12 / 220
18V LXT
Outdoor Power Equipment
DUC302Z
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
12" Chain (196740-7), 12" Guide Bar (165245-8), Chain Cover (419288-5), Spike Bumper Set (197820-2)
18Vx2 Handle Mount Battery Position
• eXtreme Protection Technology (XPT) offers maximum protection against
dust, debris and liquids for optimal performance in extreme conditions
• Battery capacity warning light indicates ideal time to recharge battery
• Lock-off button prevents accidental startup
• Inertia chain brake provides maximum operator safety if kickback occurs
• Tool-less chain tension adjustment for quick and easy adjustment on the jobsite
• Automatic chain oiler
• Metal lanyard hook enables quick attachment to lanyard during climbing or bucket operations
12" Chainsaw
SPECIFICATIONS
Battery Capacities
Two 18V Li-Ion
Guide Bar Length
12" (300 mm)
Chain Pitch / Gauge
3/8" / 0.043"
Chain Speed
1,650 FPM (500 m/min)
Overall Length
23-5/8" (600 mm)
Net Weight
7.7 lbs (3.5 kg)
Features Extreme Protection Technology (XPT™) to provide increased dust and water resistance in harsh job site conditions
• Delivers up to 60 minutes of run time under load using one 18V LXT (6.0 Ah) BL1860 battery
• Holds (2) 18V LXT Lithium-Ion batteries but operates using (1) 18V battery at a time; utilizes second battery when needed
• Makita-built BL™ Brushless Motor for optimal performance
• 2-speed with maximum speed up to 2.5 MPH on a 12º incline
• Maximum load capacity up to 287 lbs (130 kg)
• 7" mechanical disc brake for faster stopping
• Rear wheel spacing is adjustable from 19" to 30" to accommodate the work environment
• L-shaped legs can be easily installed to replace rear wheels
• L.E.D. lights on each side of frame to illuminate the work area
DCU180ZX1, DCU180ZX2
Power-Assisted Wheelbarrows
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Maximum Speed:
Forward, High / Low
0 - 3.5 km/h / 0 - 1.5 km/h
Reverse
0 - 1.0 km/h
Minimum Turning Radius
(Outer diameter when turning with front wheel as axis) 110 cm
Maximum Climbing Capacity
12°
Maximum Load Capacity
287 lbs (130 kg)
DCU180ZX1:
Overall Dimensions (L x W x H)
61-1/2" x 41-3/4" x 35-1/2" (156 cm x 106 cm x 90 cm)
Net Weight
97.5 lbs (44.2 kg)
DCU180ZX2:
Overall Dimensions (L x W x H)
51-1/2" x 31-1/8" x 35-1/2" (131 cm x 79 cm x 90 cm)
Net Weight
86 lbs (39 kg)
Convenient
solution for
material
transport
on job sites
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and
Charger Sold Separately.
Support Foot (2 Ea. 144675-6),
Key (643890-4),
Wrench 13 (2 Ea. 781006-4),
Bucket (198494-2)
DCU180ZX2
with Bucket
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
Support Foot (2 Ea. 144675-6), Key (643890-4),
Wrench 13 (2 Ea. 781006-4), FlatbedTray (199116-7)
DCU180ZX1
with Flatbed Tray
18V x2 LXT POWER-ASSISTED
WHEELBARROWACCESSORIES
FLATBED TRAY
199116-7
BUCKET
198494-2
Description
• Easy four bolt installation and removal
• Side rails install in up or down position;
large knob for easy adjustment
• Ideal for loading heavy duty bulky
material such as bricks, concrete
bags and more
• For use with Makita Power Assisted
Wheelbarrow model DCU180Z
•
INCLUDES:
Flatbed Tray
• Easy four bolt installation
and removal
• Heavy duty steel based bucket
for tough workloads
• Ideal for transporting material
on job sites
• For use with Makita Power Assisted
Wheelbarrow model DCU180Z
•
INCLUDES:
Bucket
10
Cordless
Benchtop
Saws
Woodworking
Hammers
Dust
Extraction
Drills
Metalworking
Pneumatic
OPE
Manufacturing
And Assembly
makita.ca
>
WHERE TOBUY
>
Buy INASTORE !
16" / 18Vx2 LXT Cordless Chainsaws with
Specialized Battery Positioning for Optimum Balance and Control
• Fast, Variable Speed (3,940 Feet Per Minute) Equivalent to a 30cc Gasoline Chainsaw
• Specialized 18Vx2 Battery Positioning is the Makita Industry Game Changer within the Cordless Product line
offering Premium Balance, Control and Cutting Performance
• Makita Built Outer Rotor Brushless Motor Direct Drive System for High Power & Speed
• Variable Speed Trigger Switch (0 - 3,940 FPM) operates the same as a Gasoline Chainsaw
• Built-in LED On / /Off Switch with Auto Power-Off function; for Extended Battery Life
• Front Hand Guard Chain Brake for Operator Safety in case of Accidental Kickback
• Low Noise Level at only 87.7 dB(A) and Zero Emissions
for Operator Comfort
DUC405Z, DUC400Z
16" Chainsaws
SPECIFICATIONS
Battery Capacities
Two 18V Li-Ion
Guide Bar Length
16" (400 mm)
Chain Pitch / Gauge
3/8" / 0.043"
Chain Speed
0-3,940 FPM (0-1 200 m/min)
DUC405Z:
Overall Length
31-1/2" (800 mm)
Net Weight
9.0 lbs (4.1 kg)
DUC400Z:
Overall Length
32-1/4" (818 mm)
Net Weight
9.3 lbs (4.2 kg)
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
16" Chain (196742-3),
16" Guide Bar (165247-4), Chain Cover (419242-9), Spike Bumper (347078-5),
Box Wrench (782027-9), Oil Supply (182229-1)
DUC405Z
with Captive Bar Nuts
Brushless
Motor + XPT +
3 Year Limited
Warranty
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
16" Chain (196742-3), 16" Guide Bar (165247-4), Chain Cover
(419242-9), Oil Supply (182229-1), Spike Bumper (347078-5)
DUC400Z
with Toolless Chain
Tension Adjustment
