DF001DW
STANDARD EQUIPMENT INCLUDES:
Plastic Carrying Case, USB Cable (661750-8),
ACAdapterADP07 (630A41-4), 81 Pc Bit Case Set
Features Built-In 3.6V (1.5 Ah)
Li-Ion Battery
Includes 81 Piece Accessory Set
• Adjustable hinged handle enables easy straight
or pistol style operation
• LED job light with Independent On / Off Switch
illuminates work area
• Built-in battery eliminates need to transport
and store additional batteries
• Includes AC charging adapter with
micro-USB connector
• Accessory set includes: magnetic bit holder,
nutsetters 3/16
˝
, 1/4
˝
, 9/32
˝
, 5/16
˝
, 11/32
˝
, 3/8
˝
2" driver bits PH1, PH2, PH3, T20, T25, T30
1" insert bits: SQ0 (3), SQ1 (3), SQ2 (3), SQ3 (3)
PH0 (3), PH1 (3), PH2 (3), PH3 (3), T10 (2), T15 (2)
T20 (3), T25 (3), T27 (2), T30 (3), T40 (2)
PZ0 (1), PZ1 (2), PZ2 (2), PZ3 (1), Hex 3/32
˝
(2)
1/8
˝
(2), 5/32
˝
(2), 3/16
˝
(2), 1/4
˝
(2), 5/64
˝
(2)
SL4-5 (3), SL6-8 (3), SL10-12 (3)
1/4˝ Screwdriver
SPECIFICATIONS
Battery
3.6V (1.5 Ah) Li-Ion
Hex Shank
1/4˝ (6.35 mm)
No Load Speed
220 RPM
Maximum Torque
53 in. lbs (6.0 Nm)
Overall Length
11-1/4˝ (287 mm)
Net Weight
0.8 lbs (0.36 kg)
DF010DSE
STANDARD EQUIPMENT INCLUDES:
Two 7.2V (1.0Ah) Li-Ion Batteries
BL14302 (194356-2), Charger (DC07SA), Phillips Bit 1-50 (784245-5), Phillips Bit 2-50 (784244-7),
Battery Plastic Case (824781-0), Plastic Carrying Case (158775-6)
High Fastening Clutch Accuracy With 21 Torque Settings
• Auto Stop System indicates battery power reduction and stops operation when battery reaches
minimal capacity in order to prevent incomplete fastening
• Auto Stop Clutch stops motor automatically when clutch is disengaged
• Adjustable Handle with Enhanced Hinge Mechanism for operational versatility
• LED Job Light illuminates work area and features Independent On / Off Switch
• Ergonomic Soft Rubber Grip design for vibration absorption and comfortable operation
1/4˝ Drill / Driver
SPECIFICATIONS
Battery
7.2V (1.0 Ah) Li-Ion
Hex Shank
1/4˝ Hex
Capacities:
Steel
3/16˝ (5 mm)
Wood
1/4˝ (6 mm)
No Load Speed:
Low
200 RPM
High
650 RPM
Maximum Torque
50 in. lbs (5.6 Nm)
Net Weight
1.2 lbs (0.6 kg)
Variable 2-Speed,
Reversible
RM01
Compact Design For
Maximum Portability
• LCD Digital Display with Backlight
• FM Telescopic Antenna
• 5 FM / 5 AM Preset Function
• Push Button AM / FM Digital Tuning Feature
• Digital and Manual Tuning Feature
• Digital Volume Control
• Auxilliary Input & Earphone Jack
• Dual Front Speakers produce
clear, high quality sound
Tool Only. Batteries and Charger Sold Separately.
12V / 10.8V Li-Ion Radio
SPECIFICATIONS
Battery Capacities: 10.8V (1.3 Ah) Li-Ion
12V MAX (1.3 Ah) Li-Ion
Continuous Run Time Approx. 2.5 Hours
Overall Dimensions (L x W x H)
6-5/8˝ x 3-1/4˝ x 2-15/16˝
(169 mm x 83 mm x 74 mm)
Net Weight
0.7 lbs (0.3 kg)
HU01Z
STANDARD EQUIPMENT INCLUDES:
ToolOnly.BatteriesandChargerSoldSeparately.
ShearBladeAssembly (195178-3),BladeCover (195274-7),ChipReceiverSet (195278-9)
Compact Design For Added Versatility
• Dual Blade action cuts quickly with shearing effect
• Chip Receiver prevents material from falling onto blade
• Non-Electrolyzed Nickel Plated Blades reduce staining and rusting
• Battery Capacity Warning Light indicates low battery capacity
• Tool-less Blade Changing System enables simple and easy blade changes
• Left and Right Hand Lock Off Button for added safety
7-7/8˝ Hedge Trimmer
SPECIFICATIONS
Battery
12V MAX (1.3 Ah) Li-Ion
No Load Speed
1,250 SPM
Cutting Length
7-7/8˝ (200 mm)
Maximum Cutting Thickness 5/16˝ (8 mm)
Overall Length
18-1/8˝ (460 mm)
Net Weight
2.2 lbs (1.0 kg)
MU01Z
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
Shear BladeAssembly (195176-7), Base Frame (325896-1),
Change Lever (451813-6), Blade Cover (452055-5)
Compact Design For Added Versatility
• Dual Blade action cuts quickly with shearing effect
• Non-Electrolyzed Nickel Plated Blades reduce staining and rusting
• Wire Toboggan Style Base Frame enables quick and easy depth adjustment
• Battery Capacity Warning Light indicates low battery capacity
• Tool-less Blade Changing System enables simple and easy blade changes
• Left and Right Hand Lock-Off Button for operator safety
• Ergonomic Soft Rubber Grip design for vibration absorption and
comfortable operation
Dual Blade Action
6-5/16˝ Grass Shear
SPECIFICATIONS
Battery
12V MAX (1.3 Ah) Li-Ion
No Load Speed
1,250 SPM
Cutting Width
6-5/16˝ (160 mm)
Depth Adjustment
3/8˝ / 9/16˝ / 1˝
(10 mm / 15 mm / 25 mm)
Overall Length
11-1/2˝ (292 mm)
Net Weight
2.0 lbs (0.9 kg)
Makita offers a wide variety of
ACCESSORIES!
Optional Grass
Shear Attachment
for HU01Z
Grass Shear Blades
195176-7
Grass Shear Cover
195269-0
Optional Hedge
Trimmer Attachment
for DUM168Z & MU01Z
Hedge Trimmer Blades
195178-3
Hedge Trimmer Cover
195274-7
Dual Blade Action
Chip Receiver Set
(Standard Equipment)
(Part No. 195278-9)
STANDARD EQUIPMENT INCLUDES:
7.2V (1.5Ah) Li-Ion Battery
BL0715 (198001-1), Pod / Stick Charger (DC10WB), Holster (168435-2),
Phillips Bit 2-50 (784244-7),Tool Bag (831277-4)
1/4˝ Cordless Impact Driver
SPECIFICATIONS
Battery
7.2V (1.5 Ah) Li-Ion
Hex Shank
1/4˝ Hex
Impacts Per Minute
0 - 3,000 IPM
No Load Speed
0 - 2,450 RPM
Maximum Fastening Torque
220 in. lbs (25 Nm)
Capacities:
Machine Screw 1/8˝ - 5/16˝ (M3 - M8)
Standard Bolt
1/8˝ - 5/16˝ (M3 - M8)
High Tensile Bolt 1/8˝ - 1/4˝ (M3 - M6)
Overall Length
11-1/8˝ (282 mm)
Net Weight
1.2 lbs (0.5 kg)
TD022DS
Variable Speed, Reversible,
Electric Brake
Compact And Lightweight Design With Precision Control
And High Fastening Torque
• Multi-function variable speed rotary switch allows operators to adjust driving speed and direction
simultaneously for precise fastening applications
• Switch position enables easy access for left or right handed users
• Lock-off button prevents accidental startup
• Adjustable handle with enhanced hinge mechanism for operational versatility
• LED job light with pre-glow feature
Reversible
