FD02Z
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
Phillips Bit 2-50 (784244-7), 3/8" Keyless Drill Chuck (763228-8)
Lightweight & Compact With High Operational Efficiency
• 18 Clutch Settings deliver up to 200 in. lbs of torque
• Two Speed Gearing for more efficiency
• Lightweight and Compact Design
• LED Job Light with Afterglow feature
• Ergonomic Soft Rubber Grip design for vibration absorption and comfortable operation
Variable 2-Speed,
Reversible
3/8˝ Drill / Driver
SPECIFICATIONS
Battery
12V MAX (1.3 Ah) Li-Ion
Capacities:
Steel
3/8˝ (10 mm)
Wood
13/16˝ (21 mm)
Maximum Torque
200 in. lbs (22 Nm)
No Load Speed:
Low
0 - 350 RPM
High
0 - 1,300 RPM
Overall Length
7-7/16˝ (189 mm)
Net Weight
2.2 lbs (1.0 kg)
SH01
STANDARD EQUIPMENT INCLUDES:
Two 12V MAX (1.3Ah) Li-Ion Batteries
BL1014 (195332-9), Pod / Stick Charger (DC10WB), 3-3/8˝ Circular Saw Blade 20CT (A-95021),
Hex Wrench 4 (783202-0), Plastic Carrying Case (824961-8)
Compact And Versatile Design For Flooring, Panelling, Trim And More!
• Battery Protection System shuts tool off when overloaded or when battery capacity is low
• Left and Right Side Lock-Out Button for operator safety
• Blower feature keeps cutting line free of sawdust
• Ergonomic Soft Rubber Grip design for vibration absorption and comfortable operation
Dust Blower
3-3/8˝ Circular Saw
SPECIFICATIONS
Battery
12V MAX (1.3 Ah) Li-Ion
Blade Diameter
3-3/8˝ (85 mm)
Arbor
9/16˝ (15 mm)
Maximum Cutting Capacities:
0°
1˝ (25.5 mm)
45°
5/8˝ (16.5 mm)
No Load Speed
1,400 RPM
Overall Length
11-3/4˝ (300 mm)
Net Weight
3.3 lbs (1.5 kg)
CC01
STANDARD EQUIPMENT INCLUDES:
CC01:
Two 12V MAX (1.3Ah) Li-Ion Batteries
BL1014 (195332-9), Pod / Stick Charger (DC10WB), 3-3/8˝ Diamond Blade (A-95722),
Hex Wrench 4 (783202-0)
CC01Z:
Tool Only. Batteries and Charger Sold Separately.
3-3/8˝ Diamond Blade (A-95722), Hex Wrench 4 (783202-0)
Specifically Designed For Cutting Glass and Ceramic Tile
• Battery Protection System shuts tool off when overloaded or when
battery capacity is low
• Left and Right Hand Lock-Off Lever for maximum operator safety
• Water Supply Tank (500 mL) features large cap for quick and easy refilling
• Nickel-Plated Base Plate prevents staining and corrosion
• Bevel Capacity of 45°
3-3/8˝ Glass & Tile Circular Saw
SPECIFICATIONS
Battery
12V MAX (1.3 Ah) Li-Ion
Blade Diameter
3-3/8˝ (85 mm)
Arbor
9/16˝ (15 mm)
Maximum Cutting Depths:
0°
1˝ (25.5 mm)
45°
5/8˝ (16.5 mm)
No Load Speed
1,400 RPM
Overall Length
11-3/4˝ (300 mm)
Net Weight
3.7 lbs (1.7 kg)
CC01Z
LCT207
INCLUDES:
• 1/4˝ Drill / Driver (FD01Z)
• 1/4˝ Impact Driver (DT01Z)
•
Two 12V MAX (1.3 Ah)
Li-Ion Batteries
BL1014 (195332-9)
• Pod / Stick Charger (DC10WB)
• Aluminum Carrying Case
(823304-1)
2 Tool Combo Kit
Makita offers a wide variety of
ACCESSORIES!
MR052
Compact Design For
Maximum Portability
• LCD Digital Display with Backlight
• Rubber FM Antenna
• 5 FM / 5 AM Preset Function
• Push Button AM/FM Digital Tuning Feature
• Digital and Manual Tuning Feature
• Digital Volume Control
• Auxilliary Input & Earphone Jack
• Dual Front Speakers produce clear,
high quality sound
Jobsite Radio
SPECIFICATIONS
Battery Capacities 12V MAX CXT Li-Ion
Continuous Run Time
Approx. 30 Hours (with 4.0 Ah BL1041B)
Overall Dimensions (L x W x H)
6-5/8˝ x 2-7/8˝ x 2-15/16˝
(169 mm x 73 mm x 74 mm)
Net Weight
0.8 lbs (0.35 kg)
CL106FDZ
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
NozzleAssembly (123488-8), Sash Nozzle (451243-1), Pipe (451244-9),
Sash Nozzle Holder (451245-7), Cloth Filter (443060-3), Nylon Pre-Filter (451208-3)
Lightweight & Portable Vacuum Cleaner For Shop, Office Or Home Use
Increased Air Flow and Sealed Suction for Maximum Performance
• 2-stage nylon and cloth filter
• Easy to empty dust canister for minimal downtime
• On board sash nozzle storage
• LED job light illuminates cleaning area
• Angled suction port enables easy floor cleaning without floor
nozzle and prevents extension pipes from wobbling
during operation
• Floor nozzle swivel joint design keeps vacuum
head close to surface and enables
360º rotation for easy high-reach cleaning
600 ml Vacuum Cleaner
SPECIFICATIONS
Battery Capacities 12V MAX CXT Li-Ion
Capacity
600 ml
Air Flow
45.9 CFM
Overall Length With Nozzle
37-3/4˝ (958 mm)
Net Weight
2.0 lbs (0.9 kg)
