BHX2500CA
STANDARD EQUIPMENT INCLUDES:
BHX2500CA:
LongNozzle(125729-8),RoundEndNozzle(450966-8),ToolKit(194717-6),StarterRope(444019-3),SparkPlug(0650109950)
BHX2500CAV:
Long Nozzle (125729-8), Round End Nozzle (450966-8),Tool Kit (194717-6), Starter Rope (444019-3),
Spark Plug (0650109950), Vacuum Kit (197234-5)
Air Speed 145 MPH, Max. Air Volume 356 CFM
• Exceeds Government Clean Air Emission Ratings
• 4-Stroke, for low noise and low emission
• Quick-start - low compression engine
for easy starting
• Auto decompression for easy starting
• Easy access to spark plug and air filter
• Light weight design
Improved Fuel
Tank Coating Is
EPA Phase II
And CARB III
Compliant
24.5 cc 4-Stroke Blower
SPECIFICATIONS
Displacement
24.5 cc
Maximum Air Flow
145 MPH
Maximum Air Volume (End Of Nozzle)
356 CFM
Carburetor All Position Diaphragm Type
Fuel / Oil Mixture
Not Required
Power Rating
0.81 kW / 1.1 hp
Tank Capacity
520 ml
Overall Length
13-3/4˝ (350 mm)
Dry Weight
9.9 lbs (4.5 kg)
EB7660TH
STANDARD EQUIPMENT INCLUDES:
Long Pipe 90 (197723-0), End Nozzle 90-68 (197722-2), Flat Nozzle
90 (196911-6), Flexible Pipe (454934-3), Swivel Pipe (161653-1),
Box Wrench Set (196771-6), Swivel Pipe (161653-1), Box Wrench
Set (196771-6), Shoulder Harness L(161534-9), Shoulder
Harness R (161535-7), Hose Clamp (282025-8), Spark Plug
(168652-4), Starter Rope (444043-6),Accessory Bag (831304-7)
205 MPH Air Speed with
705 CFM Volume
• For the demanding professional. Now with more
power and air flow.
• 4 damper springs mounted between the engine and
the backpack frame reduce the vibration on the
back of operator even during long hours
• Cushioned back padding and shoulder straps,
in addition to being well-ventilated, aid in effective
sweat evaporation and to provide
more operator comfort
75.6 cc 4-Stroke Backpack Blower
BLOWER ACCESSORIES FOR EB5300TH / EB7660TH
Description
For Model No.
Part No.
Long Pipe
EB7650TH
454895-7
Short Pipe
455127-5
End Nozzle
454896-5
End Nozzle
455128-3
Flat Nozzle
454916-5
BLOWER ACCESSORIES FOR BHX2500CA
Description
For Model No.
Part No.
Straight Pipe #1
BHX2500CA
455462-1
Straight Pipe #2
454188-2
Pipe #3
454241-4
Round End Pipe
450966-8
Curved End Pipe
451753-8
Elbow
453720-9
Vacuum Assembly
197234-5
Dust Bag
166114-6
Grip
6609008000
Tool Kit
194717-6
Reliable & Environment Friendly Makita
4-STROKE ENGINE SERIES
Makita’s 4-Stroke Engines offer the following advantages compared
with the equivalent size of 2-Stroke Engines:
High Performance, Compact and Light Weight Design
•
Clean Exhaust Emissions
Low Running Cost
•
Easy Maintenance
•
Low Noise
SPECIFICATIONS
Displacement
75.6 cc
Maximum Air Flow (Long Pipe) 205 MPH
Maximum Air Volume (Long Pipe) 705 CFM
Carburetor
Diaphragm Type
Fuel / Oil Mixture
Not Required
Power Rating
3.0 kW / 4.1 hp
Tank Capacity
1.9 L
Overall Length
13 -1/8˝ (332 mm)
Dry Weight
24.1 lbs (10.9 kg)
4-Stroke MM4 engine for
lower emissions and greater
fuel economy
Outdoor
Power Equipment
BHX2500CA
Shown With Optional
Curved End Pipe
Sold Separately
(Part No. 451753-8)
EB5300TH
STANDARD EQUIPMENT INCLUDES:
Long Pipe 90 (197723-0), End Nozzle 90-62 (198034-6),
Flat Nozzle 90 (196911-6), Flexible Pipe (454934-3),
Swivel Pipe (161653-1), Box Wrench Set (196771-6),
Shoulder Harness R (161544-6), Shoulder Harness L(161543-8),
Hose Clamp (282025-8), Spark Plug (168652-4),
Starter Rope (444043-6),Accessory Bag (831304-7)
218 MPH Air Speed with
512 CFM Volume
• Professional power in a lighter weight blower
• 4 damper springs mounted between the engine and
the backpack frame reduce the vibration on the
back of operator even during long hours
• Cushioned back padding and shoulder straps,
in addition to being well-ventilated, aid in effective
sweat evaporation and to provide
more operator comfort
• MM4 4-Stroke engine for lower
emissions and longer run tim
52.5 cc 4-Stroke Backpack Blower
SPECIFICATIONS
Displacement
52.5 cc
Maximum Air Flow
(Long Pipe, End Nozzle 90-62) 218 MPH
Maximum Air Volume
(Long Pipe, End Nozzle 90-62) 512 CFM
Carburetor
Diaphragm Type
Fuel / Oil Mixture
Not Required
Power Rating
1.8 kW / 2.5 hp
Tank Capacity
1.8 L
Overall Length
12-5/8˝ (320 mm)
Dry Weight
19.7 lbs (8.9 kg)
4-Stroke MM4 engine for
lower emissions and greater
fuel economy
BHX2500CAV
NEW!
BHX2500CAV
includes Vacuum Kit
