Makita General Catalogue

Electric

Power Tools

makita.ca

147

When

QUALITY & SERVICE

Counts – Choose Makita

Cordless

Benchtop

Saws

Woodworking

Hammers

Dust

Extraction

Drills

Metalworking

Pneumatic

OPE

Manufacturing

And Assembly

STANDARD EQUIPMENT INCLUDES:

1/4˝ Quick Coupler, (10TT-8), Compressor Oil (0.3L) (181122-A)

Low Noise At Only 79 db

• Oil lubricated for cooler operation and reduced noise

• High output cast iron pump delivers maximum performance and operational life

• Big Bore

cylinder and piston feature high output at lower RPM with reduced heat buildup, less noise

and longer operational life

• Low amperage draw reduces incidents of tripped breakers and voltage drops that cause

premature motor failure

• Easy view oil gauge and large pressure gauges for quick identification

• Air pressure regulator enables easy adjustment of line pressure

2.5 hp Air Compressor

SPECIFICATIONS

Motor

2.5 hp

Pump

Oil-Lubricated

Tank

2 x 2.1 Gallon

Performance (90 PSI)

4.2 CFM

AMPS (120 V)

12.3 A

Dimensions (L x W x H)

20-1/2˝ x 19-5/8˝ x 20-7/8˝

(520 mm x 497 mm x 530 mm)

Maximum Pressure

130 PSI

Net Weight

77.0 lbs (34.9 kg)

MAC2400

STANDARD EQUIPMENT INCLUDES:

7˝ D.C.W. 24 Grit (741413-B), Wheel Guard (122767-1), Side Handle (152539-0), Inner Flange (224317-9), Lock Nut (224568-4),

Lock Nut Wrench (782412-6)

INCLUDES:

• 18 Gauge Brad Nailer (AF505N)

• 2 hp Compressor (MAC700)

• 25 ft. Hose (YYVAH25)

• Air Fitting (YY311018-A), (YY311002-A)

• Quick coupler 1/4˝ (447013)

• Compressor oil (0.3L) (181122-A)

2 hp Air Compressor And Brad Nailer Kit

SPECIFICATIONS

(MAC700) Motor

2.0 hp

Pump

Oil-Lubricated

Tank

2.6 gal (9.8 L)

Performance (90 PSI)

3.3 CFM

AMPS (120V)

12.4 A

Dimensions (L x W x H)

19-5/16˝ x 12-1/8˝ x 24-1/8˝

(491 mm x 310 mm x 615 mm)

Maximum Pressure

130 PSI

Net Weight

52.0 lbs (23.6 kg)

MAC700-KIT3

STANDARD EQUIPMENT INCLUDES:

1/4˝ Quick Coupler, (10TT-8), Compressor Oil (0.3 L) (181122-A)

Low Noise At Only 80 db

• Oil lubricated for cooler operation and reduced noise

• High output cast iron pump delivers maximum performance and operational life

• Big Bore

cylinder and piston feature high output at lower RPM with reduced heat buildup,

less noise and longer operational life

• Low amperage draw reduces incidents of tripped breakers and voltage drops that cause

premature motor failure

• Easy view oil gauge and large pressure gauges for quick identification

• Air pressure regulator enables easy easy adjustment of line pressure

2 hp Air Compressor

SPECIFICATIONS

Motor

2.0 hp

Pump

Oil-Lubricated

Tank

2.6 gal (9.8 L)

Performance (90 PSI)

3.3 CFM

AMPS (120 V)

12.4 A

Dimensions (L x W x H)

19-5/16˝ x 12-1/8˝ x 24-1/8˝

(493 mm x 310 mm x 615 mm)

Maximum Pressure

130 PSI

Net Weight

52.0 lbs (23.6 kg)

MAC700

STANDARD EQUIPMENT INCLUDES:

1/4˝ Quick Coupler (447013)

Ultra-Compact and Lightweight Design Ideal For Trim, Cabinetry,

Hobby and DIY Applications

• Oil-less design requires no day to day maintenance

• Integrated roll cage design protects motor, tank and switch from damage during storage,

transport and operation

• Low noise level suitable for interior use

• Large pressure gauges for quick identification on the jobsite

• Air pressure regulator enables easy adjustment of line pressure

• Features 1 quick connect air hose fitting

1 hp Peak Air Compressor

SPECIFICATIONS

Motor

1.0 hp (Peak)

Pump

Oil-Free

Tank

1.0 gal (4.0L)

Performance (90 PSI)

0.45 CFM

AMPS (120V)

1.8 A

Dimensions (L x W x H, with Handle Folded)

13˝ x 15˝ x 11-1/2˝

(330 mm x 381 mm x 292 mm)

Maximum Pressure

125 PSI

Net Weight

23.1 lbs (10.5 kg)

AC001

Oil-less

STANDARD EQUIPMENT INCLUDES:

Oil Supply 30cc (181434-7), Safety Goggles (195246-2)

28° Round Head Framing Strip Nailer

• Large capacity air chamber for increased power

• 2 Mode - Sequential & Bump

• Depth setting knob for adjustment of nailing depth

• Convenient Collapsible Rafter Hook

• Nose piece with sure-grip spikes prevents slipping

Uses 28° Round Head

Framing Nails

3-1/2˝ Framing Nailer

SPECIFICATIONS

Nail Type 0.113˝ - 0.131˝, 28° Round Head

Magazine Capacity

60 - 84 Nails

Operating Air Pressure

70-120 PSIG

Nail Size 2-1/2˝- 3-1/2˝, 28° Round Head

Dimensions (L x W x H)

17-1/2˝ x 4-31/32˝ x 13-11/32˝

(445 mm x 126 mm x 339 mm)

Net Weight

7.0 lbs (3.2 kg)

AN944

STANDARD EQUIPMENT INCLUDES:

1/4˝ Quick Coupler (10TT-8), Compressor Oil (0.3L) (181122-A)

Designed Especially For Framing Nailers

• Oil lubricated for cooler operation and reduced noise

• High output cast iron pump delivers maximum performance and operational life

• Big Bore

cylinder and piston feature high output at lower RPM with reduced heat buildup, less noise

and longer operational life

• Low amperage draw reduces incidents of tripped breakers and voltage drops that cause

premature motor failure

• Easy view oil gauge and large pressure gauges for quick identification

Oil Lubricated

3 hp Air Compressor

SPECIFICATIONS

Motor

3.0 hp

Pump

Oil-Lubricated

Tank

5.2 gal (19.7L)

Performance (90 PSI)

6.5 CFM

AMPS (120 V)

13.8 A

Dimensions (L x W x H, with Handle Folded)

30-5/16˝ x 20˝ x 21-13/16˝

(770 mm x 510 mm x 553 mm)

Maximum Pressure

140 PSI

Net Weight

88.0 lbs (39.9 kg)

MAC5200

Oil Lubricated
