75 / 204
Electric
Power Tools
makita.ca
73
Cordless
Benchtop
Saws
Woodworking
Hammers
Dust
Extraction
Drills
Metalworking
Pneumatic
OPE
Manufacturing
And Assembly
When
QUALITY & SERVICE
Counts – Choose Makita
STANDARD EQUIPMENT INCLUDES:
10˝ C.T. Blade 60T(A-93675), Hex Wrench 6 (781044-6), Dust Bag (122852-0), Vertical Vise (126617-2),Triangle Rule (762001-3),
Dust Nozzle (123980-4),Two Holders (326978-2), Wrench Holder (416536-3)
NEW Close To Wall "Zero Clearance" Design!
Up To 12" Cuts In 2x Material, 6-5/8" Nested Crown Moulding And 5-1/4" Vertical Baseboard
• Rail forward design enables saw to be placed against wall to maximize effective workspace
• 3 stage gear reduction system greatly increases capacity when cutting vertical baseboard or
nested crown molding
• 1-3/16" guide rail diameter provides increased stability and cutting precision
• Integrated guide fence and lower fence increases rigidity and support of materials
• Fence design allows fence to be secured to holders to prevent damage and/or loss
• Front bevel knob enables easy adjustment without reaching for operator convenience and precise
setting of bevel angle
10
˝
Sliding Compound Mitre Saw
SPECIFICATIONS
Blade Diameter
10˝ (255 mm)
Arbor
5/8˝ (15.88 mm)
No Load Speed
3,200 RPM
AMPS (120V)
15.0 A
Overall Dimensions (L xW x H)
31-3/4˝ x 25˝ x 26˝
(805 mm x 644 mm x 660 mm)
Net Weight
57.9 lbs (26.3 kg)
LS1019
Incorporates Makita's Deep And eXact
Cutting Technology (DXT)
STANDARD EQUIPMENT INCLUDES:
10˝ C.T. Blade 60T(A-93675), Hex Wrench 6 (781044-6), Hex Wrench 2.5 (783208-8), Dust Bag (122852-0), Vertical Vise (126617-2),
Triangle Rule (762001-3), Dust Nozzle (123980-4),Two Holders (326978-2), Wrench Holder (416536-3)
NEW Close To Wall "Zero Clearance" Design!
Up To 12" Cuts In 2x Material, 6-5/8" Nested Crown Moulding And 5-1/4" Vertical Baseboard
• Rail forward design enables saw to be placed against wall to maximize effective workspace
• 3 stage gear reduction system greatly increases capacity when cutting vertical baseboard or
nested crown molding
• 1-3/16" guide rail diameter provides increased stability and cutting precision
• Integrated guide fence and lower fence increases rigidity and support of materials
• Fence design allows fence to be secured to holders to prevent damage and/or loss
• Front bevel knob enables easy adjustment without reaching for operator convenience and precise
setting of bevel angle
• Laser marker enables accurate alignment of blade
and cutting line
10
˝
Sliding Compound Mitre Saw with Laser
SPECIFICATIONS
Blade Diameter
10˝ (255 mm)
Arbor
5/8˝ (15.88 mm)
No Load Speed
3,200 RPM
AMPS (120V)
15.0 A
Overall Dimensions (L xW x H)
31-3/4˝ x 25˝ x 26˝
(805 mm x 644 mm x 660 mm)
Net Weight
57.9 lbs (26.3 kg)
LS1019L
Incorporates Makita's Deep And eXact
Cutting Technology (DXT)
Mitre Saw
Work Station
WST06
STANDARD EQUIPMENT INCLUDES:
10˝ C.T. Blade 32T(721434-1), Socket Wrench 13 (782212-4), Dust Bag (122852-0), Vertical Vise (122536-0),Triangle Rule (762001-3),
Two Safety Switch Buttons (411478-6), Sub PlateAssy (193471-9)
• Electric Brake for increased operator safety
• 2 Stage Safety Switch for increased operator safety
• Bevel Capacity of 45° Left
• Mitre Capacity of 45° Left or 52° Right with Positive Stops at 0°, 15°, 22.5°, 30° and 45°
• Pivoting Fence (Left Side) can be adjusted when bevel cutting or to support larger materials
10˝ Compound Mitre Saw
SPECIFICATIONS
Blade Diameter
10˝ (255 mm)
Arbor
5/8˝ (15.9 mm)
No Load Speed
4,600 RPM
AMPS (120V)
15.0 A
Overall Dimensions (L x W x H)
20-7/8˝ x 18-3/4˝ x 21˝
(530 mm x 476 mm x 532 mm)
Net Weight
27.3 lbs (12.4 kg)
LS1040
Place Directly
AGAINST WALL
&
Model: LS1019
Model: LS1019L (with LASER)
MAXIMIZE
10" Sliding Compound Mitre Saw
Your
WORKSPACE!
