6 / 40
ELECTRIC
POWER
makita.ca
ANGLE
CUTTERS
DIAMOND BLADES
Premium Professional Performance
•
Guide Wheels
on the tool guard ensure smooth
tool travel over surface material
•
Rubber Shield
protects the operators
hand and motor from debris
•
Lock-on Button
for continuous operation
•
Ball Bearing Construction
for longer tool life
•
Integrated Nozzle
can be connected to
vacuum system for clean operation
4114 / 4112H
ANGLE CUTTER
FEATURES & BENEFITS
SPECIFICATIONS 4114
4112H
Blade Diameter
14" (35.5 cm)
12" (30.5 cm)
Arbor
1" (2.5 cm)
Maximum Cutting
Depth
5" (12.5 cm)
3-15/16" (10 cm)
No Load Speed
3,800 RPM
5,000 RPM
AMPS (120V)
15.0 A
Overall Length
26-1/2" (67.3 cm)
25-1/2" (64.8 cm)
Net Weight
22.7 lbs (10.3 kg) 25.1 lbs (11.4 kg)
4114
Used To Cut Steel, Concrete And
Masonry Materials With A Dry Cutting
Diamond Blade
Angle Cutters
"SJS" technology prevents kickback
if blade jams protecting both the
operator and tool
Visit
makita.ca
for our full line of
ANGLE CUTTER ACCESSORIES
14" OPTIMUM™
DIAMOND BLADE
Turbo Rim
• Granite, Ceramic & Stone
• 5,400 RPM
• Material Type: Hard
• For 14" Angle Cutter 4114
12" OPTIMUM™
DIAMOND BLADE
Segmented Rim
• Concrete & Asphalt
• 6,300 RPM
• Material Type: Medium & Soft
• For 12" Angle Cutter 4112H
14" Blade Diameter
12" Blade Diameter
4112H
See page 30 for more details
4
