18V LXT Metalworking Tools
40
Cordless
Benchtop
Saws
Woodworking
Hammers
Dust
Extraction
Drills
Metalworking
Pneumatic
OPE
Manufacturing And Assembly
Makita offers a wide variety of ACCESSORIES!
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately. Two Wrenches 13 (781039-9), 1/4˝ Collet Cone (763673-7),
Collet Nut (763668-0)
Compact And Lightweight Die Grinder
• Anti-Restart feature prevents accidental start up of tool during battery changing when switch is
locked in the on position
• Low Battery Capacity Light indicates ideal time to recharge battery
• Vent Slots direct exhaust towards opposite side of operator
• Easy to Grip Motor Housing for easier handling
• Ergonomic Soft Rubber Grip design
for vibration absorption and
comfortable operation
1/4˝ Die Grinder
SPECIFICATIONS
Battery Capacities 18V Li-Ion
Collet Capacity 1/4˝ (6.35 mm)
Maximum Wheel Diameter 1-7/16˝ (36 mm)
No Load Speed 26,000 RPM
Overall Length 15-3/4˝ (402 mm)
Net Weight 4.4 lbs (2.0 kg)
DGD800Z
DJS101Z
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately. Hex Wrench 3 (783201-2), Side Blade Set (792536-0), Center Blade (792537-8)
In-Line Design Allows For Better Control And Excellent Maneuverability
• Anti-restart feature prevents accidental start up of tool during battery changing when switch is
locked in the on position
• Battery capacity warning light indicates ideal time to recharge battery
• Electronic current limiter with warning light prevents motor burnout caused by overloading
• Adjustable blade set minimizes burring for various thicknesses of material
• Small circumference, ergonomic soft rubber grip design for vibration absorption and
comfortable operation
• In-line design allows for better control
and excellent maneuverability
20 ga Straight Shear
SPECIFICATIONS
Battery Capacities 18V Li-Ion
Capacities:
Steel 20 gauge (1.0 mm)
Stainless 23 gauge (0.7 mm)
No Load Speed 4,300 SPM
Minimum Cutting Radius 1-3/16˝ (30 mm)
Overall Length 14-3/8˝ (364 mm)
Net Weight 3.1 lbs (1.4 kg)
DJS161Z
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately. Thickness Gauge (762013-6), Hex Wrench 3 (783201-2), Side Blade Set (792533-6),
Center Blade (792534-4)
In-Line Design Allows For Better Control And Excellent Maneuverability
• Battery capacity warning light indicates ideal time to recharge battery
• Anti-restart feature prevents accidental start up of tool during battery changing when switch is locked
in the on position
• Electronic current limiter with warning light prevents motor burnout caused by overloading
• Adjustable blade set minimizes burring for various thicknesses of material
• Small circumference, ergonomic soft rubber
grip design for vibration absorption and
comfortable operation
16 ga Straight Shear
SPECIFICATIONS
Battery Capacities 18V Li-Ion
Capacities:
Steel 16 gauge (1.6 mm)
Stainless 18 gauge (1.2 mm)
No Load Speed 4,300 SPM
Minimum Cutting Radius 9-7/8˝ (250 mm)
Overall Length 14-1/4˝ (362 mm)
Net Weight 3.1 lbs (1.4 kg)
DJN161Z
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately. Wrench 32 (781028-4), Hex Wrench 2.5 (783208-8),
Die (A-15051), Punch (A-83951)
Optimal Size And Maneuverability For Cutting Keystone Plate,
Deck Plate, Metal Roofing And Other Corrugated Sheet Materials
• Battery Capacity Warning Light indicates ideal time to recharge battery
• Anti-Restart feature prevents accidental start up of tool during battery changing when switch is
locked in the on position
• Die rotates 360° with positive stops at 0°, 90° Left, 90° Right and 180° for simple and accurate
adjustment on the jobsite
• Built-in thickness gauge for
operator convenience
• Easy punch and die
replacement for less
down time
16 ga Nibblers
SPECIFICATIONS
Battery Capacities 18V Li-Ion
Maximum Capacities:
Mild Steel 16 gauge (1.6 mm)
Stainless 18 gauge (1.2 mm)
Aluminum 12 gauge (2.5 mm)
Strokes Per Minute 1,900 SPM
Minimum Cutting Radius:
Outside Edge 2˝ (50 mm)
Inside Edge 1-3/4˝ (45 mm)
Overall Length 12-3/8˝ (313 mm)
Net Weight 4.8 lbs (2.2 kg)
DJS130Z
STANDARD EQUIPMENT INCLUDES:
ToolOnly.BatteriesandChargerSoldSeparately. Hook(281220-7),HexWrench4(783202-0),ShearHeadAssembly(125849-8)
Shear Head Attachment Rotates 360° For Optimum Maneuverability
• Compact and Lightweight (Overall Length 13-3/4˝)
• Lock-Off Button prevents accidental engagement of trigger
• On Board Hex Wrench Storage
• Belt Clip for operator convenience
• Ergonomic Soft Rubber Grip design for
vibration absorption and
comfortable operation
18 ga Straight Shear
SPECIFICATIONS
Battery Capacities 18V Li-Ion
Capacities:
Steel 18 gauge (1.3 mm)
Stainless 20 gauge (1 mm)
No Load Speed 3,000 SPM
Overall Length 13-3/4˝ (350 mm)
Net Weight 5.3 lbs (2.4 kg)
STANDARD EQUIPMENT INCLUDES:
ToolOnly.BatteriesandChargerSoldSeparately.
OuterSleeve20-37(764361-9),InnerSleeve(764419-4),
OuterSleeve22-39(153909-6),InnerSleeve(764418-6),
Screwdriver(783001-0),ShoulderBelt(161347-8),
PlasticCarryingCase(821748-9)
Tightens up to 380 M22 torque control bolts per charge
using two 18V (6.0 Ah) Li-Ion Batteries!
• eXtreme Protection Technology (XPT) offers maximum protection against dust, debris and liquids for
optimal performance in extreme conditions
• Brushless DC motor with high power to weight and size ratio
• LED battery capacity warning lamp warns operator when the number of bolts that can be tightened is less
than 10 and when the battery is fully drained
• Cast aluminum gear housing to withstand high torque levels of planetary gears (804 Nm)
• Trigger lock-off feature prevents accidental start-up for increased operator safety
• Easy to grip D-handle
Electric
Brake
Shear Wrench
SPECIFICATIONS
Battery Capacities Two 18V Li-Ion
Capacities: 5/8˝ (M16), 3/4˝ (M20), 7/8˝ (M22)
No Load Speed 14 RPM
Fastening Torque 593 ft. /lbs (804 Nm)
Overall Height 14-7/8˝ (377 mm)
Overall Length 11-5/8˝ (296 mm)
Net Weight 12.8 lbs (5.8 kg)
DWT310ZK
