DUST EXTRACTION
Portable, Efficient Dust Extraction Technology
• Automatic filter cleaning system to maximize filter efficiency and maintain suction power
• Washable HEPA Filter cartridge filter protects turbine by holding back fine dust and debris
• Power regulation and switch off delay in auto mode
• On-board outlet and automatic start feature enables dust extractor to be operated in conjunction with power tools
• Variable suction power enables operator to adjust the suction power to the application
• Air Flow sensor warning with LED indication
• Compact and lightweight poly-carbonate shell for ease of transport
• Low noise level (60 dBA suitable for use in sensitive environments including hospitals, schools, institutions and more!)
• 13' Anti-Static Suction Hose (Features Quick Connect Coupling)
SPECIFICATIONS
Container Capacity
42.0 L
Dry Tank Capacity
34.0 L
Wet Tank Capacity
30.0 L
Maximum Air Flow
148 CFM
Static Water Lift
101" (255 cm)
AMPS (120V)
7.4 A
Power Cord Length
24.6 ft (7.5 m)
Overall Length
22-5/8" (575 mm)
Net Weight
35.3 lbs (16.0 kg)
VC4210L
L Class
Automatic Filter Cleaning 42.0 L Dust Extractor
Wet & Dry
MAXIMUMAIR FLOW
The
AMOUNT
of air being drawn in by the turbine. Typically measured in cubic feet per minute (CFM)
STANDARD EQUIPMENT INCLUDES:
HEPAFilter (W107413555), Fleece Filter Bag (1 Ea. W107418353),
Disposal Bag (1 Ea. W107418355), 1-3/8" x 13'Anti-Static Suction Hose
(Features Quick Connect Coupling) (P-84084), Quick ConnectToolAdapter (P-70378),
ToolAdapter (W07418688), Crevice Nozzle (W6084),Two Interlocking Case Holder (W107418357)
Interlocking Case Holder
mounted on the machine!*
* Interlocking Case
Sold Separately
Push & Clean Filter System clears particulate and debris from clogged
filters to maximize filter efficiency and maintain suction power
• Onboard outlet and automatic start feature enables dust extractor to be operated in
conjunction with power tools
• For wet and dry vacuuming cleaning
• Variable settings enable operator to adjust the suction power to the application
• Push and clean system
• Washable HEPA Filter cartridge filter protects turbine by holding back fine dust and debris
• Automatic on / off function
• Polycarbonate shell with 2 wheels and 2 castors for excellent stability and mobility
SPECIFICATIONS
Container Capacity
30.0 L
Dry Tank Capacity
24.0 L
Wet Tank Capacity
19.0 L
Maximum Air Flow
0 - 113 CFM
Static Water Lift
101" (255 cm)
AMPS (120V)
7.0 A
Power Cord Length
24.6' (7.5 m)
Overall Length
19-3/8" (500 mm)
Net Weight
22.0 lbs (10.0 kg)
VC3012L
L Class
Push & Clean Filter Cleaning 30.0 L Dust Extractor
Wet & Dry
STANDARD EQUIPMENT INCLUDES:
Floor Nozzle (P-81789), ExtensionTubes (P-70437), 12" Crevice
Nozzle (P-80005), Front Cuff 32 (W14682), CurvedTube Handle
(P-70346), Quick ConnectToolAdapter (P-70378), 1-3/8"
x 13'Anti-Static Suction Hose (Features Quick Connect
Coupling) (P-84084), Nano Fleece Filter Bag (1 Ea. P-84078),
HEPAFilter (T-01806), Plastic Disposal Bag (1 Ea. P-70297)
Push & Clean Filter System clears particulate and debris from clogged
filters to maximize filter efficiency and maintain suction power
• Onboard Outlet and Automatic Start Feature enables dust extractor to be operated in conjunction with power tools
• For Wet and Dry vacuuming cleaning
• Variable Settings enable operator to adjust the suction power to the application
• Push and clean system
• Washable PET cartridge filter protects turbine by holding back fine dust and debris
• Automatic On / Off function
• Polycarbonate shell with 2 wheels and 2 castors for excellent stability and mobility
• 11' Anti-static hose and grounded canister prevents buildup of static charges
SPECIFICATIONS
Container Capacity
25.0 L
Dry Tank Capacity
21.0 L
Wet Tank Capacity
18.0 L
Maximum Air Flow
127 CFM
Static Water Lift
84.4" (215 cm)
AMPS (120V)
9.4 A
Power Cord Length
24.6' (7.5 m)
Overall Length
15-5/8" (395 mm)
Net Weight
17.4 lbs (8.0 kg)
VC2512L
L Class
Push & Clean Filter Cleaning 25.0 L Compact Dust Extractor
Wet
& Dry
STANDARD EQUIPMENT INCLUDES:
Floor Nozzle (W107402706), ExtensionTubes (P-72942), Crevice
Nozzle (W295410000), Universal Nozzle (W142950000),ToolAdapter
(W107409977), 1-1/4" x 11' Suction Hose (W107406115), Filter Bag
(P-72899), Plastic Disposal Bag (1 Ea. P-70297), PETFleece Filter
Cartridge (P-70219),AccessoryTool Box (W107409980)
AUTO-STARTWIRELESS SYSTEM (AWS)
DUST EXTRACTORADAPTER SET
WUT02U
• Enables wireless on / off activation of electric (AC) dust extractors when used with Makita cordless AWS tools
• Features hanging hook and band to secure to transmitter to dust extractor
• Includes two (2) AWS Bluetooth
®
Transmitters (part no. 198901-5)
Bluetooth
®
is a registered trademark of Bluetooth
®
SIG
WUT02U
