130 / 220
HAMMERS
Cordless
Benchtop
Saws
Woodworking
Hammers
Dust
Extraction
Drills
Metalworking
Pneumatic
OPE
Manufacturing
And Assembly
NEW!
SDS-MAX3 PIECE CORE BITS
Diameter Core Part No. Shank Type & Part No.
Pilot Drill Bit Part No.
Drift Pin Part No.
1-3/4"
B-66634
SDS-MAX 9"
B-66612
SDS-MAX 12"
B-66628
Spline 9"
B-66597
Spline 12"
B-66606
B-66709
(7/16" x 4-1/2")
B-66715
2"
B-66640
2-5/8"
B-66656
3-1/8"
B-66662
4"
B-66678
5"
B-66684
6"
B-66690
• Core bits are ideal for drilling large diameter holes in concrete
• 3 piece modular system includes Core, Shank and Pilot Bit
• Modular design allows operator to utilize same components across a range of
core sizes and enables easy and less costly replacement as required
• Use with Makita Rotary Hammer Grease 194683-7 or 196804-7
NEW!
SDS-MAX TUNNEL DRILL BITS
Diameter
Overall Length
Usable Length
Part No.
2-1/8"
24"
18"
B-66298
2-1/2"
B-66307
3-1/8"
B-66313
• Ideal for drilling deep through-holes
• Ideal alternative to core bits
• Solid single piece design transfers power directly to the drilling tip
for maximum performance
• Use with Makita Rotary Hammer Grease 194683-7 or 196804-7
STANDARDSDS-MAX2-CUTTER
ROTARYHAMMERDRILL BITS
Diameter Overall Length Usable Length Cutting Edges Part No.
1/2"
13"
8"
2 Cutting
Edges
D-36538
21"
16"
D-36544
9/16"
21"
16"
D-36550
5/8"
13"
8"
D-36566
21"
16"
D-36572
3/4"
13"
8"
D-36588
21"
16"
D-36594
27/32"
21"
16"
D-36603
7/8"
13"
8"
D-36619
21"
16"
D-36625
1"
13"
8"
D-36631
21"
16"
D-36647
1-1/8"
15"
10"
D-36653
22"
18"
D-36669
1-1/4"
15"
10"
D-36675
22"
18"
D-36681
1-3/8"
22"
18"
D-36697
1-1/2"
22"
18"
D-36706
PREMIUM6-CUTTER SDS-MAX
ROTARYHAMMERDRILL BITS
Diameter
Usable Length Overall Length
Part No.
1/2"
8"
13"
B-61307
16"
21"
B-61313
9/16"
8"
13"
B-61329
16"
21"
B-61335
5/8"
8"
13"
B-61341
16"
21"
B-61357
31"
36"
B-61363
11/16"
16"
21"
B-61379
3/4"
8"
13"
B-61385
16"
21"
B-61391
31"
36"
B-61400
13/16"
16"
21"
B-61416
7/8"
8"
13"
B-61422
16"
21"
B-61438
31"
36"
B-61444
1"
8"
13"
B-61450
16"
21"
B-61466
31"
36"
B-61472
1-1/8"
8"
13"
B-61488
16"
21"
B-61494
31"
36"
B-61503
1-1/4"
8"
13"
B-61519
16"
21"
B-61525
31"
36"
B-61531
1-3/8"
16"
21"
B-61547
31"
36"
B-61553
1-1/2"
16"
21"
B-61569
31"
36"
B-61575
• Premium made in Europe quality design, materials and manufacturing
• 6-cutter design (5/8") design with aggressive head geometry engineered
for drilling in reinforced concrete
• 6-cutter design ensures round holes for anchoring applications
• Centering tip enables easy spot drilling with pinpoint accuracy and no walking
• Flute design maximizes efficiency of dust removal for faster drilling and longer bit life
• Engineered for reduced vibration transmission to operator
• Use with Makita Rotary Hammer Bit Grease 194683-7
128
B-66634
B-66690
B-66298
NEW!
DUST EXTRACTIONDRILL BITS
Diameter
Overall Length
Usable Length
Part No.
1/2"
15-3/4"
24"
B-63828
9/16"
B-63834
5/8"
B-63840
3/4"
B-63862
7/8"
B-63884
1"
B-63890
1-1/8"
B-63909
1-3/16"
B-63915
1-1/4"
B-63921
1-3/8"
B-63937
Replacement Vacuum Attachment
B-63943
• Through hole design and vacuum attachment enables dust to be extracted
directly at the source, creating cleaner holes for anchoring applications and
eliminating exposure of workers to airborne dust
• 3-cutter (1/2" - 3/4") and 10-cutter design (7/8" - 1-3/8") with aggressive head
geometry ensures round holes for anchoring applications
• Use with Makita AC or DC Dust Extractors for maximum performance and efficiency
• Use with Makita Rotary Hammer Grease 194683-7 or 196804-7
Through hole design and
vacuum attachment enables
dust to be extracted
directly at the source!
B-63828
