5 / 40
When QUALITY Counts - Choose Makita
Outdoor
Power Equipment
QUALITY & SERVICE Counts – Choose Makita
For 3.8 L / 1 Gallon Mix
(T-00745C) HP synthetic 2-Stroke oil
*For distributor:
(T-00745C-48) (48 Bottles / Case)
For 9.5 L / 2.5 Gallon Mix
(T-00739C) HP synthetic 2-Stroke oil
*For distributor:
( T-00739C-48) (48 Bottles / Case)
All 2-stroke Makita power cutters
require synthetic 2-cycle engine
oil with fuel stabilizer
•
NEW Scavenging Losses Rejection (SLR) muffler
recycles
exhaust unburnt gas emissions for increased operational
efficiency and cleaner emissions
•
Top mount decompression valve
reduces required
start up force by 70%
•
Advanced 5 stage air filtration system
for cleaner operation and enhanced engine life
14" 3D PREMIUM
Diamond Blade
Features 3D Diamond Grid
Technology incorporating even
placement of diamond content
throughout the segment
14" Metal Cutting
Diamond Blade
Ideal for cutting angle iron,
rebar, deck plating, steel studs,
pipe and more!
2-STROKE
POWER
SPECIFICATIONS
EK8100
EK7301
EK6101
Displacement
4.9 cu.in (81 cc)
4.5 cu.in (73 cc)
3.7 cu.in (60.7 cc)
Maximum Power
4.2 kW (5.6 hp)
3.8 kW (5.1 hp)
3.2 kW (4.4 hp)
Fuel / Oil Mixture
50:1 Synthetic
Ignition System
Electronic
Fuel Tank Capacity
1/3 Gal (1.1 L)
1/6 Gal (0.7 L)
No Load Speed (Engine)
9,350 RPM
9,400 RPM
9,850 RPM
Maximum Spindle Speed
3,820 RPM
4,300 RPM
4,400 RPM
Maximum Cutting Depth
5-3/4" (14.7 cm)
4-13/16" (12.2 cm)
5-1/8" (13 cm)
Dry Weight
23.4 lbs (10.6 kg)
22.5 lbs (10.2 kg)
19.6 lbs (8.9 kg)
See pages 30-31 for more
POWER CUTT R ACCESSORIES
DIAMOND BLADES
Premium Professional Performance
See page 30 for more details
• Stratified scavenging system to comply
with many exhaust emission regulations
• Rapid start pull force required to start the machine is
drastically reduced with spring-assisted recoil starter
0.2 L (200 ml) size ideal for use
with MM4 Power Cutters and
Backpack Blowers
(T-02484) (single bottle)
*For distributor: (T-02490) (12 Bottles / Case)
0.08 L (80 ml) size ideal for use
with MM4 Line Trimmers, Brush Cutters, Pole
Chain Saw, Hand Held Blowers and 1" Water Pump
(195826-4) (single bottle)
*For distributor: (195826-4-48) (48 Bottles / Case)
PREMIUM
4-STROKE ENGINE OIL
81
cc
Power Cutter
EK8100
73
cc
Power Cutter
EK7301
60
.
7cc
Power Cutter
EK6101
20 mm Arbor
20 mm Arbor
16" cutting
wheel
14" cutting
wheel
20 mm Arbor
14" cutting wheel
3
