Outdoor Power Equipment Catalogue

Outdoor

Power Equipment

4-STROKE

POWER

Inverter generator restricts fluctuations

Voltage

less than 3%,

frequency

less than 1%,

wave distortion

less than 2.5%.

Can be used to power your computer or other sensitive equipment

Multi-

monitor

LED

display

Why professionals prefer Makita generators and water pumps powered by

EX series Subaru-Robin™ 4-cycle engines

• Case-hardened steel timing chain allows for precision timing and maximum durability

• Heavy-duty piston rings and a cast-iron cylinder liner resist wear and ensure a long engine life

• Hardened steel rocker arms with precision tappet adjusters are used for greater durability and reduce

service requirements

• Dual ball bearing crankshaft offers maximum durability under load

• Chain-driven overhead cam design offers superior power and performance with an automatic decompression system to

reduce the required pulling force by 30% to 40%. EX engines start easily – even in cold Canadian winters.

• Cooling fins cast into the interior and exterior of the block maximize surface area for superior engine cooling

• Electronic ignition, low oil shut-off and automatic idle / full power throttle control

GENERATORS

3,000W 2,800W 1,700W

169

Generator

EG301A

169

Inverter Generator

G2800I

8.2 Hours

of continuous operation

9.1 Hours

of continuous operation

5+ Hours

of continuous operation

SPECIFICATIONS

EG301A

G2800I

G1700I

Maximum Output Current

3,000W (25 AMP)

2,800W (23.3 AMP)

1,700W (14.2 AMP)

Rated Output Current

2,400W / 20 A

2,500W / 20.8 A

1,350W / 11.2 A

AC Voltage

60 Hz (120V)

DC Voltage

12 VDC (8.3 AMP)

Displacement

169 cc

85.8 cc

Maximum Power

6.0 hp @ 4,000 RPM

2.4 hp @ 4,000 RPM

Fuel Tank Capacity

12.8 L

10 L

3.5 L

Noise Level

70.5 dB

67 dB

59 dB

Overall Length

23-5/8" (60 cm)

19" (48.7 cm)

18-15/16" (49 cm)

Dry Weight

103.4 lbs (47 kg)

82.0 lbs (37.0 kg)

45.2 lbs (20.5 kg)

GENERATOR

FEATURES & BENEFITS

EG301A

G2800I

FEATURES IDLE MODE

G1700I

FEATURES IDLE MODE

Receptacles

Duplex 120V (20 AMP)

Locking 120V (20 AMP)

Duplex 120V (20 AMP)

Generator

Full copper windings, brushless design,

AC & DC circuit breakers

Full copper windings,

AC & DC circuit breakers

Engine

EX series Subaru-Robin™ 4-cycle engine

Inverter Generator

G1700I

When QUALITY & SERVICE Counts – Choose Makita
