General Catalogue

39 / 212

18V LXT Woodworking Tools / Metalworking Tools
37
Cordless
Benchtop
Saws
Woodworking
Hammers
Dust
Extraction
Drills
Metalworking
Pneumatic
OPE
ManufacturingAnd Assembly
When QUALITY & SERVICE Counts – Choose Makita
DCG180RFEC
STANDARD EQUIPMENT INCLUDES:
DCG180RFEC: Two18V(3.0Ah)Li-IonBatteries BL1830B
(194205-3),RapidCharger(DC18RC),BatteryCover(450128-8),
SafetyGoggles(195246-2),ToolBag(831278-2)
DCG180ZC: Tool Only. Batteries and Charger Sold Separately.
Safety Goggle (195246-2),Tool Bag (831278-2)
Ideal For Quick and Precise Application of Caulking and Sealants
Accepts Standard 800 ml Cartridges
• Anti-drip function eliminates residual pressure on caulking tube to prevent caulking from escaping
when the trigger is released
• Variable speed dial allows operator to set maximum dispensing speed while the variable speed trigger
enables fine adjustment for maximum control and precision in a wide range of applications
• 360 °rotating tube tray allows
operator to adjust positioning
based on materials or
application
• Overload protection feature
with warning light prevents
motor burnout caused by
overloading
800 ml Caulking Gun
SPECIFICATIONS
Battery Capacities 18V Li-Ion
Max. Pushing Force 1,100 lb (5,000 N)
Compatible Sealant Size:
800 ml Cartridge, Sausage Pack
Dimensions (L x W x H)
18-7/8" x 4-1/4" x 11-1/8"
(480 mm x 108 mm x 281 mm)
Net Weight 4.6 lbs (2.1 kg)
DCG180RFE DCG180Z
STANDARD EQUIPMENT INCLUDES:
DCG180RFE: Two18V(3.0Ah)Li-IonBatteriesBL1830B
(194205-3),RapidCharger(DC18RC),BatteryCover(450128-8),
SafetyGoggle(195246-2),ToolBag(831278-2)
DCG180Z: Tool Only. Batteries and Charger Sold Separately.
Safety Goggle (195246-2),Tool Bag (831278-2)
Ideal For Quick and Precise Application of Caulking and Sealants
Accepts Standard 300 ml Cartridges
• Anti-drip function eliminates residual pressure on caulking tube to prevent caulking from escaping
when the trigger is released
• Variable speed dial allows operator to set maximum dispensing speed while the variable speed trigger
enables fine adjustment for maximum control and precision in a wide range of applications
• 360 °rotating tube tray allows
operator to adjust positioning
based on materials or application
• Overload protection feature with
warning light prevents motor
burnout caused by overloading
300 ml Caulking Gun
SPECIFICATIONS
Battery Capacities 18V Li-Ion
Max. Pushing Force 1,100 lb (5,000 N)
Compatible Sealant Size
300 ml Cartridge
Dimensions (L x W x H)
15-7/8˝ x 4-1/4˝ x 11-1/8˝
(404 mm x 108 mm x 281 mm)
Net Weight 4.8 lbs (2.2 kg)
Anti-Drip Function,
Variable Speed
Anti-Drip Function,
Variable Speed
DCG180ZC
DBN600Z
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately. Two NoseAdapters (424443-6), Safety Goggles (195246-2), Hook (346449-3)
Bump & Sequential Fire Operating Modes
• Anti-dry fire mechanism prevents added wear on the drive pin
• Rubber bumpers protect tool and materials from damage
• Quick release toolless nose enables easy clearing of jammed nails
• Nail view window enables fast identification of remaining nail capacity
• Trigger lock-off feature prevents accidental firing for increased operator safety
• Compact center height for easy use when working in tight spaces and corners
• Battery protection system provides over-discharge, temperature and current protection for enhanced
performance, battery cycle life and overall battery life
• LED job light illuminates work area
• On-board nail depth adjustment dial for quick
and easy adjustment
16 ga Finishing Nailer
SPECIFICATIONS
Battery Capacities 18V Li-Ion
Magazine Capacities 100 nails
Gauge 16 ga
Nail Length 1" - 2-1/2" (25 mm - 64 mm)
Overall Length 11-5/8" (296 mm)
Net Weight 6.9 lbs (3.1 kg)
DCG180RFEB DCG180ZB
STANDARD EQUIPMENT INCLUDES:
DCG180RFEB: Two 18V (3.0Ah) Li-Ion Batteries BL1830B (194205-3),
Rapid Charger (DC18RC), Battery Cover (450128-8), Nozzle (454226-0),
Rubber Ring (424547-4), PistonA(142071-2), Piston C (123221-8),
Screw (266827-0), Safety Goggle (195246-2),Tool Bag (831278-2)
DCG180ZB: Tool Only. Batteries and Charger Sold Separately.
Nozzle (454226-0), Rubber Ring (424547-4), PistonA(142071-2), Piston C (123221-8),
Screw (266827-0), Safety Goggle (195246-2),Tool Bag (831278-2)
Ideal For Quick and Precise
Application of Caulking and Sealants
Accepts Standard 600 ml Cartridges, Sausage Packs
and Bulk Caulking or Sealants
• Anti-drip function eliminates residual pressure on
caulking tube to prevent caulking from escaping
when the trigger is released
• Variable speed dial allows operator to set
maximum dispensing speed while the variable
speed trigger enables fine adjustment for maximum
control and precision in a wide range of applications
600 ml Caulking Gun
SPECIFICATIONS
Battery Capacities 18V Li-Ion
Max. Pushing Force 1,100 lb (5,000 N)
Compatible Sealant Size: 600 ml Cartridge
Sausage Pack, Bulk Sealant
Dimensions (L x W x H)
21-1/4˝ x 4-1/4˝ x 11-1/8˝
(538 mm x 108 mm x 281 mm)
Net Weight 5.9 lbs (2.7 kg)
Anti-Drip Function, Variable Speed
Auto-Start Wireless System (AWS) Technology Features
Wireless Dust Collection Technology!
• AWS (Auto-Start Wireless System) uses Bluetooth® technology to communicate between tool and
vacuum and enable wireless control when used with Makita AWS cordless tools
• Automatic torque Drive Technology (ADT) adjusts the torque and speed according to the load condition,
enabling rapid movement between high speed and high torque applications
• eXtreme Protection Technology (XPT) offers maximum protection against dust, debris and liquids
for optimal performance in extreme conditions
9˝ Angle Grinder with AWS
SPECIFICATIONS
Battery Capacities Two 18V Li-Ion
Grinding Wheel 9˝ (230 mm)
No Load Speed 6,000 RPM
Arbor Size 5/8˝ - 11 UNC
Overall Length 19-5/8˝ (499 mm)
Net Weight 9.9 lbs (4.5 kg)
DGA901Z
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately. Toolless Wheel Cover (123543-6), Side Handle (143486-6),
Lock Nut Wrench 28 (782412-6), Inner Flange (224500-8), Lock Nut 5/8"-45 (224486-6)
Two-Stage Safety
Paddle Switch,
Electric Brake
Bluetooth® is a registered
trademark of Bluetooth® SIG
Auto-Start Wireless System
(AWS) Technology!
DGA901Z
