177 / 204
21˝ / 60.7 cc Environment-Friendly 2-Stroke Chainsaw with Easy Start and Winter Operation Mode
• SAS / Stratified Air Scavenging System to comply with many exhaust emission regulations
• Easy Start / Equipped with a Spring Assisted Recoil Starter for 30% Less pulling force and Low RPM Ignition Coil providing Faster, Easier Starting
• Heavy Duty Cartridge Filter System designed for Extended Filter Life and Less Maintenance
• Touch & Stop / One Lever Control for Starting, Running and Shut Down Operation
• Steel Spring / Advanced Vibration Dampening System is engineered for reducing vibration transfer to the operator
• Fuel Primer Bulb for Improved and Quicker Cold Starts
• Aggressive Large Metal Spike Bar for Safety and Hinge Action Cutting
• Half Throttle-lock start position with Easy Start for Reduced Start-Up Force
• Easy Remove Air Filter and Spark Plug Cover for quick maintenance access
SPECIFICATIONS
Displacement
60.7 cc (3.7 cu.in.)
Chain Pitch / Gauge
3/8" / . 058”
Max. Engine Speed
13,800 RPM
Power Rating
3.4 kW / 4.5 hp
Fuel Tank Capacity
800 ml
Oil Tank Capacity
480 ml
Fuel / Oil Mixture
50:1
Net Weight: Dry w/o Bar & Chain 13.2 lbs (6.0 kg)
STANDARD EQUIPMENT INCLUDES:
20-21˝ Chain (523 099 072), 21˝ Guide Bar (443 053 651), Chain Cover (952 020 660),Tool Kit (957 004 002), Spike Bar (130 250 020), Spark Plug (965 603 021), Starter Rope (181 164 020)
SAS + Easy Start
+ Winter Mode
makita.ca
175
Cordless
Benchtop
Saws
Woodworking
Hammers
Dust
Extraction
Drills
Metalworking
Pneumatic
OPE
Manufacturing
And Assembly
EA6100PRGE
21˝ / 60.7 cc 2-Stroke Chainsaw
STANDARD EQUIPMENT INCLUDES:
20-21˝ Chain (523 099 072), 20˝ Guide Bar (445 050 655),
Chain Cover (952 020 660),Tool Kit (957 004 002), Starter Rope (108 164 020), Spark Plug (965 603 021)
20˝ / 72.6 cc Environment-Friendly 2-Stroke Chainsaw with Winter Operation Mode
• SLR / Scavenging Losses Rejection Muffler
producing much Cleaner Emissions
• Half Throttle-lock start position with
Decompression Valve for Reduced Start-Up Force
• Steel Spring / Advanced Vibration Dampening
System is engineered for reducing vibration
transfer to the operator
• Dual Mount, Aggressive Large Metal Spike Bars
for Safety and Hinge Action Cutting
• Easy Remove Air Filter and Spark Plug Cover
for quick maintenance access
• Electronic Ignition system incorporates
a Microprocessor
SLR + Decompression Valve
+ Winter Mode
20˝ / 72.6 cc 2-Stroke Chainsaw
SPECIFICATIONS
Displacement
72.6 cc (4.4 cu.in.)
Chain Pitch / Gauge
3/8˝ / . 058˝
Maximum Engine Speed 12,800 RPM
Power Rating
4.0 kW / 5.4 hp
Fuel Tank Capacity
750 ml
Oil Tank Capacity
420 ml
Fuel / Oil Mixture
50:1
Net Weight
13.8 lbs (6.3 kg)
EA7300PRFE
When
QUALITY & SERVICE
Counts – Choose Makita
DCS5121REJ
18˝ / 50 cc Environment-Friendly 2-Stroke Chainsaw with Easy Start
and Winter Operation Mode
• SLR / Scavenging Losses Rejection Muffler
producing much Cleaner Emissions
• Easy Start / Equipped with a Spring Assisted Recoil
Starter for 30% Less pulling force and Low RPM
Ignition Coil providing Faster, Easier Starting
• Touch & Stop / One Lever Control for Starting,
Running and Shut Down Operation
• Steel Spring / Advanced Vibration Dampening
System is engineered for reducing vibration
transfer to the operator
• Dual Mount, Aggressive Large Metal
Spike Bars for Safety and Hinge
Action Cutting
• Half Throttle-lock start
position with Easy
Start for Reduced
Start-Up Force
SLR + Easy Start
+ Winter Mode
18˝ / 50 cc 2-Stroke Chainsaw
SPECIFICATIONS
Displacement
50 cc (3.1 cu.in.)
Chain Pitch / Gauge
.325˝ / .058˝
Maximum Engine Speed 13,800 RPM
Power Rating
2.5 kW / 3.3 hp
Fuel Tank Capacity
470 ml
Oil Tank Capacity
269 ml
Fuel / Oil Mixture
50:1
Net Weight: Dry w/o Bar & Chain
12.1 lbs (5.4 kg)
Outdoor
Power Equipment
18˝ Rescue Bar
& Chain Kit
Sold Separately
(Part No. 957 415 060)
See page 160
All Makita
Gasoline Powered Chainsaws
now feature
New
HIGH VISIBILITY SAFETY COLOUR!
EA5600FREE
STANDARD EQUIPMENT INCLUDES:
18˝ Chain (523 099 064), 18˝ Sprocket Nose Bar
3/8˝ 58G (445 045 651), Chain Protector Cover (952 020 640), Universal Wrench 13/19 (941 719 141),Torx Wrench (782025-3),
Screwdriver (783012-5), Starter Rope (131 164 020), Spark Plug (965 603 021), Spike Bar (326648-3)
18˝ / 55.6 cc Environment-Friendly 2-Stroke Chainsaw with Easy Start
and Winter Operation Mode
• SLR / Scavenging Losses Rejection Muffler
producing much Cleaner Emissions
• Easy Start / Equipped with a Spring Assisted Recoil
Starter for 30% Less pulling force and Low RPM
• Ignition Coil providing Faster, Easier Starting
• Winter Mode (Optional) / Prevents Carburetor Icing
by providing a Higher Operating Engine
• Temperature during Cold Weather use and up to 5
°
C
• Heavy Duty Cartridge Filter System designed for
Extended Filter Life and Less Maintenance
• Touch & Stop / One Lever Control for Starting,
Running and Shut Down Operation
• Steel Spring / Advanced Vibration
Dampening System is
engineered for reducing
vibration transfer
to the operator
18˝ / 55.6 cc 2-Stroke Chainsaw
SPECIFICATIONS
Displacement
55.6 cc (3.4 cu.in.)
Chain Pitch / Gauge
3/8˝ / .058˝
Maximum Engine Speed 13,800 RPM
Power Rating
3.0 kW / 3.9 H.P.
Fuel Tank Capacity
570 ml
Oil Tank Capacity
320 ml
Fuel / Oil Mixture
50:1
Net Weight Dry w/o Bar/Chain
12.8 lbs (5.8kg)
SLR + Easy Start
+ Winter Mode
Bar & Chain Fasteners remain
fixed to cover when loosened
EA4300FREC
STANDARD EQUIPMENT INCLUDES:
.325˝ Chain 18" 50G (512 484 672), 18˝ Sprocket Nose Bar .325" 50G (444 045 141), Chain Protector Cover (419560-5), Spike Bar (346301-5),
Universal Wrench 13/16 (782026-1),Torx Wrench (782025-3), Screwdriver (for CarburetorAdjustment) (783012-5), Spark Plug (0650109950)
18˝ / 43 cc Environment-Friendly 2-Stroke Chainsaw with Easy Start and
Winter Operation Mode
• SLR / Scavenging Losses Rejection Muffler
producing much Cleaner Emissions
• Easy Start / Equipped with a Spring Assisted Recoil
Starter for 30% Less pulling force and Low RPM
Ignition Coil providing Faster, Easier Starting
• Touch & Stop / One Lever Control for Starting,
Running and Shut Down Operation
• Steel Spring / Advanced Vibration Dampening
System is engineered for reducing vibration
transfer to the operator
• Dual Mount, Aggressive Large
Metal Spike Bars for Safety and
Hinge Action Cutting
Catalytic Converter Muffler
+ Easy Start + Winter Mode
18˝ / 42.4 cc 2-Stroke Chainsaw
SPECIFICATIONS
Displacement
42.4 cc (2.6 cu.in.)
Chain Pitch / Gauge
.325˝ / .050˝
Maximum Engine Speed 13,500 RPM
Power Rating
2.1kW / 2.9 hp
Fuel / Oil Mixture (Makita Oil)
50:1
Fuel Tank Capacity
480 ml
Oil Tank Capacity
280 ml
Net Weight: Dry w/o Bar & Chain
10.8 lbs (4.9 kg)
STANDARD EQUIPMENT INCLUDES:
18˝ Chain (523 686 072),18˝ Guide Bar (445 045 631), Chain Cover (952 020 650),
Starter Rope (108 164 020), Spark Plug (965 603 021),Tool Kit (957 004 002)
