76 / 204
BENCHTOP
makita.ca
74
STANDARD EQUIPMENT INCLUDES:
12˝ Double Edged HSS Planer Blades (793346-8),
Two Magnetic Holder (762014-4), Socket Wrench 9 (782203-5), Hex Wrench 2.5 (783208-8), Key (415715-0A), PlasticTool Box (824002-0)
Fastest And Easiest Blade Change On The Market
• 4-Post design with Diagonal Cross Supports provide maximum operational stability
• Interna-Lok Automated Head Clamp Feed Mechanism ensures smooth finishes with minimal snipe
• Indicator Lamp indicates active power supply
• Large Support Table for maximum material support
• Fold Away Depth Adjustment Handle for compact transport and storage
• Flat Top Design facilitates repetitive cutting operations
• On-Board, Detachable Tool Box for operator convenience
12˝ Thickness Planer
SPECIFICATIONS
Cutting Capacities:
Width
12˝ (304 mm)
Depth
1/8˝ (3 mm)
Thickness
6-3/32˝ (155 mm)
Feed Rate Per Minute
27.9' (8.5 m)
No Load Speed
8,500 RPM
AMPS (120V)
15.0 A
Table Size (W x L)
12˝ x 30-3/8˝
(304 mm x 771 mm)
Overall Dimensions (W x H x L)
19˝ x 15-13/16˝ x 30-3/8˝
(483 mm x 401 mm x 771 mm)
Net Weight
61.9 lbs (28.1 kg)
2012NB
Makita offers a wide variety of
ACCESSORIES!
STANDARD EQUIPMENT INCLUDES:
2705:
10˝ C.T. Blade 32T(A-94948), Push Stick (416772-1), Wrench 19 (781038-1), Wrench 13-22 (782024-5),
Hex Wrench 5 (783224-0),Adapter Ring 1" x 5/8" (257060-5),Angle Rule (122838-4), RulerAssembly (122740-1), Center Cover (125279-3)
2705X1:
Same as 2705 except with
Table Saw Stand
(194093-8)
Enhanced Safety Features For Improved Operator Safety
• Quick Release Blade Guard is easily accessible and provides clear line of sight to blade
• Adjustable Riving Knife prevents material pinching behind blade eliminating risk of material kickback
• Smooth Operating Guide Rail with larger Locking Lever and Lock Mechanism for quick and easy setup
• Large cutting capacity (3-9/16˝ at 90° and 2-1/2˝ at 45°) allows cutting 4x material in a single pass
10˝ Table Saw & Table Saw with Stand
SPECIFICATIONS
Blade Diameter
10˝ (255 mm)
Arbor
5/8˝ (15.9 mm)
Maximum Cutting Capacities:
90°
3-9/16˝ (91 mm)
45°
2-1/2˝ (63 mm)
Maximum Dado Capacity
6˝ x 13/16˝ (152 mm x 21 mm)
No Load Speed
4,800 RPM
AMPS (120V)
15.0 A
Table Size (L x W)
26-3/4˝ x 30-1/4˝
(678 mm x 766 mm)
Net Weight
65.5 lbs (29.7 kg)
2705
2705X1
Riving Knife,
Electric Brake
STANDARD EQUIPMENT INCLUDES:
8-1/2˝ C.T. Blade 48T(A-95934), Box Wrench 13-3 (JM23100197), Dust Bag (JM23510010), Vertical Vise (JM23510009),
Triangle Rule (JM27000328),Two Holders (JM23000127)
Up To 12˝ Cuts In 2x Material
• Electric brake for increased operator safety
• Soft start feature gradually increases speed to eliminate start up shock
• LED job light illuminates cutting area for increased accuracy and precision
• Factory calibrated class II laser enables accurate alignment of blade and cutting line
• Bevel Capacity of 48° left or 5° right
• Mitre Capacity of 50° left or 60° right with positive stops at 0°, 15°, 22.5°, 31.6° and 45°
• 2 stage safety switch for increased operator safety
8-1/2
˝
Sliding Compound Mitre Saw with Laser and LED Light
SPECIFICATIONS
Blade Diameter
8-1/2˝ (216 mm)
Arbor
5/8˝ (15.88 mm)
No Load Speed
5,000 RPM
AMPS (120V)
13.0 A
Overall Dimensions (L x W x H)
29-1/2˝ x 17-3/4˝ x 19˝
(750 mm x 450 mm x 483 mm)
Net Weight
31.1 lbs (14.1 kg)
LS0815FL
High Cutting Capacity And Dust Extraction Rate
STANDARD EQUIPMENT INCLUDES:
7-1/2˝ C.T. Blade 40T(A-90629), Hex Wrench 5 (783203-8),Triangle rule (762001-3), Dust Box (194175-6),
Two Safety Switch Button (411478-6), Vertical Vise (122571-8),Two Holders (322312-4)
Ideal For Trim And Flooring Applications
• Sliding Rail Mechanism incorporating 4 Linear Ball Bearings provides increased rigidity to produce
precise, adjustment free cuts right out of the box
• Electric Brake for increased operator safety
• Mitre Capacity of 47° Left or 57° Right with Positive Stops at 0°, 15°, 22.5°, 30° & 45°
• Bevel Capacity of 45° Left or 5° Right
• Includes Cyclonic Mitre Saw Dust Box for improved dust collection
7-1/2
˝
Dual Sliding Compound Mitre Saw and Cyclonic Mitre Saw Dust Box
SPECIFICATIONS
Blade Diameter
7-1/2˝ (190 mm)
Arbor
5/8˝ (15.88 mm)
No Load Speed
6,000 RPM
AMPS (120V)
10.0 A
Overall Dimensions (L xW x H)
17˝ x 26-3/8˝ x 18˝
(430 mm x 670 mm x 458 mm)
Net Weight
28.9 lbs (13.1 kg)
LS0714B
Cordless
Benchtop
Saws
Woodworking
Hammers
Dust
Extraction
Drills
Metalworking
Pneumatic
OPE
Manufacturing
And Assembly
STANDARD EQUIPMENT INCLUDES:
7-1/2˝ C.T. Blade 40T(A-90629), Hex Wrench 5 (783203-8),Triangle rule (762001-3), Dust Bag (122852-0),
Two Safety Switch Button (411478-6), Vertical Vise (122571-8),Two Holders (322312-4)
Ideal For Trim And Flooring Applications
• Sliding Rail Mechanism incorporating 4 Linear Ball Bearings provides increased rigidity to produce
precise, adjustment free cuts right out of the box
• Electric Brake for increased operator safety
• Mitre Capacity of 47° Left or 57° Right with Positive Stops at 0°, 15°, 22.5°, 30° & 45°
• Bevel Capacity of 45° Left or 5° Right
7-1/2˝ Dual Sliding Compound Mitre Saw
SPECIFICATIONS
Blade Diameter
7-1/2˝ (190 mm)
Arbor
5/8˝ (15.88 mm)
No Load Speed
6,000 RPM
AMPS (120V)
10.0 A
Overall Dimensions (L xW x H)
17˝ x 26-3/8˝ x 18˝
(430 mm x 670 mm x 458 mm)
Net Weight
28.9 lbs (13.1 kg)
LS0714
LS0815FL
