Makita General Catalogue

Cordless

Power Tools

makita.ca

Cordless

Benchtop

Saws

Woodworking

Hammers

Dust

Extraction

Drills

Metalworking

Pneumatic

OPE

Manufacturing

And Assembly

6349DWFE

STANDARD EQUIPMENT INCLUDES:

Two 18V (3.0Ah) Ni-MH Batteries

1835 (193140-2), Charger (DC1804),Two Battery Covers (414938-7), 1/2˝ Keyless Drill Chuck (763191-5),

1 Ea. Square Bits (784639-4, 784640-9), Side Handle (122712-6), Plastic Carrying Case (824763-2)

MXT Series Drill (Makita Xtreme Technology)

• 16 Clutch Settings deliver up to 560 in. lbs of torque

• Three Speed Gearing for more efficiency

• Shift-Lock drive converts from Drill to Driver mode

• All Metal Gears for more efficient power transmission

1/2˝ Drill / Driver

SPECIFICATIONS

Battery

18V (3.0 Ah) Ni-MH

Capacities:

Steel

1/2˝ (13 mm)

Wood

2-9/16˝ (65 mm)

No Load Speed:

Low

0 - 300 RPM

Medium

0 - 600 RPM

High

0 - 1,700 RPM

Maximum Torque

560 in. lbs (63 Nm)

Overall Length

9-11/16˝ (246 mm)

Net Weight

5.7 lbs (2.6 kg)

When

QUALITY & SERVICE

Counts – Choose Makita

6271DWPE

STANDARD EQUIPMENT INCLUDES:

Two 12V (1.3Ah) Ni-Cad Batteries

PA12 (638347-8-2, 2 / Pk), Charger (DC1804),Two Battery Covers (414938-7),

3/8˝ Keyless Drill Chuck (196309-7), Phillips Bit 2-65 (784636-0), Plastic Carrying Case (824852-3)

Versatile, General Purpose Drill / Driver

• 16 Clutch Settings deliver up to 250 in. lbs of torque

• All Metal Gears for more efficient power transmission

• Compact Design with a reduced body length of only 7-9/16˝

• Single Sleeve Keyless Drill Chuck for easy bit installation and removal

3/8˝ Drill / Driver

SPECIFICATIONS

Battery

12V (1.3 Ah) Ni-Cad

Capacities:

Steel

3/8˝ (10 mm)

Wood

1˝ (25 mm)

No Load Speed:

Low

0 - 400 RPM

High

0 - 1,300 RPM

Maximum Torque

250 in. lbs (28 Nm)

Overall Length

7-9/16˝ (192 mm)

Net Weight

3.3 lbs (1.5 kg)

6261DWPE

STANDARD EQUIPMENT INCLUDES:

Two 9.6V (1.3Ah) Ni-Cad Batteries

PA09 (638344-4-2), Charger (DC1804),Two Battery Covers (414938-7),

3/8˝ Keyless Drill Chuck (196309-7), Phillips Bit 2- 65 (784636-0), Plastic Carrying Case (824852-3)

Versatile, General Purpose Drill / Driver

• 16 Clutch Settings deliver up to 200 in. lbs of torque

• All Metal Gears for more efficient power transmission

• Compact Design with a reduced body length of only 7-9/16˝

• Single Sleeve Keyless Drill Chuck for easy bit installation and removal

3/8˝ Drill / Driver

SPECIFICATIONS

Battery

9.6V (1.3 Ah) Ni-Cad

Capacities:

Steel

3/8˝ (10 mm)

Wood

13/16˝ (21 mm)

No Load Speed:

Low

0 - 400 RPM

High

0 - 1,300 RPM

Maximum Torque

200 in. lbs (23 Nm)

Overall Length

7-9/16˝ (192 mm)

Net Weight

3.3 lbs (1.5 kg)

6281DWPE

STANDARD EQUIPMENT INCLUDES:

Two 14.4V (1.3Ah) Ni-Cad Batteries

PA14 (193987-4), Charger (DC1804),Two Battery Covers (414938-7),

3/8˝ Keyless Drill Chuck (196309-7), Phillips Bit 2-65 (784636-0), Plastic Carrying Case (824852-3)

Versatile, General Purpose Drill / Driver

• 16 Clutch Settings deliver up to 260 in. lbs of torque

• All Metal Gears for more efficient power transmission

• Compact Design with a reduced body length of only 7-9/16˝

• Single Sleeve Keyless Drill Chuck for easy bit installation and removal

3/8˝ Drill / Driver

SPECIFICATIONS

Battery

14.4V (1.3 Ah) Ni-Cad

Capacities:

Steel

3/8˝ (10 mm)

Wood

1˝ (25 mm)

No Load Speed:

Low

0 - 400 RPM

High

0 - 1,300 RPM

Maximum Torque

260 in. lbs (30 Nm)

Overall Length

7-9/16˝ (192 mm)

Net Weight

3.3 lbs (1.5 kg)

6391DWPE

STANDARD EQUIPMENT INCLUDES:

Two 18V (1.3Ah) Ni-Cad Batteries

PA18 (194227-3, 2 / Pk), Charger (DC1804),Two Battery Covers (414938-7),

1/2˝ Keyless Drill Chuck (766027-7), Phillips Bit 2-65 (784636-0), Plastic Carrying Case (824853-1)

Versatile, General Purpose Drill / Driver

• 16 Clutch Settings deliver up to 340 in. lbs of torque

• All Metal Gears for more efficient power transmission

• Compact design with a reduced body length of only 8-3/8˝

• Single Sleeve Keyless Drill Chuck for easy bit installation and removal

1/2˝ Drill / Driver

SPECIFICATIONS

Battery

18V (1.3 Ah) Ni-Cad

Capacities:

Steel

1/2˝ (13 mm)

Wood

1-7/16˝ (36 mm)

No Load Speed:

Low

0 - 400 RPM

High

0 - 1,300 RPM

Maximum Torque

340 in. lbs (38 Nm)

Overall Length

8-3/4˝ (223 mm)

Net Weight

4.4 lbs (2.0 kg)

8391DWPE

STANDARD EQUIPMENT INCLUDES:

Two 18V (1.3Ah) Ni-Cad Batteries

PA18 (194227-3, 2 / Pk), Charger (DC1804), Battery Cover (414938-7),

1/2˝ Keyless Drill Chuck (766027-7), Double Ended Bit (784636-0), Plastic Carrying Case (824853-1)

Single Sleeve 1/2˝ Keyless Chuck With Shaft Lock

• 16 Clutch Settings deliver up to 340 in. lbs of torque

• All Metal Gears for more efficient power transmission

• Compact Design with a reduced body length of only 9-1/2˝

• Single Sleeve Keyless Drill Chuck for easy bit installation and removal

1/2˝ Hammer Drill / Driver

SPECIFICATIONS

Battery

18V (1.3 Ah) Ni-Cad

Capacities:

Concrete

1/2˝ (13 mm)

Steel

1/2˝ (13 mm)

Wood

1-7/16˝ (36 mm)

No Load Speed:

Low

0 - 400 RPM

High

0 - 1,300 RPM

Blows Per Minute:

Low

0 - 6,000 BPM

High

0 - 19,500 BPM

Maximum Torque

340 in. lbs (38 Nm)

Overall Length

9-1/2˝ (241 mm)

Net Weight

4.6 lbs (2.1 kg)

Variable 3-Speed,

Reversible

Variable 2-Speed,

Reversible

Variable 2-Speed,

Reversible

Variable 2-Speed,

Reversible

Variable 2-Speed,

Reversible

Variable 2-Speed,

Reversible
