190 / 220
Advanced High Pressure
Pneumatic Technology
AC310HX
PNEUMATIC
Cordless
Benchtop
Saws
Woodworking
Hammers
Dust
Extraction
Drills
Metalworking
Pneumatic
OPE
Manufacturing
And Assembly
STANDARD EQUIPMENT INCLUDES:
Wheel Kit (HY00000212)
Advanced High Pressure Pneumatic Technology
• Low noise level - Just 90 dB
• Oil-less design requires no day to day maintenance
• Features dual high pressure and dual 90-130 PSI fittings enables use of multiple pneumatic tools
• Unique High Pressure fittings eliminates confusion with 90-130 PSI fittings
• Internal breaker and reset function eliminates overload of main electrical source
High Pressure Air Compressor
SPECIFICATIONS
Maximum Pressure:
High Pressure
375 PSI
Regular Pressure
130 PSI
Performance:
(90 PSI) 3.6 CFM
(300 PSI) 2.7 CFM
Pump
Oil-less
Output Power
1,500 W
Motor
2.5 HP
Tank Size
1.6 gal. (6.2 L)
Dimensions (L x W x H)
18-3/4" x 14-3/4" x 20"
(476 mm x 375 mm x 507 mm)
Net Weight
79.4 lbs (36.0 kg)
AC310HX
HIGH PRESSURE COLLATEDAUTOFEEDSCREWS
Length Shank
Diameter
Shank /
Thread
Head
Diameter
Notes
Application Box Qty.
For Model
Part No.
1"
0.139"
Fine
0.322" PH2 Recess /
Ultra-Coated
Drywall to
Steel
2,000
(20 Strips
of 100)
AR410HR
F-32830
1-1/8"
F-32843
1-5/8"
F-32856
1"
0.146"
Coarse
Drywall to
Wood
F-32869
1-1/8"
F-32872
1-1/4"
F-32885
1-5/8"
F-32898
HIGH PRESSURE PNEUMATICHOSE
Length
Inner Diameter (I.D.)
Maximum Operating Pressure Part No.
25' (7.5 m)
1/4" (6 mm)
470 PSI (3.25 Mpa)
B-80036
50' (15 m)
B-80014
100' (30 m)
B-80020
HIGH PRESSURE PNEUMATIC
MAINTENANCE ACCESSORIES
Description
For Model(s)
Part No.
Air Leak
Repair Set
AN450H, AN610H
194735-4
AN250HC, AN911H
194737-0
AR410HR
194738-8
Pneumatic
Oil 30 mL
All Makita High
Pressure Tools
194381-3
188
Superior Power To Weight
Ratio Versus 90-130 PSI
• 2 mode - Sequential Fire or Lock-Off
• Limited recoil and operator strain ideal for use over prolonged periods
• Increased drive power ideal for hardwoods or laminated materials and ensures
consistent depth of drive
• Adjustable depth of drive up to 3/8" (10 mm)
• Recessed mode selector switch eliminates accidental engagement
• One-touch magazine opens quickly and easily for rapid nail loading
• Slim contact arm and vertical magazine enables easy operation in narrow spaces
• Adjustable belt hook for operator convenience
SPECIFICATIONS
Nail Size
3/4" - 1"
(19 mm - 25 mm)
Nail Type
0.099" - 0.120"
Plastic Sheet Collated Concrete Nails
Magazine Capacity
100 Nails
Operating Pressure
170 - 320 PSI
Dimensions (L x W x H)
11-5/8" x 5" x 11-1/2"
(295 mm x 128 mm x 291 mm)
Net Weight
4.6 lbs (2.1 kg)
+
STANDARD EQUIPMENT INCLUDES:
NoseAdapter (424234-5),NoseAdapterB(424237-9),
SafetyGoggles (195246-2),OilSupplySet (194381-3),
PlasticCarryingCase (824792-5)
AN250HC
INCLUDES:
High PressureAir Compressor (AC310HX) 1˝ High Pressure
Coil Concrete Nailer (AN250HC) High Pressure Hose (B-80014)
AC310HX4
Combo Kit
Nails Metal Studs & Track To Concrete
AN250HC, AC310HX4
1
"
High Pressure Coil Concrete Nailers
HIGH PRESSURE COLLATEDCONCRETE PINS
Length Shank
Diameter
Shank
Thread
Head
Diameter
Notes
Application
Box Qty.
For Model
Part No.
3/4"
0.12"
Stepped
0.25"
High Density Concrete Metal Stud or
Track to
Concrete
1,000
(10 Strips of 100) AN250HC
F-33591
3/4"
0.098"
Spiral
Regular Density
Concrete
F-33562
1"
F-33588
