapter (421658-6), Oil Supply (181434-7), Safety Goggles (195246-2)
15° Round Head Coil Framing Nailer
• 360° exhaust system directs exhaust away from the operator
• 3 Mode - Sequential, Bump, Lock-off
• 9 depth nailing settings in 1/16˝ increments with adjustment knob
• Convenient adjustable Belt Hook
• One touch and easy to load magazine
• Rubberized Grip for increased comfort during prolonged use
3-1/2˝ Framing Coil Nailer
SPECIFICATIONS
Operating Air Pressure 65 - 120 PSIG
Nail Size 1-3/4˝ - 3-1/2˝ (45 mm - 90 mm)
Nail Type .099˝ - .150˝ 15° Round Head
Magazine Capacity
150 - 300 Nails
Dimensions (L x W x H)
16-1/8˝ x 12-1/2˝ x 5-1/4˝
(408 mm x 316 mm x 131 mm)
Net Weight
7.1 lbs (3.2 kg)
AN901
STANDARD EQUIPMENT INCLUDES:
Oil Supply (181434-7), Safety Goggles (195246-2), Protective Casing (BA00000372)
15° Round Head Coil Framing Nailer
• Reduced size for improved handling and optimal maneuverability during operation
• 2 Mode - Sequential, Bump Fire
• 8 depth nailing settings in 1/32˝ increments with adjustment knob
• One touch and easy to load magazine
• Rubberized Grip for increased comfort during prolonged use
3-1/2˝ Framing Coil Nailer
SPECIFICATIONS
Operating Air Pressure 70 - 120 PSIG
Nail Size 1-3/4˝ - 3-1/2˝ (45 mm - 90 mm)
Nail Type .099˝ - .150˝ 15° Round Head
Magazine Capacity
150 - 300 Nails
Dimensions (L x W x H)
12-1/2˝ x 5˝ x 14-1/4˝
(318 mm x 128 mm x 363 mm)
Net Weight
7.7 lbs (3.5 kg)
AN902
STANDARD EQUIPMENT INCLUDES:
HookAssy (122742-7), Oil Supply 30cc (181434-7), Safety Goggles (195246-2)
21° Round Head Framing Nailer
• Large capacity air chamber for increased power
• 3 Mode - Sequential, Bump, Lock-Off
• 9 depth nailing setting in 1/16˝ increments
with adjustment knob
• Convenient Collapsible Rafter Hook
• Nose piece with sure-grip spikes prevents slipping
• Dry fire prevention system prolongs life of tool
• Silent sheet reduces noise when
disconnecting coupler
3-1/2˝ Framing Nailer
SPECIFICATIONS
Operating Air Pressure 65 - 120 PSIG
Nail Size
2˝ - 3-1/2˝
Nail Type .113˝ - .162˝ 21° Round Head
Magazine Capacity
64 - 74 Nails
Dimensions (L x W x H)
22˝ x 4-1/4˝ x 13-11/16˝
(559 mm x 109 mm x 347 mm)
Net Weight
8.6 lbs (3.9 kg)
AN923
STANDARD EQUIPMENT INCLUDES:
HookAssy (122742-7), Oil Supply 30cc (181434-7), Safety Goggles (195246-2)
34° Clipped Head Framing Strip Nailer
• Large capacity air chamber for increased power
• 3 Mode - Sequential, Bump, Lock-off
• 9 depth nailing setting in 1/16˝ increments
with adjustment knob
• Convenient Collapsible Rafter Hook
• Nose piece with sure-grip spikes prevents slipping
• Dry fire prevention system prolongs life of tool
• Silent sheet reduces noise
when disconnecting coupler
3-1/2˝ Framing Nailer
SPECIFICATIONS
Nail Type .113˝ - .131˝ 34° Clipped Head
Nail Size
2˝ - 3-1/2˝ 34° Clipped Head
Operating Air Pressure
65-120 PSIG
Magazine Capacity
60 - 84 Nails
Dimensions (L x W x H)
17-7/8˝ x 4-1/4˝ x 14-3/8˝
(455 mm x 109 mm x 365 mm)
Net Weight
8.8 lbs (4.0 kg)
AN943
Uses 34° Clipped Head
Framing Nails
STANDARD EQUIPMENT INCLUDES:
Safety Goggles (195246-2), Oil Supply (181434-7), Hex Wrench 4 (783202-0)
15° Round Head Coil Roofing Nailer
• Operates in Bump Fire mode
• 6 depth nailing settings with adjustment knob
• Convenient adjustable Belt Hook
• One touch and easy to load magazine
• Rubberized Grip for increased comfort during prolonged use
• Easy to remove contact top to clear nail/debris jams
1-3/4˝ Coil Roofing Nailer
SPECIFICATIONS
Operating Air Pressure 65 - 120 PSIG
Nail Size 3/4 – 1-3/4˝ (19 mm - 45 mm)
Nail Type 1/8˝ (3.0 mm) 15° Round Head
Magazine Capacity
120 Nails
Dimensions (L x W x H)
10-3/8˝ x 4-5/8˝ x 10-5/8˝
(265 mm x 117 mm x 269 mm)
Net Weight
5.5 lbs (2.5 kg)
AN453
STANDARD EQUIPMENT INCLUDES:
Oil Supply (181434-7)
15° Round Head Coil Roofing Nailer
• Operates in Bump Fire Mode
• 9 Depth Settings with adjustment knob
• Two Housing Guards to protect air chamber
• One-Touch, easy to load magazine
• Quick Release Shingle Guide for easy adjustment on the jobsite
• Rubberized Grip for vibration absorption and comfortable operation
1-3/4˝ Roofing Coil Nailer
SPECIFICATIONS
Operating Air Pressure 65 - 120 PSIG
Nail Size 7/8˝ – 1-3/4˝ (22 mm - 45 mm)
Nail Type 1/8˝ (3.0 mm) 15° Round Head
Magazine Capacity
120 Nails
Dimensions (L x W x H)
9-5/8˝ x 4-1/2˝ x 10-3/8˝
(245 mm x 114 mm x 265 mm)
Net Weight
5.8 lbs (2.5 kg)
AN451
Makita offers a wide variety of
ACCESSORIES!
Uses 21° Round Head
Framing Nails
