90 / 220
BENCHTOP
STANDARD EQUIPMENT INCLUDES:
12" Double Edged HSS Planer Blades (793346-8),
Two Magnetic Holder (762014-4), Socket Wrench 9 (782203-5), Hex Wrench 2.5 (783208-8), Key (415715-0A), PlasticTool Box (824002-0)
Fastest And Easiest Blade Change On The Market
• 4-Post design with Diagonal Cross Supports provide maximum operational stability
• Interna-Lok Automated Head Clamp Feed Mechanism ensures smooth finishes with minimal snipe
• Indicator Lamp indicates active power supply
• Large Support Table for maximum material support
• Fold Away Depth Adjustment Handle for compact transport and storage
• Flat Top Design facilitates repetitive cutting operations
• On-Board, Detachable Tool Box for operator convenience
12" Thickness Planer
SPECIFICATIONS
Cutting Capacities:
Width
12" (304 mm)
Depth
1/8" (3 mm)
Thickness
6-3/32" (155 mm)
Feed Rate Per Minute
27.9' (8.5 m)
No Load Speed
8,500 RPM
AMPS (120V)
15.0 A
Table Size (W x L)
12" x 30-3/8"
(304 mm x 771 mm)
Overall Dimensions (L x W x H)
19" x 15-13/16" x 30-3/8"
(483 mm x 401 mm x 771 mm)
Net Weight
61.9 lbs (28.1 kg)
2012NB
STANDARD EQUIPMENT INCLUDES:
8" Grinding Wheel WA60K (51960), 8" Grinding Wheel
GC120H (B-51976), Wrench 10-13 (AL00000086),
Wrench 8-19 (AL00000087)
• Wheel covers feature built-in job lights to illuminate work piece for maximum visibility
• Large, easy to access on/off switch for maximum safety and convenience
• Precision-built electric induction motor has sufficient power to handle tough grinding jobs
• Equipped with coarse and fine grinding wheels to suit a wide range of applications
• Adjustable work rests allow of maximum precision and convenience
• Adjustable safety shields deflect sparks without limiting visibility
• Safety shield with integrated magnifying glass provide maximum visibility when working
with small objects
• Built-in coolant tray allows operator to periodically cool the work piece maximizing
safety and efficiency
8" Bench Grinder
SPECIFICATIONS
Grinding Wheel
8" (205 mm)
No Load Speed
3,550 RPM
Arbor Size
5/8" (15.8 mm)
Horsepower
3/4 HP
Overall Length
15-9/16" (395 mm)
Net Weight
43.2 lbs (19.6 kg)
GB801
STANDARD EQUIPMENT INCLUDES:
6" Grinding Wheel WA60K (B-51926), 6" Grinding Wheel
GC120H (B-51932), Wrench 10-13 (AL00000044),
Wrench 8-19 (AL00000045)
• Wheel covers feature built-in job lights to illuminate work piece for maximum visibility
• Large, easy to access on/off switch for maximum safety and convenience
• Precision-built electric induction motor has sufficient power to handle tough grinding jobs
• Equipped with coarse and fine grinding wheels to suit a wide range of applications
• Adjustable work rests allow of maximum precision and convenience
• Adjustable safety shields deflect sparks without limiting visibility
• Safety shield with integrated magnifying glass provide maximum visibility when working
with small objects
• Built-in coolant tray allows operator to periodically cool the work piece maximizing
safety and efficiency
6" Bench Grinder
SPECIFICATIONS
Grinding Wheel
6" (150 mm)
No Load Speed
3,550 RPM
Arbor Size
1/2" (12.7 mm)
Horsepower
1/3 HP
Overall Length
14-3/4" (375 mm)
Net Weight
20.0 lbs (9.0 kg)
GB602
STANDARD EQUIPMENT INCLUDES:
2705:
10" C.T. Blade 32T (A-94948), Push Stick (416772-1), Wrench 19 (781038-1), Wrench 13-22 (782024-5), Hex Wrench 5 (783224-0),
Adapter Ring 1" x 5/8" (257060-5),Angle Rule (122838-4), RulerAssembly (122740-1), Center Cover (126901-5)
2705X1:
10" C.T. Blade 32T (A-94948), Push Stick (416772-1), Wrench 19 (781038-1), Wrench 13-22 (782024-5), Hex Wrench 5
(783224-0),Adapter Ring 1" x 5/8" (257060-5),Angle Rule (122838-4), RulerAssembly (122740-1), Center Cover (126901-5),
Table Saw Stand (194093-8)
Enhanced Safety Features For Improved Operator Safety
• Quick Release Blade Guard is easily accessible and provides clear line of sight to blade
• Adjustable Riving Knife prevents material pinching behind blade eliminating risk of material kickback
• Electric Brake for operator safety
• Aluminum Diecast Precision Machined Table remains flat and true for out of the box accuracy
• Smooth Operating Guide Rail with larger
Locking Lever and Lock Mechanism for quick
and easy setup
10" Table Saws
SPECIFICATIONS
Blade Diameter
10" (255 mm)
Arbor
5/8" (15.9 mm)
Maximum Cutting Capacities:
90°
3-9/16" (91 mm)
45°
2-1/2" (63 mm)
Maximum Dado Capacity
6" x 13/16" (152 mm x 21 mm)
No Load Speed
4,800 RPM
AMPS (120V)
15.0 A
Table Size (L x W)
26-3/4" x 30-1/4"
(678 mm x 766 mm)
Net Weight
65.5 lbs (29.7 kg)
2705
2705X1 (With Stand)
Riving Knife,
Electric Brake
