EA3501SRDB
STANDARD EQUIPMENT INCLUDES:
16˝ Guide Bar (165202-6), 16˝ Chain (196444-1), Chain Cover 14”-16” (419560-5), Spike Bar (346301-5),
Universal Wrench 13/16 (782026-1), Starter Rope (444038-9), Spark Plug (0650109950), Screwdriver (783012-5)
16˝ / 35 cc Environment-Friendly 2-Stroke Chainsaw with
Intelligent Ignition Coil + Easy Start
• Intelligent Ignition Coil controls Stable Idling,
increases Output Power, protects against Engine
Overrun and enables Easier Restarting
• Toolless Chain Tensioner for quick and
easy adjustments
• Touch & Stop / One Lever Control for Starting,
Running and Shut Down Operation
• Steel Spring / Advanced Vibration Dampening
System is engineered for reducing vibration
transfer to the operator
• Fuel Primer Bulb for Improved
and Quicker Cold Starts
• Aggressive Large Metal
Spike Bar for Safety
and Hinge Action
Cutting
16˝ / 35 cc 2-Stroke Chainsaw
SPECIFICATIONS
Displacement
35 cc (2.1 cu.in)
Chain Pitch / Gauge
3/8˝ / .050˝
Maximum Engine Speed 13,100 RPM
Power Rating
1.7 kW / 2.3 hp
Fuel / Oil Mixture
50:1
Fuel Tank Capacity
400 ml
Oil Tank Capacity
290 ml
Net Weight: Dry w/o Bar & Chain
9.9 lbs (4.5 kg)
EA3201SRDB
STANDARD EQUIPMENT INCLUDES:
16˝ Guide Bar (165202-6), 16˝ Chain (196444-1), Chain Cover 16˝ (419560-5), Spike Bar (346301-5), Universal Wrench 13/16 (782026-1),
Screwdriver (783012-5), Spark Plug (0650109950), Starter Rope (444038-9)
16˝ / 32 cc Environment-Friendly 2-Stroke Chainsaw with
Intelligent Ignition Coil + Easy Start
• Intelligent Ignition Coil controls Stable Idling,
increases Output Power, protects against Engine
Overrun and enables Easier Restarting
• Toolless Chain Tensioner for quick and
easy adjustments
• Touch & Stop / One Lever Control for Starting,
Running and Shut Down Operation
• Steel Spring / Advanced Vibration Dampening
System is engineered for reducing vibration
transfer to the operator
• Fuel Primer Bulb for Improved
and Quicker Cold Starts
• Aggressive Large Metal
Spike Bar for Safety
and Hinge Action
Cutting
Intelligent Ignition Coil
+ Easy Start
16˝ / 32 cc 2-Stroke Chainsaw
SPECIFICATIONS
Displacement
32 cc (1.95 cu.in.)
Chain Pitch / Gauge
3/8˝ / .050˝
Maximum Engine Speed 12,800 RPM
Power Rating
1.35 kW / 1.8 hp
Fuel / Oil mixture
50:1
Fuel Tank Capacity
400 ml
Oil Tank Capacity
280 ml
Net Weight: Dry w/o Bar & Chain
9.4 lbs (4.2 kg)
All Makita
Gasoline Powered Chainsaws
now feature
New
HIGH VISIBILITY SAFETY COLOUR!
Intelligent Ignition Coil
+ Easy Start
DUC353Z
14˝ / 18Vx2 LXT Cordless Chainsaw
SPECIFICATIONS
Battery Capacities
Two 18V Li-Ion
Guide Bar Length
14˝ (350 mm)
Chain Pitch / Gauge
3/8˝ / 0.043˝
Chain Speed
0-3,940 FPM (0-1 200 m/min)
Overall Length
30-1/2˝ (773 mm)
Net Weight
8.9 lbs (4.0 kg)
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
14" Chain (196741-5), 14" Guide Bar (165246-6), Chain Cover (419288-5),
Spike Bumper (347078-5), Oil Supply (182229-1)
makita.ca
DUC353Z
Brushless Outer
Motor + XPT + 3 Year
Limited Warranty
DUC353Z
14˝ / 18Vx2 LXT Cordless Chainsaw with Specialized
Battery Positioning for Optimum Balance and Control
• Fast, Variable Speed (3,940 Feet Per Minute) Equivalent to a 30 cc Gasoline Chainsaw
• Specialized 18Vx2 Battery Positioning is the Makita Industry Game Changer within the Cordless
Product line offering Premium Balance, Control and Cutting Performance
• Makita Built Outer Rotor Brushless Motor Direct Drive System for High Power & Speed
equivalent to a 30 cc Gasoline Chainsaw
• XPT / eXtreme Protection Technology offers maximum protection against dust, debris
and liquids for optimal performance in extreme conditions
Unique Battery Positioning for
Optimum Performance
Brushless Outer
Motor Direct
Drive System
EA3601FRDB
STANDARD EQUIPMENT INCLUDES:
16˝ Guide Bar (165202-6), 16˝ Chain (531 492 656), Chain Cover (419560-5), Box Wrench (782027-9), Starter Rope (SG00000025),
Spark Plug (649500-1)
16˝ / 35.2 cc Environment-Friendly 2-Stroke Chainsaw with Easy Start and
Winter Operation Mode
• Stratified Air Scavenging engine for lower emissions
and improved fuel efficiency
• "Tool-less" chain tensioning for quick and
convenient chain adjustment
• Touch & Stop single lever control shuts off engine
with just a touch
• Compact design with less weight
(only 9.3 lbs / 4.2 kg)
• High power-to-weight ratio 2.4 HP engine
• Centrifugal air cleaner for
enhanced air filtration
• Advanced vibration dampening
system engineered to
reduce vibration
• Fuel level view window
SAS + Easy Start + Winter Mode
16˝ / 35.2 cc 2-Stroke Chainsaw
SPECIFICATIONS
Displacement
35.2 cc (2.15 cu.in.)
Chain Pitch / Gauge
3/8" / .050"
Maximum Engine Speed 13,500 RPM
Power Rating
1.7 kW / 2.4 hp
Fuel / Oil Mixture
50:1
Fuel Tank Capacity
310 ml
Oil Tank Capacity
260 ml
Net Weight Dry w/o Bar/Chain
9.3 lbs (4.2 kg)
DUC400Z
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
16˝ Chain (196742-3), 16" Guide Bar (165247-4), Chain Cover (419242-9), Oil Supply (182229-1), Spike Bumper (347078-5)
16˝ / 18Vx2 LXT Cordless Chainsaw
with Specialized Battery Positioning
for Optimum Balance and Control
• Fast, Variable Speed (3,940 Feet Per Minute)
Equivalent to a 30 cc Gasoline Chainsaw
• Specialized 18Vx2 Battery Positioning is the Makita
Industry Game Changer within the Cordless
Product line offering Premium Balance, Control
and Cutting Performance
• Makita Built Outer Rotor Brushless Motor Direct
Drive System for High Power & Speed equivalent
to a 30 cc Gasoline Chainsaw
16˝ / 18Vx2 LXT Cordless Chainsaw
SPECIFICATIONS
Battery Capacities
Two 18V Li-Ion
Guide Bar Length
16˝ (400 mm)
Chain Pitch / Gauge
3/8˝ / 0.043˝
Chain Speed 0-3,940 FPM (0-1 200 m/min)
Overall Length
32-1/4˝ (818 mm)
Net Weight
9.3 lbs (4.2 kg)
Brushless Outer Motor
+ XPT + 3 Year Limited Warranty
