Outdoor Power Equipment Catalogue

4 / 28

POWER CUTTERS
• Reduced noise and fuel consumption versus
competitive 2-stroke models for maximum
operator comfort and reduced operational costs
• No fuel mixing prevents damage due to
improper fuel mixture and eliminates need
to carry separate mixed fuel
• Cleaner 4-stroke emissions limits
environmental impact and reduced
carbon buildup in engine
EK7651H
POWER CUTTER
FEATURES & BENEFITS
Guide Roller
Guide Trolley ACCESSORIES
4-STROKE POWER
SPECIFICATIONS EK7651H
Displacement 4.6 (75.6 cc)
Maximum Power 3.0 kW (4.1 hp)
Ignition System Non-Contact, Magnet Type
Fuel Tank Capacity 1/3 Gal (1.1 L)
No Load Speed 9,100 RPM
Maximum Spindle Speed 4,300 RPM
Maximum Cutting Depth 4-13/16" (12.2 cm)
Dry Weight 28.4 lbs (12.9 kg)
See pages 22-23 for more
POWER CUTTER ACCESSORIES
Angled Fuel Tank Filler
10L (2.5 Gal)
Pressurized
Water Tank
MM4 Premium
4-Stroke Engine Oil
(Part No. T-02484)
75 .6cc
Power Cutter
EK7651H
Shown with Optional Blade(T-02836)
The FIRST 4-Stroke
Power Cutter Available
On The Market!
Automatic
decompression
reduces required
start up force by
40%
20 mm Arbor
14" cutting
wheel
