186 / 220
Air blower feature cleans material
of dust and debris
AT638A
PNEUMATIC
Cordless
Benchtop
Saws
Woodworking
Hammers
Dust
Extraction
Drills
Metalworking
Pneumatic
OPE
Manufacturing
And Assembly
STANDARD EQUIPMENT INCLUDES:
Two NoseAdapter (HY00000378), Oil Supply, Safety Goggles (HY00000951)
Features Slim Contact Tip Design For Precise Woodworking
Fastening Applications
• Slim contact tip design enables precise fastening in wood trim, crown moulding, baseboard, casing,
cabinetry and other woodworking applications!
• Air blower feature cleans material of dust and debris
• Quick release nose enables fast and easy clearing of jammed nails
• Quick release, side loading magazine holds up to 100 18-gauge brad nails
• Dual windows enable fast identification of remaining nail capacity
• Convenient, adjustable belt hook for operator convenience
2˝ Brad Nailer
SPECIFICATIONS
Operating Air Pressure 70 - 120 PSIG
Nail Size (18 ga)
5/8" - 2" (15 - 50 mm)
Nail Type
18 ga Brad Nails
Magazine Capacity
100
Dimensions (L x W x H)
9-7/8" x 2-3/4" x 10-1/8"
(250 mm x 70 mm x 256 mm)
Net Weight
2.9 lbs (1.3 kg)
AF506
STANDARD EQUIPMENT INCLUDES:
Two NoseAdapter (HY00000422), Oil Supply, Plastic Carrying Case, Safety Goggles
15-Gauge Finish Nailer
• 2 mode - sequential & bump fire
• 360° exhaust system directs exhaust away from operator
• Air blower feature cleans material of dust and debris
• Toolless depth adjustment for quick and easy adjustment
• Quick release toolless nose enables easy clearing of jammed nails
• Contact arm design prevents accidental engagement of
trigger for maximum operator safety
• High visibility slim nose tip enables precise positioning of nails
2-1/2" Angled Finishing Nailer
SPECIFICATIONS
Operating Air Pressure 70 - 120 PSIG
Nail Size (15 ga)
1-1/4" - 2-1/2" (32 - 64 mm)
Nail Type
15 ga Finishing Nails
Magazine Capacity
100
Dimensions (L x W x H)
13-3/8" x 3-15/16" x 12-1/8"
(339 mm x 100 mm x 309 mm)
Net Weight
4.0 lbs (1.8 kg)
AF635
STANDARD EQUIPMENT INCLUDES:
Two NoseAdapter (HY00000560), Oil Supply, Plastic Carrying Case, Safety Goggles
16-Gauge Straight Finish Nailer
• 2 mode - sequential & bump fire
• 360° exhaust system directs exhaust away from operator
• Air blower feature cleans material of dust and debris
• Toolless depth adjustment for quick and easy adjustment
• Quick release toolless nose enables easy clearing of jammed nails
• Contact arm design prevents accidental engagement of trigger for maximum operator safety
• High visibility slim nose tip enables precise positioning of nails
2-1/2" Straight Finishing Nailer
SPECIFICATIONS
Operating Air Pressure 70 - 120 PSIG
Nail Size (16 ga) 1" - 2-1/2" (25 - 64 mm)
Nail Type
16 ga Finishing Nails
Magazine Capacity
100
Dimensions (L x W x H)
12" x 3-3/4" x 11-3/4"
(304 mm x 95 mm x 297 mm)
Net Weight
3.8 lbs (1.7 kg)
AF601
184
makita.ca
>
WHERE TOBUY
>
Buy INASTORE !
Visit us online
>
makita.ca
STANDARD EQUIPMENT INCLUDES:
Oil Supply (181434-7), Safety Goggles (195246-2), Protective Casing (BA00000372)
15° Round Head Coil Framing Nailer
• Reduced size for improved handling and optimal maneuverability during operation
• 2 Mode - Sequential, Bump Fire
• 8 depth nailing settings in 1/32" increments with adjustment knob
• One touch and easy to load magazine
• Rubberized Grip for increased comfort during prolonged use
3-1/2" Framing Coil Nailer
SPECIFICATIONS
Operating Air Pressure 70 - 120 PSIG
Nail Size 1-3/4" - 3-1/2" (45 mm - 90 mm)
Nail Type 0.099" - 0.150" 15° Round Head
Magazine Capacity
150 - 300 Nails
Dimensions (L x W x H)
12-1/2" x 5" x 14-1/4"
(318 mm x 128 mm x 363 mm)
Net Weight
7.7 lbs (3.5 kg)
AN902
STANDARD EQUIPMENT INCLUDES:
Hex Wrench 4 (783202-0), Plastic Carrying Case (824490-1), Safety Goggles (195246-2), Oil Supply (181434-7)
15° Round Head Coil Siding Nailer
• 360° exhaust system directs exhaust away from the operator
• 3 Mode - Sequential, Bump, Lock-Off
• Easy load magazine provides maximum versatility
• 9 depth nailing settings in 1/16" increments with adjustment knob
• Convenient adjustable Belt Hook
• One touch and easy to load magazine
• Rubberized Grip for increased comfort during prolonged use
2-1/2" Coil Siding Nailer
SPECIFICATIONS
Operating Air Pressure
65 - 120 PSIG
Nail Size:
Wire Collated
1-1/4" - 2-1/2"
(32 mm - 65 mm)
Plastic Collated
1-1/4" - 2"
(32 mm - 50 mm)
Nail Type 0.080" - 0.099" 15° Round Head
Magazine Capacity
200 - 400 Nails
Dimensions (L x W x H)
13-1/16" x 5" x 12-1/2"
(332 mm x 317 mm x 127 mm)
Net Weight
5.1 lbs (2.3 kg)
AN611
