20 / 220
18V LXT
Cleaning Tools
See pages 20-23 for our
FULL LINE
of
VacuumCleaner Accessories
MAXIMUMAIR FLOW
The
AMOUNT
of air being drawn in by the turbine. Typically measured in cubic feet per minute (CFM)
DCL182Z
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
Floor Nozzle (123488-8), Sash Nozzle (451243-1), Pipe (451244-9),
Sash Nozzle Holder (451245-7), Paper Filter (5 / Pk) (194566-1)
Lightweight And Portable Vacuum Cleaner For Shop, Office Or Home Use
• Push Button Air Volume Selection (Low / High Settings)
• Front Cover opens with push button for easier access
• On board sash nozzle storage
• Floor nozzle swivel joint for easier maneuverability
• Ergonomic Soft Rubber Grip design for vibration
absorption and comfortable operation
330 ml Vacuum Cleaner
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Container Capacity:
500 ml Dust Bag
330 ml Paper Bag
Continuous Use with 18V (5.0 Ah) Battery:
Approx. 33 minutes (High)
Approx. 66 minutes (Low)
Maximum Air Flow
35 CFM
Power:
30 W (High) / 11 W (Low)
Static Water Lift
15-3/4" (400 mm)
Overall Length
39-1/2" (100 cm)
Net Weight
2.0 lbs (0.9 kg)
DCL501Z
250 ml Cyclone Vacuum Cleaner
Portable Cyclone Vacuum Cleaner With Longer Run Time And
Increased HEPA Filtration Efficiency
• HEPA filter certified to 99.97% efficiency (0.03% max. permeability) at 0.3 - 05 microns (μ)
• Longer run time minimizes downtime required to switch or charge batteries for maximum performance
• Removable cyclonic dust canister separates coarse and fine dust to ensure expelled air is virtually dust free
• Filter offers maximum performance for residential and commercial applications
• Filter cleaning feature clears particulate and debris from clogged filter to maximize efficiency and
maintain suction power
• Brushless DC motor with high
power to weight and size ratio
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Container Capacity
250 ml
Continuous Use with 18V (5.0 Ah) Battery:
Approx. 29 minutes (High)
Approx. 64 minutes (Low)
Maximum Air Flow
46 CFM
Power:
75 W (High) / 25 W (Low)
Static Water Lift
26" (660 mm)
Overall Length
12-5/8" (322 mm)
Net Weight
6.0 lbs (2.7 kg)
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
HEPAFilter (SH00000286), 4´ Suction Hose (SH00000034), Floor Nozzle
(SH00000058), 2´To 2-1/2´Telescopic Straight Pipe (SH00000060), Hose Hook (SH00000041), 12˝Turbine Crevice Nozzle (SH00000042),
Shoulder Harness (166124-3), Internal Cleaning Brush (SH00000032)
DCL282FZ
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
Floor Nozzle (123488-8), Sash Nozzle (451243-1), Pipe (459356-2),
Paper Filter (5 / Pk) (194566-1), Sash Nozzle Holder (459355-4)
Lightweight And Portable Vacuum Cleaner For Professional Use, Office Or
Home Use / One Touch Push Button Switch
• Enhanced motor durability equipped with BL motor and improved
dust-resistant performance
• 3-speed change button
• Pipe is fixed by the locking mechanism to prevent it from
accidentally coming off
• On board sash nozzle storage
• Angled suction port enables cleaning without floor
nozzle and prevents extension pipes from
wobbling during operation
330 ml Vacuum Cleaner
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Container Capacity 330 ml (Paper Bag)
Continuous Use with 18V (5.0 Ah) Battery:
Approx. 13 minutes (Max)
Approx. 17 minutes (High)
Approx. 42 minutes (Low)
Maximum Air Flow
53 CFM
Power:
60 W (Max) 45 W (High) / 15 W (Low)
Static Water Lift
33" (840 mm)
Overall Length
40" (102 cm)
Net Weight
2.0 lbs (0.9 kg)
18
Cordless
Benchtop
Saws
Woodworking
Hammers
Dust
Extraction
Drills
Metalworking
Pneumatic
OPE
Manufacturing
And Assembly
DVC350Z
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold
Separately.
Blower Nozzle (132025-7),
Dust Bag (122918-6), 1-1/8" x 8' Hose
With Front Cuff 22 (140456-6),
Shoulder Harness (166094-6),
Front Cuff 38 (195545-2)
Portable & Versatile Vacuum Cleaner
• Push Button Air Volume Selection
(High / Low Settings)
• Shoulder Strap for operator convenience
• Can be converted into a blower by attaching
nozzle assembly
3.0 L Vacuum Cleaner
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Container Capacity
3.0 L
Continuous Use with 18V (5.0 Ah) Battery:
Approx. 21 minutes (High)
Approx. 42 minutes (Low)
Maximum Air Flow
120 CFM
Maximum Air Speed 308 ft./s (94 m/s)
Power:
50 W (High) / 15 W (Low)
Static Water Lift
22" (560 mm)
Overall Length
15-7/8" (403 mm)
Net Weight
3.5 lbs (1.6 kg)
Includes
Powerful
Blower
Feature
DCL180RFB DCL180ZB DCL180ZX
STANDARD EQUIPMENT INCLUDES:
DCL180RFB (BLACK):
18V (3.0Ah) Li-Ion Battery
BL1830B (194205-3), Rapid Charger (DC18RC), Floor Nozzle (123539-7),
Sash Nozzle (456586-6), Pipe (456587-4), Sash Nozzle Holder (456585-8), High Efficiency Filter (198752-6)
DCL180ZB (BLACK):
Tool Only. Batteries and Charger Sold Separately.
Floor Nozzle (123539-7), Sash Nozzle (456586-6),
Pipe (456587-4), Sash Nozzle Holder (456585-8), High Efficiency Filter (198752-6)
DCL180ZX
(TEAL)
:
Tool Only. Batteries and Charger Sold Separately.
Floor Nozzle (123488-8), Sash Nozzle (451243-1),
Pipe (451244-9), Sash Nozzle Holder (451245-7), High Efficiency Filter (198752-6)
Lightweight And Portable Vacuum Cleaner For Professional Use, Office Or Home Use
• Easy to empty see-through dust canister minimizes downtime and maximizes
vacuuming efficiency
• High Performance Filter
• On board sash nozzle storage
• Angled suction port enables cleaning without floor nozzle and prevents
extension pipes from wobbling during operation
650 ml Vacuum Cleaners
DCL180RFB
DCL180ZX
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Container Capacity
650 ml
Continuous Use with 18V (5.0 Ah) Battery
Approx. 33 minutes
Maximum Air Flow
46 CFM
Power
30 W
Static Water Lift
14-1/2" (379 mm)
Overall Length
39-5/16" (999 cm)
Net Weight
1.4 lbs (0.6 kg)
DCL181FXRF DCL181FZX DCL181FZWX
STANDARD EQUIPMENT INCLUDES:
DCL181FXRF
(TEAL)
:
18V (3.0Ah) Li-Ion Battery
BL1830B (194205-3), Rapid Charger (DC18RC), Battery Cover (450128-8),
Floor Nozzle (123488-8), Sash Nozzle (451243-1), Pipe (451244-9), Sash Nozzle Holder (451245-7), High Efficiency Filter (198752-6)
DCL181FZX
(TEAL)
:
Tool Only. Batteries and Charger Sold Separately.
Floor Nozzle (123488-8), Sash Nozzle (451243-1),
Pipe (451244-9), Sash Nozzle Holder (451245-7), High Efficiency Filter (198752-6)
DCL181FZWX (WHITE):
Tool Only. Batteries and Charger Sold Separately.
Floor Nozzle (123486-2), Sash Nozzle (451240-7),
Pipe (451241-5), Sash Nozzle Holder (451242-3), High Efficiency Filter (198752-6)
Lightweight And Portable Vacuum Cleaner For Professional Use, Office Or Home Use
• Easy to empty see-through dust canister minimizes downtime and maximizes
vacuuming efficiency (DCL181FXRF & DCL181FZX only)
• High Performance Filter
• On board sash nozzle storage
• Angled suction port enables cleaning without floor nozzle and prevents
extension pipes from wobbling during operation
650 ml Vacuum Cleaners
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Container Capacity
650 ml
Continuous Use with 18V (5.0 Ah) Battery
Approx. 33 minutes (High)
Approx. 66 minutes (Low)
Maximum Air Flow
49 CFM
Power
30 W (High) / 11 W (Low)
Static Water Lift
17" (430 mm)
Overall Length
39-5/16" (999 cm)
Net Weight
1.8 lbs (0.6 kg)
DCL181FXRF
DCL181FZWX
2
Speed
2
Speed
3
Speed
2
Speed
2
Speed
