STANDARD EQUIPMENT INCLUDES:
Keyless Drill Chuck (196193-0), Side Handle (153503-4), Plastic Carrying Case (824811-7)
Ideal For Small Self Anchoring Concrete Screws
Hammer & Rotation / Rotation Only
• Industrial Aluminum Gear Housing for durability and long tool life
• Lock-On Button for easy comfortable operation during prolonged periods of use
• 1/2" Keyless Chuck will accept 5/8" concrete bits with 1/2" reduced shank
• 360° Swivel Side Handle
• Ergonomic Soft Rubber Grip design for vibration absorption and comfortable operation
Variable Speed, Reversible
5/8" Hammer Drill
SPECIFICATIONS
Maximum Capacities:
Concrete
5/8" (16 mm)
Steel
1/2" (13 mm)
Wood
1-3/16" (30 mm)
No Load Speed
0 - 3,200 RPM
Impacts Per Minute
0 - 48,000 IPM
AMPS (120V)
6.2 A
Overall Length
11-5/8" (296 mm)
Net Weight
4.4 lbs (2.0 kg)
HP1631K
SPECIFICATIONS
Wheel Diameter
5" (125 mm)
Wheel Type
Offset Diamond
Hole Diameter
7/8" (22.3 mm)
PC5010C:
No Load Speed 4,000 - 9,000 RPM
AMPS (120V)
12.0 A
Cord Length
8.2' (2.5 m)
Overall Length 17-1/8" (437 mm)
Net Weight
7.7 lbs (3.5 kg)
PC5000C:
No Load Speed
10,000 RPM
AMPS (120V)
10.0 A
Cord Length
16.4' (5.0 m)
Overall Length 17-1/8" (437 mm)
Net Weight
8.8 lbs (4.0 kg)
PC5001C:
No Load Speed
10,000 RPM
AMPS (120V)
10.0 A
Cord Length
16.4' (5.0 m)
Overall Length 18-13/16" (479 mm)
Net Weight
11.2 lbs (5.1 kg)
PC5010C, PC5000C, PC5001C
5" Concrete Planers
STANDARD EQUIPMENT
INCLUDES:
Loop Handle (458690-7),
Lock Nut Wrench 28 (782425-7)
PC5010C
• SJS II (Super Joint System II) reduces vibration
and prevents kickback during wheel lock up for
optimal tool and operator protection
(PC5010C Only)
• Variable speed dial enables operator to adjust
wheel speed based on materials or application
(PC5010C Only)
• Auxiliary Planing Base and Front Roller enables
planing to a consistent depth (PC5001C Only)
• Electronic Speed Control maintains constant
speed under heavy load
• Soft Start feature gradually increases speed to
eliminate start up shock
• Electronic Current Limiter eliminates motor
burnout due to current overload
• Anti-Restart feature prevents tool from operating
if it is plugged in when locked in the on position
• LED Light indicates active power supply and
activation of Anti-Restart feature
• Easy to Operate Larger Trigger Switch with
Lock-On feature
• Removable Front Dust Cap enables operator to
plane flush to walls and corners
5" DIAMONDCUPWHEELS
Diameter Arbour Range
Rim Type
Segments Finish Type Max. RPM For Models Part No.
5"
7/8"
Standard
Segmented
11
Fast / Rough
12,250 RPM PC5010C
PC5000C
PC5001C
D-41458
Continuous
-
Fine / Finish
D-41464
Premium
Double Row Segmented
11
Fast / Rough
12,200 RPM
A-95009
Continuous
-
Fine / Finish
A-94998
STANDARD EQUIPMENT
INCLUDES:
D-Style Front Handle (273529-1),
5" Offset Finish Diamond Wheel
(A-94998), Dust BagAssembly
(122853-8), Wrench Holder
(410047-0), Hex Wrench 5 (783203-8),
Lock Nut Wrench 28 (782425-7),
Steel Carrying Case (140073-2)
PC5001C
STANDARD EQUIPMENT
INCLUDES:
Loop Handle (416256-9),
5" Offset Coarse Diamond Wheel
(A-95009), Dust BagAssembly
(122853-8), Wrench Holder
(410047-0), Hex Wrench 5 (783203-8),
Lock Nut Wrench 28 (782425-7)
PC5000C
Thumb Switch
with Lock-On (AC)
126
Visit us online
>
makita.ca
STANDARD EQUIPMENT INCLUDES:
HP1641K:
Keyless Drill Chuck (196193-0),
Side Handle (135302-6), Depth Gauge (324219-0),
Plastic Carrying Case (824811-7)
HP1640:
Keyed Drill Chuck (763115-1), Chuck Key (763430-3),
Side Handle (153503-4), Depth Gauge (324219-0)
Ideal For Small Self Anchoring Concrete Screws
Hammer & Rotation / Rotation Only
• Lock-On Button for easy comfortable operation during prolonged periods of use
• 1/2" Keyless Chuck will accept 5/8" concrete bits with 1/2" reduced shank (HP1641K Only)
• 1/2" Keyed Chuck will accept 5/8" concrete bits with 1/2" reduced shank (HP1640 Only)
• 360° Swivel Side Handle
• Industrial aluminum gear housing for durability and long tool life (HP1640 Only)
5/8" Hammer Drills
SPECIFICATIONS
Maximum Capacities:
Concrete
5/8" (16 mm)
Steel
1/2" (13 mm)
Wood
1-3/16" (30 mm)
No Load Speed
0 - 2,800 RPM
Impacts Per Minute
0 - 44,800 IPM
AMPS (120V)
6.0 A
Overall Length
11-7/8" (303 mm)
Net Weight
4.4 lbs (2.0 kg)
HP1641K
HP1640
HP1640
with Keyed Chuck
HP1641K
with Keyless Chuck
Variable Speed,
Reversible
makita.ca
>
WHERE TOBUY
>
Buy INASTORE !
PC5010C
