55 / 220
Improved ball
bearing anvil holder
reduces bit wobbling
and vibration
DF333DWYE
12VMAXCXT
Power Tools
CLX205SAX1
INCLUDES:
• 3/8" Hammer Drill / Driver
(HP332DZ)
• 1/4" Impact Driver
(TD111DZ)
•
Two 12V MAX (2.0 Ah) CXT
Li-Ion Batteries
BL1021B
• Slide Charger (DC10SB)
• Tool Bag (831274-0)
2 Tool Combo Kits
CLX210SAX2
• Same as above except with
3/8" Drill / Driver (DF332DZ)
DF333DWYE
STANDARD EQUIPMENT INCLUDES:
DF333DWYEE:
Two 12V MAX (1.5Ah) CXT Li-Ion Batteries
BL1016, Slide Charger (DC10SB), Battery Cover (456128-6),
Phillips Bit 2-50 (784244-7), Hook (346909-5), Plastic Carrying Case (821661-1)
DF333DZ:
Tool Only. Batteries and Charger Sold Separately.
Phillips Bit 2-50 (784244-7), Hook (346909-5)
Compact eXtreme Technology (CXT)
• Improved ball bearing anvil holder reduces bit wobbling and vibration for cleaner, more accurate
drilling and fastening
• Battery protection system provides over-discharge, temperature and circuit protection for enhanced
performance, battery cycle life and overall battery life
• 20 clutch settings + drill mode delivers up to 250 in. lbs. of torque
• Variable speed trigger allows operator to adjust speed based on materials or application
3/8" Drill / Driver
SPECIFICATIONS
Battery Capacities 12V MAX CXT Li-Ion
Capacities:
Steel
3/8" (10 mm)
Wood
13/16" (21 mm)
Maximum Torque
250 in. lbs (28 Nm)
No Load Speed:
Low
0 - 450 RPM
High
0 - 1,700 RPM
Overall Length
7" (179 mm)
Net Weight
2.0 lbs (0.9 kg)
DF333DZ
Variable 2-Speed,
Reversible
CLX224
INCLUDES:
• 3/8" Drill / Driver
(DF333DZ)
• 1/4" Impact Driver
(TD110DZ)
•
Two 12V MAX (1.5 Ah) CXT
Li-Ion Batteries
BL1016
• Standard Charger (DC10WD)
• Tool Bag (832035-1)
2 Tool Combo Kit
TD111DSYE
STANDARD EQUIPMENT INCLUDES:
TD111DSYE:
Two 12V MAX (1.5Ah) CXT Li-Ion Batteries
BL1016, Slide Charger (DC10SB), Battery Cover (456128-6),
Phillips Bit 2-50 (784244-7), Hook (346909-5), Plastic Carrying Case (821661-1)
TD111DZ:
Tool Only. Batteries and Charger Sold Separately.
Phillips Bit 2-50 (784244-7), Hook (346909-5)
Compact eXtreme Technology (CXT)
• Brushless DC motor generates less heat buildup and is ideal for prolonged use in manufacturing
and production applications
• Battery protection system provides over-discharge, temperature and circuit protection for enhanced
performance, battery cycle life and overall battery life
• LED job light with pre-glow and after-glow feature illuminates work area
1/4" Hex Impact Driver
SPECIFICATIONS
Battery Capacities 12V MAX CXT Li-Ion
Hex Shank
1/4"
No Load Speed:
Low
0 - 1,300 RPM
High
0 - 3,000 RPM
Impacts Per Minute:
High
0 - 3,900 IPM
Low
0 - 1,600 IPM
Maximum Torque 1,200 in. lbs (135 Nm)
Overall Length
5-5/16" (135 mm)
Net Weight
2.1 lbs (0.97 kg)
TD111DZ
Variable Speed,
Reversible
TD110DSYE
STANDARD EQUIPMENT INCLUDES:
TD110DSYE:
Two 12V MAX (1.5Ah) CXT Li-Ion Batteries
BL1016, Slide Charger (DC10SB), Battery Cover (456128-6),
Phillips Bit 2-50 (784244-7), Hook (346909-5), Plastic Carrying Case (821661-1)
TD110DZ:
Tool Only. Batteries and Charger Sold Separately.
Phillips Bit 2-50 (784244-7), Hook (346909-5)
Compact eXtreme Technology (CXT)
• Battery protection system provides over-discharge, temperature and circuit protection for enhanced
performance, battery cycle life and overall battery life
• LED job light with pre-glow and after-glow feature illuminates work area
• Ergonomic soft rubber grip design for vibration absorption and comfortable operation
Variable Speed,
Reversible
1/4" Hex Impact Driver
SPECIFICATIONS
Battery Capacities 12V MAX CXT Li-Ion
Hex Shank
1/4"
No Load Speed
0 - 2,600 RPM
Impacts Per Minute
0 - 3,500 IPM
Maximum Torque 970 in. lbs (110 Nm)
Overall Length
6" (153 mm)
Net Weight
2.3 lbs (1.0 kg)
TD110DZ
53
