STANDARD EQUIPMENT INCLUDES:
10" C.T. Blade 40T (JM23000176), Box Wrench 13-3 (JM23100197), Dust Bag (JM23100501), Vertical Vise (JM23100502),
Triangle Rule (JM27000328),Two Holders (322312-4)
Affordable, Professional Quality
• Sliding Rail Mechanism incorporating 3 Linear Ball Bearings provides increased rigidity to produce
precise, adjustment free cuts right out of the box
• Sliding Fence (Left Side) can be adjusted outwards when bevel cutting or inwards for increased support
of small or delicate materials
• Soft Start feature gradually increases speed to eliminate start up shock
• Battery Operated, Factory Calibrated Class II Laser enables accurate alignment of blade and cutting line
• Bevel Capacity of 45° Left or Right
• Mitre Capacity of 47° Left or 60° Right with Positive Stops at 0°, 15°, 22.5°, 31.6° & 45°
10
"
Sliding Compound Mitre Saw With Laser
SPECIFICATIONS
Blade Diameter
10" (255 mm)
Arbor
5/8" (15.88 mm)
No Load Speed
4,300 RPM
AMPS (120V)
13.0 A
Overall Dimensions (L x W x H)
32-1/2" x 21-1/8" x 25"
(825 mm x 536 mm x 633 mm)
Net Weight
43.7 lbs (19.8 kg)
LS1018L
STANDARD EQUIPMENT INCLUDES:
10" C.T. Blade 40T (JM23000176), Box Wrench 13-3
(JM23100197), Dust Bag (JM23100501), Vertical Vise
(JM23100502),Triangle Rule (JM27000328),Two Holders
(322312-4), Mitre Saw Stand (WST06)
Affordable, Professional Quality
• Sliding Rail Mechanism incorporating 3 Linear Ball Bearings provides increased rigidity to produce
precise, adjustment free cuts right out of the box
• Sliding Fence (Left Side) can be adjusted outwards when bevel cutting or inwards for increased support
of small or delicate materials
• Soft Start feature gradually increases speed to eliminate start up shock
• Battery Operated, Factory Calibrated Class II Laser enables accurate alignment of blade and cutting line
• Bevel Capacity of 45° Left or Right
• Mitre Capacity of 47° Left or 60° Right with Positive Stops at 0°, 15°, 22.5°, 31.6° & 45°
• Includes Mitre Saw Stand (WST06)
for easy transport and jobsite
portability
10
"
Sliding Compound Mitre Saw With Laser And Mitre Saw Stand
SPECIFICATIONS
Blade Diameter
10" (255 mm)
Arbor
5/8" (15.88 mm)
No Load Speed
4,300 RPM
AMPS (120V)
13.0 A
Overall Dimensions (L x W x H)
32-1/2" x 21-1/8" x 25"
(825 mm x 536 mm x 633 mm)
Net Weight
43.7 lbs (19.8 kg)
LS1018LX4
86
makita.ca
>
WHERE TOBUY
>
Buy INASTORE !
Visit us online
>
makita.ca
LS1219L, LS1219
12" Sliding Compound Mitre Saws
SPECIFICATIONS
Blade Diameter
12" (305 mm)
Arbor
1" (25.4 mm)
No Load Speed
3,200 RPM
AMPS (120V)
15.0 A
Overall Dimensions (L xW x H)
35-1/4" x 26-1/8" x 28-1/2"
(898 mm x 664 mm x 725 mm)
Net Weight
65 lbs (29.5 kg)
Incorporates Makita's Deep And
eXact Cutting Technology (DXT)
Up To 15" Cuts In 2x Material,
8" Nested Crown Moulding
and 6-3/4" Vertical Baseboard
LS1219L
with Laser
STANDARD EQUIPMENT INCLUDES:
12" C.T. Blade 60T (A-93712), Dust Bag (122852-0),
Vertical Vise (126617-2),Triangle Rule (762001-3),
Holder 90 (327145-2), Hex Wrench 6 (781044-6),
Hex Wrench 2.5 (783208-8)
LS1219
STANDARD EQUIPMENT INCLUDES:
12" C.T. Blade 60T (A-93712), Dust Bag (122852-0),
Vertical Vise (126617-2),Triangle Rule (762001-3),
Holder 90 (327145-2), Hex Wrench 6 (781044-6)
LS1019L, LS1019
10" Sliding Compound Mitre Saws
SPECIFICATIONS
Blade Diameter
10˝ (255 mm)
Arbor
5/8" (15.88 mm)
No Load Speed
3,200 RPM
AMPS (120V)
15.0 A
Overall Dimensions (L x W x H)
31-3/4" x 25" x 26"
(805 mm x 644 mm x 660 mm)
Net Weight
57.9 lbs (26.3 kg)
Incorporates Makita's Deep And
eXact Cutting Technology (DXT)
Up To 12" Cuts In
2x Material, 6-5/8"
Nested Crown Moulding
and 5-1/4" Vertical Baseboard
LS1019L
with Laser
STANDARD EQUIPMENT INCLUDES:
10" C.T. Blade 60T (A-93675), Hex Wrench 6 (781044-6),
Hex Wrench 2.5 (783208-8), Dust Bag (122852-0),
Vertical Vise (126617-2),Triangle Rule (762001-3),
Dust Nozzle (123980-4),Two Holders (326978-2),
Wrench Holder (416536-3)
LS1019
STANDARD EQUIPMENT INCLUDES:
10" C.T. Blade 60T (A-93675), Hex Wrench 6 (781044-6),
Dust Bag (122852-0), Vertical Vise (126617-2),Triangle
Rule (762001-3), Dust Nozzle (123980-4),
Two Holders (326978-2),
Wrench Holder (416536-3)
WST06
NEW Close To Wall "Zero Clearance" Design!
• Rail forward design enables saw to be placed against wall to maximize effective workspace
• Integrated guide fence and lower fence increases rigidity and support of materials
• Front bevel knob enables easy adjustment without reaching for operator convenience and precise setting of bevel angle
• Constant speed control maintains constant speed under heavy load
• Soft start feature gradually increases speed to eliminate start up shock
• Electric brake stops blade quickly after trigger is released for increased operator safety
• Laser marker enables accurate alignment of blade and cutting line (LS1219L Only)
• Bevel capacity of 48° left or right with positive stops at 0°, 22.5°, 33.9°, 45° & 48°
• Mitre capacity of 60° left or right with positive stops at 0°, 15°, 22.5°, 31.6°, 45° & 60°
• Large mitre table ideal for use with wide materials
• Easy to operate mitre angle lock with free spin releasing lever and locking lever
• Improved dust collection with dual dust collection ports
• Horizontal handle design with 2 stage safety switch for increased operator safety
NEW Close To Wall "Zero Clearance" Design!
• Rail forward design enables saw to be placed against wall to maximize effective workspace
• 3 stage gear reduction system greatly increases capacity when cutting vertical baseboard or nested crown molding
• 1-3/16" guide rail diameter provides increased stability and cutting precision
• Integrated guide fence and lower fence increases rigidity and support of materials
• Fence design allows fence to be secured to holders to prevent damage and / or loss
• Front bevel knob enables easy adjustment without reaching for operator convenience and precise setting of bevel angle
• Electronic speed control maintains constant speed under heavy load
• Soft start feature gradually increases speed to eliminate start up shock
• Factory calibrated class II laser enables accurate alignment of blade and
cutting line (LS1019L Only)
• Bevel capacity of 48° left or right with positive stops at 0°, 22.5°, 33.9°, 45° & 48°
• Mitre capacity of 60° left or right with positive stops at 0°, 15°, 22.5°, 31.6°, 45° & 60°
• Large mitre table ideal for use with wide materials
• Easy to operate mitre angle lock with free spin releasing lever and locking lever
