16 / 220
18V LXT
Outdoor Power Equipment
DUB361Z
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
Shoulder Harness (166095-4), Long Nozzle (452123-4)
More Power From Makita's 18Vx2 Battery Platform
• eXtreme Protection Technology (XPT) offers maximum protection against dust,
debris and liquids for
• Optimal performance in extreme conditions
• Battery capacity warning light indicates ideal
time to recharge battery
• Low noise level suitable for use in residential
areas and public spaces
• Push button air volume selection
(low / high settings)
• Long blowing nozzle with curved tip
for optimal blowing performance
• Shoulder belt for operator
convenience
Blower
SPECIFICATIONS
Battery Capacities
Two 18V Li-Ion
Maximum Air Volume:
High
155 CFM (4.4 m
3
/min)
Low
92 CFM (2.6 m
3
/min)
Maximum Air Velocity:
High
208 MPH (93 m/sec)
Low
128 MPH (57 m/sec)
No Load Speed:
High
17,000 RPM
Low
10,000 RPM
Overall Length
35-5/8" (90 cm)
Net Weight
4.2 lbs (1.9 kg)
DUH523SF
STANDARD EQUIPMENT INCLUDES:
DUH523SF:
18V (3.0Ah) Li-Ion Battery
BL1830B (194205-3), Standard Charger (DC18SD), Shear Blade Complete Set (195846-8),
Blade Cover (453723-3)
DUH523Z:
Tool Only. Batteries and Charger Sold Separately.
Blade Cover (453723-3), Shear Blade Complete Set (195846-8)
Designed for Maximum Versatility and Ease of Operation
• Battery Protection System provides Over-Discharge, Temperature and Current Protection
for enhanced performance, battery cycle life and overall battery life
• Anti-Vibration Structure features five cushions linking handle and motor sections for significantly
reduced vibration transmission to operator
• Non-Electrolyzed Nickel Plated Blades reduce
staining and rusting
• Tool-less Blade Changing System
enables simple and easy blade changes
• Ergonomic Soft Rubber Grip design for
vibration absorption and comfortable
operation
22" Hedge Trimmer
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Strokes Per Minute (min-1)
1,350 SPM
Cutting Length
22" (560 mm)
Maximum Cutting Thickness
15/32" (12 mm)
Overall Length
38" (96 cm)
Net Weight
6.0 lbs (2.7 kg)
Dual Blade Action
DUH523Z
DUB362Z
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
Front Nozzle (455914-2), Long Nozzle (455915-0)
Our Most Powerful Cordless Blower Yet!
Amazing 120 MPH and 473 CFM Operation
• Powered by two 18V Li-ion batteries in series to supply energy to the powerful 36V DC motor drive system
• 6-stage air volume/velocity settings by dial with variable speed control by trigger
• The trigger also has a lock on function, with button operable from either side of handle
• 3-stage telescopic long nozzle with adjustment range of 4" (100 mm)
• Dual LED charge level indicators display
approximate remaining battery power
• Best grip to frame angle provides optimum
nozzle to ground angle for efficient
sweeping operation
• Lightweight & compact for single
handed operation
• Longer run time thanks to
brushless motor
Turbo Blower
SPECIFICATIONS
Battery Capacities
Two 18V Li-Ion
Max. Air Volume 473 CFM (13.4 m
3
/min)
Max. Air Velocity 120 MPH (54 m/sec)
No Load Speed
22,000 RPM
Overall Length 32-3/4", 34-3/4", 36-5/8"
(830 mm, 880 mm, 930 mm)
Net Weight
6.0 lbs (2.7 kg)
14
Cordless
Benchtop
Saws
Woodworking
Hammers
Dust
Extraction
Drills
Metalworking
Pneumatic
OPE
Manufacturing
And Assembly
DUH602Z
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
Shear BladeAssembly Set (199101-0), Blade Cover (459121-9), Safety Goggles (195246-2)
Reduced Noise And Emissions Versus Competitive Gas Models
• eXtreme Protection Technology (XPT) offers maximum protection against dust, debris and liquids for
optimal performance in extreme conditions
• Electric brake stops blade 3-5 seconds after trigger is released
for increased operator safety
• Battery capacity warning light indicates
approximate remaining battery power
• 5 position rotating rear handle with positive stops
at 0°, 45° and 90° enables optimal positioning
when cutting vertical or angled hedges
• 3 speed selection switch plus variable speed
trigger to tailor the tool to the trimming needs
• Reverse button function for freeing
the blade if it happens to jam
• Dual blade action cuts quickly
with shearing effect
23-5/8" Hedge Trimmer
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Strokes Per Minute (min-1)
0 - 2,000 / 0 - 3,600 / 0 - 4,400 SPM
Cutting Length
23-5/8" (600 mm)
Maximum Cutting Thickness
7/8" (21.5 mm)
Overall Length
43-3/4" (111.3 cm)
Net Weight
7.8 lbs (3.5 kg)
Dual Blade Action
makita.ca
>
WHERE TOBUY
>
Buy INASTORE !
Visit us online
>
makita.ca
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
Shear BladeAssembly Set (196689-1), Blade Cover (450490-1)
Reduced Noise And Emissions Versus
Competitive Gas Models
• Accepts two 18V Li-Ion batteries without a battery converter for use with
existing 18V Li-Ion battery platform
• eXtreme Protection Technology (XPT) offers maximum protection against dust, debris and liquids
for optimal performance in extreme conditions
• Electric brake stops blade 3-5 seconds after trigger is
released for increased operator safety
• Battery capacity warning light indicates
approximate remaining battery power
• 5 position rotating rear handle with
positive stops at 0°, 45° and 90°
enables optimal positioning when
cutting vertical or angled hedges
25-1/2" Hedge Trimmer
SPECIFICATIONS
Battery Capacities
Two 18V Li-Ion
Strokes Per Minute (min-1)
1,000 - 1,800 SPM
Cutting Length
25-1/2" (650 mm)
Maximum Cutting Thickness
11/16" (18 mm)
Overall Length
48-1/2" (123 cm)
Net Weight
8.9 lbs (4.0 kg)
DUH651Z
Dual Blade Action
DUB183SF (With Long Nozzle)
DUB183Z (With Long Nozzle)
DUB182Z (With Short Nozzle)
STANDARD EQUIPMENT INCLUDES:
DUB183SF:
18V (3.0Ah) Li-Ion Battery
BL1830B (194205-3), Standard Charger (DC18SD), Long Nozzle (TP00000199)
DUB183Z:
Tool Only. Batteries and Charger Sold Separately.
Long Nozzle (TP00000199)
DUB182Z:
Tool Only. Batteries and Charger Sold Separately.
NozzleAssembly (132025-7), Dust Bag (122814-8)
Unique Extended Nozzle Design for Optimum Operation
• Unique Extended Nozzle Design for Optimum Operation directs Air Flow Angle for Blowing / Sweeping
Debris, Grass Clipping, Leaves etc. from Driveway's, Sidewalks and more.
• Low / Medium / High Air Volume Settings with Variable Speed Control within Each Setting
• Ergonomic Soft Rubber Grip design for Vibration Absorption and Comfortable Operation
Blowers / Vacuums
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Maximum Air Volume 92 CFM (2.6 m
3
/min)
Maximum Air Velocity:
With Long Nozzle 116 MPH (52 m/sec)
With Short Nozzle 179 MPH (80 m/sec)
No Load Speed
0 - 18,000 RPM
Overall Length:
With Long Nozzle 33-1/4" (845 mm)
With Short Nozzle 20-3/4" (525 mm)
Net Weight
2.9 lbs (1.3 kg)
Optional Long Nozzle
Sold Separately
(Part No. TP00000199)
DUB183SF
DUB182Z
