GN900S
STANDARD EQUIPMENT INCLUDES:
7.2VLi-IonBattery
BL0715 (198001-1),Charger (DC07SA),PlasticCarryingCase (824875-1),SafetyGoggles (195246-2),
HexWrench4 (783230-5)
Makita's First Cordless 34° Clipped Head Framing Nailer
• Utilizes industry standard fuel cells
• Utilizes 7.2V (1.5Ah) Li-Ion Battery BL0715 with 35 minute charging time
• LED Warning System indicates low battery capacity or tool malfunction for quick identification on the jobsite
• Anti-Slip Sure Grip Spikes provide optimal hold against material
• Dual Position Rafter Hook for operator convenience
• Ergonomic Soft Rubber Grip design for vibration absorption and comfortable operation
3-1/2" Cordless Framing Nailer
SPECIFICATIONS
Battery Capacities
7.2V Li-Ion
Charging Time
30 Minutes
Battery Life
Approx. 4,000 Nails
Fuel Cell Life
Approx. 1,200 Nails
Nail Type
0.113" - 0.131" (2.9 - 3.3 mm)
34° Clipped Head
Driving Speed:
Nails / sec. 2 - 3
Dimensions (L x W x H)
12-5/8" x 4-1/4" x 14-1/2"
(321 mm x 108 mm x 368 mm)
Net Weight
7.5 lbs (3.4 kg)
STANDARD EQUIPMENT INCLUDES:
Two 7.2V Li-Ion Batteries
BL0715 (198001-1), Pod / Stick Charger (DC10WB), Safety Goggles (195246-2),
Two NoseAdapter (424443-6), Hex Wrench 3 (783201-2), Hex Wrench 4 (783202-0), Short NailAdapter Set (346488-3),
Spark Plug (162326-9), Plastic Carrying Case (824990-1)
Makita's First Cordless Finishing Nailer
• Utilizes industry standard compact sized fuel cells
• Utilizes 7.2V (1.5Ah) Li-Ion Battery BL0715 with 35 minute charging time
• LED Warning System indicates low battery capacity or tool malfunction for quick identification on the jobsite
2-1/2" Cordless Finishing Nailer
SPECIFICATIONS
Battery Capacities
7.2V Li-Ion
Charging Time
30 Minutes
Battery Life
Approx. 4,000 Nails
Fuel Cell Life
Approx. 1,000 Nails
Nail Type
16 Ga. Straight
Driving Speed
Nails / sec. 2 - 3
Dimensions (L x W x H)
11-7/8" x 3-1/2" x 10-1/2"
(303 mm x 90 mm x 267 mm)
Net Weight
4.8 lbs (2.2 kg)
FG01
STANDARD EQUIPMENT INCLUDES:
Two 7.2V Li-Ion Batteries
BL0715 (198001-1), Pod / Stick Charger (DC10WB)
Plastic Carrying Case (821512-8), Safety Goggles (195246-2), Hex Wrench 4 (783230-5), Spark Plug (162269-5)
Makita's First Cordless Concrete Nailer
• Utilizes industry standard fuel cells
• Utilizes 7.2V 1.5Ah Li-Ion Battery BL0715 with 35 minute charging time
• Slim nose design provides access into tight spaces including narrow metal channels as well as
maximum visibility during operation
• LED Warning System indicates low battery capacity or tool malfunction for quick identification
on the jobsite
• Tool-Less design for rapid clearing of nail jams
• Anti-dry fire mechanism prevents added wear on drive pin
• Rubber Housing Bumper protects tool and materials from damage and prevents slipping
on inclined surfaces
1-9/16" Cordless Concrete Nailer
SPECIFICATIONS
Battery Capacities
7.2V Li-Ion
Charging Time
30 Minutes
Battery Life
Approx. 4,000 Nails
Fuel Cell Life
Approx. 1,200 Nails
Nail Type
Straight / Plastic
Driving Speed
Nails / sec. 2 - 3
Dimensions (L x W x H)
12-3/8" x 4-1/4" x 15-3/8"
(315 mm x 108 mm x 390 mm)
Net Weight
7.9 lbs (3.6 kg)
GN01
FUEL POWEREDNAILERACCESSORIES
Description
Contents
For Model
Part No.
Fuel Cell
Approx. 1,200 nails
per fuel cell
GN01
GN900S 242080-2
Approx. 1,000 nails
per fuel cell
FG01
242090-9
Aerosol
Lubricating
Oil
100 mL
GN900S
FG01
242077-1
Aerosol
Cleaner
500 mL
242075-5
Cleaning
Kit
Includes: Aerosol
Cleaner, Lubricating Oil,
Cleaning Brush, Hex Key,
Cleaning Cloth in Cloth
Carrying Case
194852-0
COLLATEDCONCRETE PINS
Length Shank Diameter
Head Diameter
Grade
Coating
Box Quantity
For Model
Part No.
3/4"
0.102"
1/4"
Standard Galvanized
1,000 Pins
(100 Strips of 10)
+ 1 ea. 242080-2
Fuel Cell
GN01
196290-2
1"
196291-0
1-1/8"
196292-8
5/8"
0.122"
Premium Mechanical
Zinc Plated
196285-5
3/4"
196286-3
7/8"
196287-1
1"
196288-9
1-1/4"
196289-7
187
makita.ca
>
WHERE TOBUY
>
Buy ONLINE !
Ideal For Installing Drywall Track, Plywood Sheathing
or Plastic Wrap to Concrete
For Use With
1-9/16" Cordless
Concrete Nailer
GN01
