General Catalogue

Electric

Power Tools

STANDARD EQUIPMENT INCLUDES:

1/2" Drill Chuck (192877-8), Chuck Key (763432-9), Side Handle (122428-3), Depth Gauge (321059-7), Plastic Carrying Case (824608-4)

Makita’s Most Popular 3/4˝ Hammer Drill

Hammer & Rotation / Rotation Only

• Industrial Aluminum Gear Housing for durability

• 1/2" Chuck will accept 3/4" concrete bits with 1/2" reduced shank

• Depth Setting Rod for easier drilling of accurate hole depths

• 360° Swivel Side Handle

Variable 2-Speed, Reversible

3/4" Hammer Drill

SPECIFICATIONS

Maximum Capacities:

Concrete

3/4" (20 mm)

Steel

1/2" (13 mm)

Wood

1-1/2" (40 mm)

No Load Speed:

Low

0 - 900 RPM

High

0 - 2,300 RPM

Blows Per Minute:

Low

0 - 18,000 BPM

High

0 - 46,000 BPM

AMPS (120V)

6.0 A

Overall Length

13-3/4" (350 mm)

Net Weight

6.4 lbs (2.9 kg)

HP2010N

STANDARD EQUIPMENT INCLUDES:

Dust Bag (122708-7), Dust Cap (421727-3), Side Handle (135302-6), Plastic Carrying Case (824729-2) (Shown with Optional Bit)

SDS-Plus Shank, Built-In Dust Collection System

Hammer & Rotation / Hammer Only / Rotation Only

• Dust Collection System especially suited for operation in Hospitals, Schools and other job sites

where dust collection is mandatory

• 40 Angle Bit Positions enable chisels to be positioned at optimum angle of operation

• One-Touch Sliding Chuck for easy bit installation and removal

• Ergonomic Soft Rubber Grip for vibration absorption and comfortable operation

Variable Speed, Reversible,

With Dust Collector

1" Rotary Hammer

SPECIFICATIONS

Bit Type

SDS-PLUS

Maximum Capacities:

Concrete

1" (25 mm)

Steel

1/2" (13 mm)

Wood

1-1/4" (32 mm)

No Load Speed

0 - 1,000 RPM

Blows Per Minute

0 - 4,500 BPM

Impact Energy

2.2 J (1.6 ft. lbs)

AMPS (120V)

6.7 A

Overall Length

16" (407 mm)

Net Weight

7.1 lbs (3.2 kg)

HR2432

STANDARD EQUIPMENT INCLUDES:

Side Handle (158057-6), Depth Gauge (415486-9), Plastic Carrying Case (824650-5)

SDS-PLUS Shank, Up To 46% REDUCED VIBRATION!

Hammer & Rotation / Rotation Only

• Anti-Vibration Technology (AVT

) system incorporates an active dynamic vibration absorbing

counterbalance spring and a vibration absorbing handle to actively counteract the vibration of the tool

for greatly reduced transmission to the operator

• Torque limiter stops bit rotation if bit jams for increased operator safety and enhanced tool protection

• Variable speed trigger allows operator to adjust speed based on materials or application

• Reverse rotation system using brush holder unit provides the same amount of power in forward and

reverse and extends life of carbon brushes

• 2 operating modes: Rotation / Rotation + Hammer

• One-touch SDS-PLUS sliding chuck for easy bit

installation and removal

Variable Speed, Reversible

11/16" Rotary Hammer

SPECIFICATIONS

Bit Type

SDS-PLUS

Maximum Capacities:

Concrete

11/16" (18 mm)

Steel

1/2" (13 mm)

Wood

15/16" (24 mm)

No Load Speed

0 – 2,100 RPM

Blows Per Minute

0 – 4,800 BPM

Impact Energy

1.4 J (1.0 ft. lbs)

AMPS (120V)

4.1 A

Overall Length

11-1/4" (285 mm)

Net Weight

5.4 lbs (2.5 kg)

HR1841F

STANDARD EQUIPMENT INCLUDES:

Side Handle (158057-6), Depth Gauge (324219-0), Plastic Carrying Case (824799-1)

SDS-PLUS Shank

Hammer & Rotation / Hammer Only / Rotation Only

• Torque Limiter stops bit rotation if bit jams for increased operator safety and enhanced tool protection

• High Durability design with Zig-Zag Armature Varnish, Enhanced Sealing, Improved Impact Bolt and

Impact Reducing Cushion Ring

• Reverse Rotation System using Brush Holder Unit provides the same amount of power in forward and

reverse and extends life of carbon brushes

• Rubber Housing Bumper protects mode selector switch and gear housing from damage

• 40 Angle Bit Positions enable chisels to be positioned at optimum angle of operation

• One-Touch Sliding Chuck for easy bit installation and removal

• LED Light illuminates drilling position

Variable Speed,

Reversible

15/16" Rotary Hammer

SPECIFICATIONS

Bit Type

SDS-PLUS

Maximum Capacities:

Concrete

15/16" (24 mm)

Steel

1/2" (13 mm)

Wood

1-1/4" (32 mm)

No Load Speed

0 – 1,100 RPM

Blows Per Minute 0 – 4,500 BPM

Impact Energy 2.7 J (1.99 ft. lbs)

AMPS (120V)

6.7 A

Overall Length 14-1/2" (370 mm)

Net Weight

6.4 lbs (2.9 kg)

HR2470F

STANDARD EQUIPMENT INCLUDES:

Side Handle (158057-6), Depth Gauge (415486-9), Plastic Carrying Case (821706-5)

SDS-PLUS Shank

Hammer & Rotation / Rotation Only

• Torque limiter stops bit rotation if bit jams for increased operator safety and enhanced tool protection

• Variable speed trigger allows operator to adjust speed based on materials or application

• Reverse rotation system using brush holder unit provides the same amount of power in forward and

reverse and extends life of carbon brushes

• 2 operating modes: Rotation / Rotation + Hammer

• One-touch SDS-PLUS sliding chuck for easy bit installation and removal

• Ergonomic soft rubber grip for vibration absorption and

comfortable operation

Variable Speed, Reversible

11/16" Rotary Hammer

SPECIFICATIONS

Bit Type

SDS-PLUS

Maximum Capacities:

Concrete

11/16" (18 mm)

Steel

1/2" (13 mm)

Wood

15/16" (24 mm)

No Load Speed

0 – 2,100 RPM

Blows Per Minute

0 – 4,800 BPM

Impact Energy

1.4 J (1.0 ft. lbs)

AMPS (120V)

4.1 A

Overall Length

11-1/4" (285 mm)

Net Weight

5.3 lbs (2.4 kg)

HR1840

Cordless

Benchtop

Saws

Woodworking

Hammers

Dust

Extraction

Drills

Metalworking

Pneumatic

OPE

Manufacturing

And Assembly

125

makita.ca

WHERE TOBUY

Buy ONLINE !

Follow us @makita.ca

STANDARD EQUIPMENT INCLUDES:

1/2" Drill Chuck & Key Set (193067-6), Side Handle (135302-6), Depth Gauge (324219-0), Plastic Carrying Case (824650-5)

Hammer & Rotation / Rotation Only

• Improved Motor Durability with Machined Metal Gearing

• Torque Limiter stops bit rotation if bit jams for increased operator safety and enhanced tool protection

• Industrial Aluminum Gear Housing for durability

• Industrial Strength Keyed Chuck for durability

• 1/2" Chuck will accept 3/4" concrete bits

with 1/2" reduced shank

• 360° Side Handle

Variable 2-Speed, Reversible

3/4" Hammer Drill

SPECIFICATIONS

Maximum Capacities:

Concrete:

Low - 3/4" (20 mm)

High - 3/4" (20 mm)

Steel:

Low - 1/2" (13 mm)

High - 5/16" (8 mm)

Wood

Low - 1-9/16" (40 mm)

High - 1" (26 mm)

No Load Speed

Low

0 - 1,200 RPM

High

0 - 2,900 RPM

Blows Per Minute

Low

0 - 24,000 BPM

High

0 - 58,000 BPM

AMPS (120V)

6.6 A

Overall Length

14-1/4" (372 mm)

Net Weight

5.5 lbs (2.5 kg)

HP2050H
