General Catalogue

12VMAXCXT

Power Tools

CG100DZC

STANDARD EQUIPMENT INCLUDES:

Tool Only. Batteries and Charger Sold Separately.

Safety Goggle (195246-2)

Ideal For Quick and Precise Application of Caulking and Sealants

Accepts Standard 800 ml Cartridges

• Anti-drip function eliminates residual pressure on caulking tube to prevent caulking from escaping

when the trigger is released

• Variable speed dial allows operator to set maximum dispensing speed while the variable speed trigger

enables fine adjustment for maximum control and precision in a wide range of applications

• 360° rotating tube tray allows operator to adjust positioning based on materials or application

• Overload protection feature with warning light prevents motor

burnout caused by overloading

• Battery protection system provides over-discharge,

temperature and circuit protection for

enhanced performance, battery cycle

life and overall battery life

800 ml Caulking Gun

SPECIFICATIONS

Battery Capacities

12V MAX CXT Li-Ion

Max. Pushing Force

1,100 lb (5,000 N)

Compatible Sealant Size:

Cartridge, Sausage Pack

Dimensions (L x W x H)

18-7/8" x 4-1/4" x 11-1/4"

(480 mm x 108 mm x 286 mm)

Net Weight

4.5 lbs (2.5 kg)

Anti-Drip Function,

Variable Speed

CG100DZB

STANDARD EQUIPMENT INCLUDES:

Tool Only. Batteries and Charger Sold Separately.

Three Nozzle (454226-0), Rubber Ring (424547-4),

PistonA (142071-2), Piston C (123221-8), Safety Goggles (195246-2)

Ideal For Quick and Precise Application of Caulking and Sealants

Accepts Standard 600 ml Cartridges, Sausage Packs and Bulk Caulking or Sealants

• Anti-drip function eliminates residual pressure on caulking tube to prevent caulking from escaping

when the trigger is released

• Variable speed dial allows operator to set maximum dispensing speed while the variable speed trigger

enables fine adjustment for maximum control and precision in a wide range of applications

• 360° rotating tube tray allows operator to adjust positioning based on materials or application

• Overload protection feature with warning light prevents motor burnout caused by overloading

• Battery protection system provides over-discharge, temperature and circuit protection

for enhanced performance,

battery cycle life and

overall battery life

600 ml Caulking Gun

SPECIFICATIONS

Battery Capacities

12V MAX CXT Li-Ion

Max. Pushing Force

1,100 lb (5,000 N)

Compatible Sealant Size:

Cartridge, Sausage Pack, Bulk Sealant

Dimensions (L x W x H)

21-1/4" x 4-1/4" x 11"

(538 mm x 108 mm x 278 mm)

Net Weight

4.9 lbs (2.2 kg)

Anti-Drip Function,

Variable Speed

CG100DZA

STANDARD EQUIPMENT INCLUDES:

Tool Only. Batteries and Charger Sold Separately.

Safety Goggle (195246-2)

Ideal For Quick and Precise Application of Caulking and Sealants

Accepts Standard 300 ml Cartridges

• Anti-drip function eliminates residual pressure on caulking tube to prevent caulking from escaping

when the trigger is released

• Variable speed dial allows operator to set maximum dispensing speed while the variable speed trigger

enables fine adjustment for maximum control and precision in a wide range of applications

• 360° rotating tube tray allows operator to adjust positioning based on materials or application

• Overload protection feature with warning light prevents motor burnout caused by overloading

• Battery protection system provides over-discharge, temperature and circuit protection for enhanced

performance, battery cycle life and overall

battery life

300 ml Caulking Gun

SPECIFICATIONS

Battery Capacities

12V MAX CXT Li-Ion

Max. Pushing Force

1,100 lb (5,000 N)

Compatible Sealant Size

Cartridge

Dimensions (L x W x H)

15-7/8" x 4-1/4" x 11"

(404 mm x 108 mm x 278 mm)

Net Weight

3.8 lbs (1.7 kg)

Anti-Drip Function,

Variable Speed

PT354DZ

STANDARD EQUIPMENT INCLUDES:

Tool Only. Batteries and Charger Sold Separately.

Two NoseAdapter (422372-7), Safety Goggles (195246-2),

Hex Wrench 3 (783201-2), Hook (346909-5)

Hose-Free Maneuverability And Control With Low Reaction Force

• Low reaction force mechanism for easy, high-quality nailing of long pins in hard density materials

• Slim contact tip design enables precise fastening in wood trim, crown moulding, baseboard, cabinetry

and other woodworking applications!

• On-board depth control dial for quick and easy adjustment

• Trigger lock-off feature prevents accidental firing for increased operator safety

• Anti-dry fire mechanism prevents added wear on drive pin

23 ga Pin Nailer

SPECIFICATIONS

Battery Capacities 12V MAX CXT Li-Ion

Magazine Capacities

100 nails

Gauge

23 ga

Pin Length 5/8", 11-16", 1", 1-3/16", 1-3/8"

(15 mm, 18 mm, 25 mm, 30 mm, 35 mm)

Overall Length

9-1/8" (231 mm)

Net Weight

3.6 lbs (1.6 kg)

SC103DZ

STANDARD EQUIPMENT INCLUDES:

Tool Only. Batteries and Charger Sold Separately.

3/8" Cutter Blade (199081-0), 1/4" Cutter Blade (199444-0), Blade Cover (458380-2),

Depth Gauge (415486-9), Hex Wrench 4 (783202-0)

Quick And Effortless Threaded Rod Cutting For Maximum Jobsite

Productivity And Safety

• Brushless DC motor with high power to weight and size ratio

• Twin LED job light with pre-glow and afterglow features

• Adjustable threaded rod guide supports threaded rod during operation for maximum precision and stability

• Spark free cutting ideal for use in sensitive areas

• Burr-free cutting operation for fast and easy installation of nuts

• Large retractable hook

• Ergonomic soft rubber grip design for vibration absorption and comfortable operation

Threaded Rod Cutter

SPECIFICATIONS

Battery Capacities 12V MAX CXT Li-Ion

Threaded Rod Cutting Capacities

3/8", 5/16", 1/4"

( 9.5 mm, 7.9 mm, 6.4 mm)

Overall Length

7-1/8" (180 mm)

Net Weight

5.6 lbs (2.5 kg)

CL108FDZ

STANDARD EQUIPMENT INCLUDES:

Tool Only. Batteries and Charger Sold Separately.

Floor Nozzle (123488-8), Sash Nozzle (451243-1), Pipe (451244-9),

Sash Nozzle Holder (451245-7), High Efficiency Filter (198752-6)

12V MAX CXT Li-Ion Cordless

3-Speed Cleaner

• Stronger suction power for faster cleaning

with more run time

• Built-in LED light illuminates the work area

• Battery capacity warning light indicates

ideal time to recharge battery

• Push button air volume selection

(Turbo / High / Low)

• Floor nozzle swivel joint design

keeps vacuum head close to surface

and enables 360º rotation for

easy high-reach cleaning

600 ml Vacuum Cleaner

SPECIFICATIONS

Battery Capacities 12V MAX CXT Li-Ion

Container Capacity

600 ml (20.2 oz)

Continuous Use with 12V (4.0 Ah) MAX

CXT Battery:

Approx. 20 minutes (Turbo)

Approx. 24 minutes (High)

Approx. 50 minutes (Low)

Maximum Air Flow

42 CFM

Power:

30 W (Turbo) / 20 W (High) / 5 W (Low)

Static Water Lift

17.7" (450 mm)

Overall Length

37-5/8" (956 mm)

Net Weight

1.9 lbs (0.8 kg)

Includes LED Job Light

Cordless

Benchtop

Saws

Woodworking

Hammers

Dust

Extraction

Drills

Metalworking

Pneumatic

OPE

Manufacturing

And Assembly

Up To 700

Cuts Per Charge

(3/8" Mild Steel

with BL1041B)!

Close to wall

cut of just

13/16"!
