PNEUMATIC
146
Cordless
Benchtop
Saws
Woodworking
Hammers
Dust
Extraction
Drills
Metalworking
Pneumatic
OPE
Manufacturing And Assembly
STANDARD EQUIPMENT INCLUDES:
1/4˝ Quick Coupler (10TT-8)
Requires Minimum 15 AMP Circuit
• Oil lubricated for cooler operation and reduced noise
• High output V-twin cast iron pump runs cooler than
inline pumps and delivers maximum performance
and operational life
• Big BoreTM cylinder and piston feature high output
at lower RPM with reduced heat buildup, less noise
and longer operational life
• Low amperage draw reduces incidents of tripped
breakers and voltage drops that cause
premature motor failure
• Features 3 quick
connect air hose fittings
Oil Lubricated
3 hp Electric Air Compressor
SPECIFICATIONS
Motor 3 hp
Pump Oil-Lubricated
Cut In Pressure 100 PSI
Cut Out Pressure 125 PSI
Tank 2 x 4 Gallon
Performance 6 CFM @ 100 PSI
Maximum Pressure 150 PSI
Dimensions: (L x W x H, with handle)
42˝ x 18˝ x 26˝ (107 cm x 457 mm x 660 mm)
Net Weight 160 lbs (72.6 kg)
MAC3001
Powered By 4 Stroke Honda
GX160 Engine
• Oil lubricated for cooler operation and reduced noise
• High output V-twin cast iron pump runs cooler than
inline pumps and delivers maximum performance
and operational life
• Big BoreTM cylinder and piston feature high output
at lower RPM with reduced heat buildup, less noise
and longer operational life
• Automatic idle control minimizes fuel consumption
and maximizes
service life
5.5 hp Gas Power Air Compressor
MAC5501G
Oil Lubricated
9237C
STANDARD EQUIPMENT INCLUDES:
9237C: HookandLoopBackingPad(743052-5),HexWrench6(783204-6),LoopHandle(455292-0),Sleeve(262542-4)
9237CX1: Hook and Loop Backing Pad (743052-5), Hex Wrench 6 (783204-6), Loop Handle (455292-0), Sleeve (262542-4), Medium CCS
Foam Polishing Pad (T-01236X), Soft CCS Foam Polishing Pad (T-01242X), Hard CCS Foam Polishing Pad (T-01220X), 21˝Tool Bag (821007X)
Designed As The Premium Polisher For Professional Polishing Applications
• Variable speed dial and trigger enables operator to adjust speed based on exact polishing application
• Ideal for maximum control during slow polish applications.
• Electronic speed control maintains constant speed under load
• Soft Start feature gradually increases speed to eliminate start up shock
• Improved power cord guard protects cord against damage and excessive wear
• Soft rubber tool rest enables tool to be set down without damaging underlying materials
• Protective rubber head cover prevents damage to materials caused by impact or abrasion during operation
7˝ Electronic Polisher
SPECIFICATIONS
Maximum Capacities:
Sanding Disc 7˝ (180 mm)
Wool or Foam Polishing Pad
7˝ (180 mm)
No Load Speed 0 - 3,200 RPM
AMP (120V) 10.0 A
Spindle Thread 5/8˝-11 UNC
Overall Length 17˝ (431 mm)
Net Weight 7.5 lbs (3.4 kg)
Soft Start,
Electronic
Speed Control,
Variable Speed
9237CX1 PO5000C
STANDARD EQUIPMENT INCLUDES:
Hook & Loop Backing Pad (197923-2), Hex Wrench (783203-8), Wrench Holder (410047-0)
Random Orbit (FINE) and Random Orbit with Forced Rotation (Coarse) Modes
• Variable speed dial and trigger enables operator to adjust speed based on exact polishing application
• Ideal for maximum control during slow polish applications.
• Electronic speed control maintains constant speed under load
• Soft Start feature gradually increases speed to eliminate start up shock
• Improved power cord guard protects cord against damage and excessive wear
• Soft rubber tool rest enables tool to be set down without damaging underlying materials
• Protective rubber head cover prevents damage to materials caused by impact or abrasion during operation
5˝ Electronic Polisher
SPECIFICATIONS
No Load Speed 180 - 790 RPM
AMP (120V) 7.8 A
Overall Length 17-34˝ (451 mm)
Net Weight 6.0 lbs (2.7 kg)
Variable Speed,
Constant Speed
Control, Soft Start
COLLAPSED CELL SYSTEM (CCS) FOAM POLISHING PADS
Density Colour Application Diameter Backing Pad Part No. For Model Part No.
Soft Black Finessing
7-1/2" 743052-5 9227CZ
9237C
T-01242
Medium White Polishing T-01236
Hard Yellow Cutting T-01220
9" DOUBLE-SIDED WOOL POLISHING BONNETS
• Double-sided bonnets offer 2x longer life versus traditional
single-sided bonnets
• Multiple bonnet densities suitable for various applications,
including compounding and polishing
• Threaded arbour adapter allows fast and easy pad changes
without the need for centering devices
• Usable edges enable effective performance in tight spaces,
around vehicle side mirrors, door handles and more!
• Use with D-57087 5/8"-11 Adapter
• For models: 9237C / X1
Part No. Description Material Max. RPM
D-57071 9" Double Wool Polishing Bonnet (Coarse) 100% Wool
4,000 RPM
D-57152 9" Double Wool Polishing Bonnet (Fine) 50% Wool / 50% Polyester
D-57087 5/8"-11 Double Wool Bonnet Adapter - -
Coarse
D-57071
Fine
D-57152
D-57087
STANDARD EQUIPMENT INCLUDES:
Two 1/4˝ Quick Couplers (10TT-8), Spark Plug (065-01404-80)
SPECIFICATIONS
Gas Motor 5.5 hp
Pump Oil-Lubricated
Tank 10 Gallon
Performance 12.5 CFM @ 100 PSI
Maximum Pressure 130 PSI
Overall Length 46˝ (117 cm)
Net Weight 190 lbs (86.2 kg)
