8 / 40
• Heavy Duty Cartridge Filter System
designed for Extended Filter Life and
Less Maintenance
• Steel Spring / Advanced Vibration
Dampening System is engineered for
reducing vibration
• Bar & Chain Fasteners remain fixed to
cover when loosened
• Easy Remove Air Filter and Spark Plug
Cover for quick maintenance access
• Steel Spring / Advanced Vibration
Dampening System is engineered for
reducing vibration
• Dual Mount, Aggressive Large Metal
Spike Bars for Safety and Hinge
Action Cutting
SAS + Easy start
+ Winter mode
SLR + Easy start
+ Winter mode
• Heavy Duty Cartridge Filter System
designed for Extended Filter Life and
Less Maintenance
• Steel Spring / Advanced Vibration
Dampening System is engineered for
reducing vibration
• Aggressive Large Metal Spike Bar for
Safety and Hinge Action Cutting
SAS + Easy start
+ Winter mode
• Easy Remove Air Filter and Spark Plug
Cover for quick maintenance access
• Steel Spring / Advanced Vibration
Dampening System is engineered for
reducing vibration
• Dual Mount, Aggressive Large Metal
Spike Bars for Safety and Hinge
Action Cutting
SLR + Decompression
Valve + Winter mode
55.6
CC
Chainsaw
EA5600FREE
50
CC
Chainsaw
DCS5121REJ
60.7
CC
Chainsaw
EA6100PRGE
72.6
CC
Chainsaw
EA7300PRFE
2-STROKE
POWER
CHAINSAWS
ACCESSORIES
Chainsaw Chain
Chainsaw Bar
18" Rescue Bar & Chain
(for EA7300PRFE)
Safety Helmet
(Complete)
Chainsaw Files (12 Pack)
SPECIFICATIONS EA7300PRFE EA6100PRGE EA5600FREE DCS5121REJ
Displacement
72.6 cc (4.4 cu.in.)
60.7 cc (3.7 cu.in.)
55.6 cc (3.4 cu.in.)
50 cc (3.1 cu.in.)
Chain Pitch / Gauge
3/8" / .058"
.325" / .058"
Maximum Engine Speed
12,800 RPM
13,800 RPM
Power Rating
4.0 kW / 5.4 hp
3.4 kW / 4.5 hp
3.0 kW / 3.9 hp
2.5 kW / 3.3 hp
Fuel Tank Capacity
750 ml
800 ml
570 ml
470 ml
Chain Oil Tank Capacity
420 ml
480 ml
320 ml
269 ml
Fuel / Oil Mixture
50:1 Synthetic
Net Weight Dry
Without Bar And Chain
13.8 lbs (6.3 kg)
13.2 lbs (6.0 kg)
12.8 lbs (5.8 kg)
12.1 lbs (5.4 kg)
All Makita
Gasoline Powered Chainsaws
now feature
20" Bar
18" Bar
18" Bar
21" Bar
6
